SeaStar Solutions® Marine Catalog DOMETIC® Marine

Parts Catalog — Online Page Viewer & Download Options

Mechanical and hydraulic steering systems plus shift and throttle control parts.

Seastar Solutions (Teleflex Marine) catalog

View Online

Flip pages & zoom in — click part numbers to order.

Download PDF

Save for offline viewing — click part numbers to order.
263 pages, 32.6 MB

Prior year's catalog available below: Not suitable for mobile device viewing — best on laptop or desktop screens.

Boat Hydraulic Steering, Mechanical Steering, Control Boxes & Control Cables

Steering
INTRODUCTION	3-22
Overview	3
SeaStar Solutions Steering Cables	4-5
How to Measure Mechanical Steering Cables	6
Steering Options Based on Engine Type	7-8
Mechanical Steering Identification Guide	9-12
SeaStar Hydraulic Steering	13
Hydraulic Steering Identification Guide	14-15
SeaStar Hydraulic Steering Options Based on Boat Type	16-17
Mechanical Steering Kit Overview	18-20
Hydraulic Steering Kit Overview	21
SeaStar Tilt Steering Kit Overview	22

OPTIMUS	23-27
Optimus EPS	24-25
Optimus 360	26-27

OUTBOARD	28-66
Alphabetical Index	29
Outboard Steering Selection Guide	30-31
Tilt Steering	32-33
XTREME Tilt Steering	34
XTREME Steering	35
NFB 4.2 Tilt Mechanical Rotary Steering	36
NFB 4.2 Mechanical Rotary Steering (Dual Cable)	37
NFB 4.2 Mechanical Rotary Steering (Single Cable)	38
NFB Mechanical Rack Steering (Single Cable)	39
NFB Pro Mechanical Rack Steering (Dual Cable)	40
The Rack Mechanical Rack Steering	41
NFB Safe-T II Mechanical Rotary Steering	42
Safe-T QC Mechanical Rotary Steering	43
BayStar 1.4 Steering Kit	44-46
SeaStar Steering (Front Mount Pivot Cylinder)	48
SeaStar Tournament Cylinders	49
Single & Dual Engine Application Guide	50-51
SeaStar PRO Steering (Front Mount Cylinder)	52-53
SeaStar Steering (Splashwell Mount Cylinder)	54-55
SeaStar Steering (Side Mount Cylinder)	56-58
SeaStar Power Assist Steering	59-61
SeaStar Autopilot System	62
SeaStar Autopilot Pump	63
Optimus EPS	64-65
SeaStar Kicker Cable Tie Bar	66

INBOARD	68-99
Alphabetical Index	69
Inboard Steering Selection Guide	70-71
HPS Mechanical Rotary Steering	72
Safe-T QC Mechanical Rotary Steering	73
Big-T Mechanical Rotary Steering (SingleStation)	74
Big-T Mechanical Rotary Steering (Dual Station)	75
HPS Mechanical Rack & Pinion Steering	76
The Rack Mechanical Rack Steering	77
SeaStar 2-Line Hydraulic Steering	78-80
Capilano 2-Line Heavy Duty Hydraulic Steering	81-83
Hynautic 3-Line Heavy Duty Hydraulic Steering	84-85
SeaStar Power Assist Steering	86-87
SeaStar Autopilot System	88
SeaStar Autopilot Pump	89
SeaStar Hydraulic Power Steering	90-95
DC Power Steering Unit	96-97
Hynautic Heavy Duty Trim Tabs	98-99

STERNDRIVE	100-113
Alphabetical Index	101
Sterndrive Steering Selection Guide	102-103
HPS Mechanical Rotary Steering	104
Safe-T QC Mechanical Rotary Steering	105
Big-T Mechanical Rotary Steering (Single Station)	106
Big-T Mechanical Rotary Steering (Dual Station)	107
HPS Mechanical Rack & Pinion Steering	108
The Rack Mechanical Rack Steering	109
SeaStar Sterndrive Steering	110-111
Capilano Heavy Duty Hydraulic Steering	112
Hynautic Heavy Duty Hydraulic Steering	113

JET BOAT STEERING/CATAMARAN	114-121
SeaStar Catamaran Hydraulic	114-117
SeaStar Power Assist Steering	118-119
Jet Boat Mechanical Steering	120
Jet Boat Mini Rack	121

JACKPLATES	122-126
SeaStar HD Jackplates	123
SeaStar Jackplates	124-125
Manual Jackplates	126

WHEELS, HELMS & CYLINDERS	127-177
Steering Wheels	128-131
Helms & Helm Fittings	132-136
Helm Mounting Options	137-138
Cylinders	139-143
Cylinder Service Parts	144-145
Hose & Tubing	146-147
Hydraulic Steering Fluid	148
Mechanical Connection Kits	149-151
Hydraulic Fittings	152-153
Hydraulic Hardware Kits	153-164
Hydraulic Service Tools	165-166
FAQs
Mechanical	167-172
Hydraulic	173-176
NMMA Certification	177

Teleflex Marine is now SeaStar Solutions

Controls
Alphabetical Index	179
Selection Guide	180-181

DUAL FUNCTION CONTROLS	182-194
CH1700 Series	182
CH7500 Series	183
CH7600 Series	184
CH7800 Series	185
SL-3 Series	186-187
MV-3 Series	188
Ski Boat (CH2200P)/Jet Boat (CH2300P)	189
MT-3 Single Lever (CH5310P)	190-191
MT-3 Twin Lever (CH5300P)	190-191
Side Mount (CH2600P)/Side Mount with Trim (CH2700P)	192
DS Unit Controls	193-194

SINGLE FUNCTION CONTROLS	195-200
Single S (CH5210P)/Twin S (CH5200P)	195
Twin SR (CH5400P)	196
SLT (CH5600P)	197
Top Mount Straight (CH4451P)/Raked (CH4481P)	198
ST (CH2400P)/STB (CH2410P)	199
MJB (CH2500P)	200

HYNAUTIC CONTROLS	201

ELECTRONIC CONTROLS	202-204
i6800	202-203
i6300	203
Pro Trim Controls	204

Control Cables
Alphabetical Index	206
Introduction to Control Cables & Overview	207-209
How to Measure Control Cables	209
Control Cables (xtreme)	210-211
Control Cables (OEM/Engine Maker Direct Replacement Types)	212-213
Control Cables Selection Guide Based on Engine Type	214-215
Control Cables (Universal 3300/33C Types)	216-217
Control Cables (Universal 4300/43 & 6400/64 Types)	218-219
Control Cables (Jet Boats)	220-221
Control Cables (Utility, Vernier & DC Control)	222-223
Cross Reference for Other Brands of Control Cables	224-225
SeaStar Solutions Universal Control Cables Identification Guide	226
OEM Direct Replacement Type Cables	227
Connection Kits for Control Cables	228-232
Installation Tips	233
Technical Reference / FAQs	234-238

Interchange
Product Codes	247
Product Interchange	248-252
Part Number to Page Number Interchange	253-259
