106
®
BIG-T® MECHANICAL ROTARY
STEERING (SINGLE) SYSTEM:
The Original SeaStar Solutions Steering System!
For over 50 years, Big-T® has been the most
durable and versatile mechanical steering
system made with both single and dual station
capability. The heavy duty helm incorporates
a strong steel pinion, dual diecast gears and
meaty shaft bearing supports, all encased in a
rugged gear housing. It’s no wonder owners of
small inboards have counted on the Big-T since
1963!
APPLICATIONS:
Inboards to 34 feet with one engine. Also suitable for
sterndrive boats with power-assisted steering. Big-T
systems accept steering wheels up to 20" diameter.
The type of system shown on this page is for single
station use. For dual station Big-T, please see the next
page.
FEATURES:
Available in single or dual station versions.
(See next page for dual station version.)
Responsive 3 turns from lock-to-lock.
Standard 3/4” round tapered steering shaft.
Stainless steel cable output ends.
2-piece bezel for 90° or 20° helm mount
to dash.
Uses SeaStar Solutions SSC62 type cable.
Meets A.B.Y.C. standards.
Meets N.M.M.A. certification requirements.
Made, designed and assembled in the USA.
BIG-T
®
SINGLE STATION SYSTEM
(Steering Wheel not included.)
COMPLETE SYSTEM
This steering system is sold by components. Select helm,
bezel and cable from items listed below.
COMPONENTS
Big-T Helm (single station push-pull)
Big-T Cable (QC II Cable)
Replaces SSC72XX
Includes SA27620P Helm Converter
SSC61XX
Bezel 2-pc. Black (90°/20° mount)
OPTIONS
Cable Gard (fits most tilt tubes)
SERVICE ITEMS
Steering Wheel Hardware Kit
(Old #2745417P)
Spent Travel Tube (Big-T)
* Can also use steering cable SSC62xx and helm
converter SA27620P
STEERING - Sterndrive (Mechanical)
