CAPILANO 2-LINE HEAVY DUTY
HYDRAULIC STEERING SYSTEM:
Uncompromising Design. Capilano steering
stands for ruggedness and reliability
worldwide. Helms include a variable
displacement feature enabling the helmsman
to adjust the number of steering wheel turns
to suit maneuvering and weather conditions.
Capilano systems install easily and give years
of dependable service.
APPLICATIONS:
Most inboard powered boats with single or dual
engines including planing/displacement hull craft
from 30-55 feet in length. Suitable for dual station
use with the purchase of extra helm, tubing/hose &
fittings. Capilano systems use Dexron II® type ATF
fluid.
FEATURES:
Variable displacement helms for adjustable
number of steering wheel turns.
Heavy duty brass cylinders with bleed fittings;
chrome-plated stainless steel rods.
Stainless steel and bronze mounting hardware.
Easy installation on single and dual rudder vessels.
Systems are not air-pressurized; no air leaks or
pressure drops; separate reservoir not needed.
Built-in pressure relief in helm protects system
rom effects of thermal expansion.
Standard 3/4” tapered steering shaft.
Meets ABS/Lloyd/Det Norske Veritas specifications.
(SINGLE STATION)
(DUAL STATION)
COMPLETE SYSTEM
System components sold separately. See application
guide to select appropriate items.
COMPONENTS
Capilano 1250V Helm
HH5250 or
Capilano 1275V Helm
Inboard Cylinder
Copper Tubing
1/2” or 5/8” OD
Fitting Kit (for 1/2” Copper Tubing)
HF5590 or
Fitting Kit (for 5/8” Copper Tubing)
Hose Kit for Copper Tubing (2 hoses)
Capilano Steering Fluid
Dexron II® ATF
OPTIONS
Dual Cylinder Hose 2’ (.6m)
Dual Cylinder Hose 3’ (.9m)
Dual Cylinder Hose 4’ (1.2m)
Dual Cylinder Hose 5’ (1.5m)
Dual Cylinder Hose 6’ (1.8m)
Fixed Mount Cylinder (13.3 cu. in.)
(one ball joint end)
Fixed Mount Cylinder (13.3 cu. in.)
(two ball joint ends)
Pivot Mount Cylinder (25.5 cu. in.)
Universal Mount Cylinder (55 cu. in.)
Add-A-Station Fitting Kit (1/2” tubing)
Add-A-Station Fitting Kit (5/8” tubing)
Helm Remote Fill Kit (through-dash)
SERVICE ITEMS
Steering Fluid
Dexron II® ATF
Steering Wheel Locknut
