ENGINE ACCESSORIES
Model
Model Notes
Year Range
Serial # Range
Closed Cooling Kit
Installations Kit
MIE V-8 (305 & 350 cid)
Hurth or V-drive transmission & CEO exh manifolds
1981 - 1997
5907058 - 0K999999
N.L.A.
N.L.A.
MIE V-8 (350 & 377 cid Gen+)
1997 - 2001
0K040300 - 0M299999
N/A
MIE V-8 (350 cid Gen+)
Carb engines
2002
0M300000 - 0M316999
N/A
MIE V-8 (350 & 377 cid Gen+)
MPI engines
2002
0M300000 - 0M316999
N/A
MIE V-8 (454 cid)
Carb engines & B/W 72 in-line series transmission
1981 - 1997
5889914 - 0K999999
N.L.A.
N.L.A.
MIE V-8 (454 cid)
Carb engines & B/W or Hurth V-drive trans.
1981 - 1997
5889914 - 0K999999
N.L.A.
N.L.A.
MIE V-8 (454 cid)
Carb engines & Hurth down-angle or B/W 5000
1989 - 1997
0C391564 - 0K999999
N.L.A.
N.L.A.
MIE V-8 (454 cid)
EFI engines & all transmissions
1995 - 1996
0F563052 - 0F820141
N/A
MIE V-8 (454 cid)
EFI engines & all transmissions
1996 - 2001
0F820142 - 0L674613
N/A
MIE V-8 (502 cid)
EFI engines & all transmissions
1990 - 2001
0C878221 - 0L674200
N/A
(1) This installation kit is required when 3 in. (76 mm) or 6 in. (152) risers are installed.
(2) Order this hose kit if engine is equipped with 5/8 in. (16 mm) I.D. hose and fittings from the back of the intake manifold to the engine water circulating pump
(3) Use ONLY rear mounted closed cooling kit
(4) Use ONLY front mounted closed cooling kit
(5) No kit available
CLOSED COOLING KIT CHART - SKI (PRE-DRY JOINT EXH)
SKI Closed Cooling Kits (2002 and older)
Model
Model Notes
Year Range
Serial # Range
Closed Cooling Kit
Installation Kit
FRONT MOUNTED COOLING KITS
Black Scorpion Ski
1996 - 2002
0F800000 - 0M316999
N/A
MX 6.2 MPI Black Scorpion Ski
2001 - 2002
0L680003 - 0M316999
N/A
Ski V-8 (350 cid)
EFI engines
1994 - 1996
0F215561 - 0K040005
(1)
N/A
Ski V-8 (350 cid)
2 bbl. carb and v-belt
1994 - 1996
0F160285 - 0K040003
N/A
Ski V-8 (350 cid)
4 bbl. carb and v-belt
1994 - 1996
0F160100 - 0K040399
N/A
Ski V-8 (350 cid)
2 bbl. carb & serpentine belt
1997
0K040004 - 0K999999
N/A
Ski V-8 (350 cid)
4 bbl. carb & serpentine belt
1997
0K040400 - 0K999999
N/A
Ski V-8 (350 cid Gen+)
1997 - 2001
0K040006 - 0M299999
N/A
Ski V-8 (350 cid Gen+)
Carb engines
2002
0M300000 - 0M316999
N/A
Ski V-8 (350 cid Gen+)
MPI engines
2002
0M300000 - 0M316999
Ski V-8 (454 cid)
1995 - 1996
0F215800 - 0F820099
(1)
N/A
REAR MOUNTED COOLING KITS
Black Scorpion Ski
1996 - 2002
0F800000 - 0M316999
(1)
N/A
MX 6.2 MPI Black Scorpion Ski
2001 - 2002
0L680003 - 0M316999
(1)
N/A
Ski V-8 (350 cid)
EFI engines
1994 - 1996
0F215561 - 0K040005
(1)
N/A
Ski V-8 (350 cid)
Carb engines & in-line transmission
1994 - 1997
0F160100 - 0K999999
N.L.A.
N.L.A.
Ski V-8 (350 cid)
Carb engines & V-drive transmission
1994 - 1997
0F160100 - 0K999999
N.L.A.
N.L.A.
Ski V-8 (350 cid Gen+)
1997 - 2001
0K040006 - 0M299999
N/A
Ski V-8 (350 cid Gen+)
Carb engines
2002
0M300000 - 0M316999
N/A
Ski V-8 (350 cid Gen+)
MPI engines w/ ECM 555
2002
0M300000 - 0M316999
US Quicksilver Product Guide
1211
