ENGINE ACCESSORIES
Year
Serial # Range
Closed Cooling Kit
Belt Kit
Seawater Pump Kit
Model
Model Notes
Heat
Range
Exchanger
Location
MCM V-8 (502 cid) Bravo
EFI engines & serpentine belt
Front
1998 - 2001 0L017000 - 0M024999 807639A 3
N/A
(1) This kit will fit all engines except the 1996 262 Mag EFI engines (S/N 0F803800 - 0F999999) with VST fuel system which does not have a kit available for it.
(2) Thru hull water pickup is not included with seawater pump kits
(3) If the seawater temperature that this boat will be operating in does not exceed 80 deg. F {26 deg. C}, a Seawater Pump Kit does not have to be installed. If the seawater temperature exceeds 80 deg. F {26 deg.
C} , then a Pump kit is required.
(4) 807901A 4 Belt Kit: Order this belt kit instead of the one listed if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
(5) 861578 P/S Pulley: Order this metal 5-3/4 in. (146 mm) P/S pulley if the engine has a plastic 4-3/4 in. (121 mm) O.D. power steering pulley. Reference MerCruiser Parts Bulletin 98-1
(6) Note the additional required kit(s) listed to complete the installation.
(7) 807901A 3 Belt Kit: Order this belt kit instead of the one listed if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
(10) 57-861050 Belt Kit: Order this belt kit if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
(11) 860315A 2 Extender and Hose Kit: Also order this kit if installing on a V-6 or V-8 (305 CID) with a carburetor
(12) Kit will not fit 1995-1996 (350 CID) EFI engines (S/N 0F225560 - 0F999999) with VST fuel system. No kit available.
(13) 32-861070T Fuel Line: Order this fuel line if the engine is below S/N 0K154018 and has a 2 bbl carburetor
(14) 85152A 2 Oil Cooler: This kit is required if boat will be operated in seawater above 90 Deg. F {32 Deg. C}
(15) 17833A 7 Installation Kit: This kit is required when 3 in. (76 mm) or 6 in. (152 mm) risers are installed.
(16) 32-62987A 3 Hose Kit: Order this kit if engine is a 7.4LX TBI and is equipped with 5/8 in. (16 mm) I.D. hose and fittings from the back of the intake manifold to the engine water circulating pump
(17) 44443A 3 Installation Kit: This kit is also required
(18) No kit available
(19) Closed cooling kit will not fit 3.0L engines with side mounts
(20) 57-863876 8 Belt Kit: Order this belt kit if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
(21) 57-863876 9 Belt Kit: Order this belt kit if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
(22) 889432A 1 Belt Kit: Order this belt kit if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
(23) 889433A 1 Belt Kit: Order this belt kit if the engine is in a dual engine boat and you are going to remove the power steering pump and hoses from this engine.
CLOSED COOLING KIT CHART - MIE (PRE-DRY JOINT EXH)
MIE Closed Cooling Kits (2002 and older)
Model
Model Notes
Year Range
Serial # Range
Closed Cooling Kit
Installations Kit
FRONT MOUNTED COOLING KITS
MIE V-8 (305 & 350 cid)
In-line transmission & CEO exh manifolds
1981 - 1993
5907058 - 0F024999
N/A
MIE V-8 (305 & 350 cid)
V-drive transmission & CEO exh manifolds
1981 - 1993
5907058 - 0F024999
(3)
N/A
MIE V-8 (350 cid)
All transmissions
1994 - 1996
0F025000 - 0K040306
N/A
MIE V-8 (350 cid)
Carb engine & serpentine belt
1997
0K040307 - 0K999999
MIE V-8 (350 & 377 cid Gen+)
1997 - 2001
0K040300 - 0M299999
N/A
MIE V-8 (350 cid Gen+)
Carb engines
2002
0M300000 - 0M316999
N/A
MIE V-8 (350 & 377 cid Gen+)
MPI engines
2002
0M300000 - 0M316999
N/A
MIE V-8 (454 cid)
Carb engines & B/W 72 series in-line or V-drive
1992 - 1997
0D715494 - 0K999999
N/A
MIE V-8 (454 cid)
Carb engines & Hurth or B/W 5000 transmission
1992 - 1997
0D715494 - 0K999999
N.L.A.
N.L.A.(1)
MIE V-8 (454 cid Gen V)
EFI engines
1995 - 1996
0F563052 - 0F820103
N/A
MIE V-8 (454 cid Gen VI)
EFI engines
1996 - 2001
0F820104 - 0L674613
N.L.A.(2)
MIE V-8 (502 cid)
Hurth transmission & cast iron exh manifolds
1990 - 1992
0C878221 - 0D857199
N.L.A.
N.L.A.(1)
MIE V-8 (502 cid)
Hurth transmission & stainless steel exh manifolds
1990 - 1992
0C878221 - 0D857199
N.L.A.
N.L.A.(1)
MIE V-8 (502 cid)
Carb engines & B/W 72 series in-line or V-drive
1993 - 1996
0D857200 - 0F819619
N/A
MIE V-8 (502 cid)
Carb engines & Hurth or B/W 5000 transmission
1993 - 1996
0D857200 - 0F819619
N.L.A.
N.L.A.(1)
MIE V-8 (502 cid Gen VI)
EFI engines
1996 - 2001
0F819620 - 0L674200
N/A
REAR MOUNTED COOLING KITS
MIE V-8 (305 & 350 cid)
B/W in-line transmission & CEO exh manifolds
1981 - 1997
5907058 - 0K999999
N.L.A.
N.L.A.
1210
