STEERING
HYDRAULIC HELM PUMP -Q/S-TILT
Front Mount Standard helm ‑ 2.0 cu in (33CC.) displacement. Approximately 4.7
turns lock to lock on singles
and 7.3 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI
(Use
Compression style fittings and hoses)
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.
HYDRAULIC HELM PUMP -Q/S
Front Mount 2.4 cu in (39 CC) displacement. Approximately 3 turns lock to lock on
singles (Use Compression style fittings and hoses)
and 6.5 on dual cylinders
Compact design
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
installs. Hose series is 8M0053474 thru 8M0053492
Front Mount 2.4 cu in (39 CC) displacement. Approximately 3 turns lock to lock on
singles (Use Compression style fittings and hoses)
HYDRAULIC STEERING KIT -Q/S
and 6.5 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
installs. Hose series is 8M0053474 thru 8M0053492
HYDRAULIC HELM PUMP - COMPRESSION STYLE
FITTINGS
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (14 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (16 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (18 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above
Front Mount Tilt helm ‑ 1.5 cu in (25 CC.) displacement. Approximately 5 turns
lock to lock on singles
and 8 on dual cylinders
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (20 ft)
Compact design
Approximately 5 turns lock to lock on a single engine
Built‑in valve for positive rudder lock
Hydraulic Steering ‑ 75 HP engines and above
Integral relief valve for over pressure protection ‑ 1500 PSI
(Use
Compression style fittings and hoses)
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (22 ft)
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
Approximately 5 turns lock to lock on a single engine
steering installation.
Hydraulic Steering ‑ 75 HP engines and above
Front Mount Tilt helm ‑ 2.0 cu in (33 CC.) displacement. Approximately 4.7 turns
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (24 ft)
lock to lock on singles
Approximately 5 turns lock to lock on a single engine
and 7.3 on dual cylinders
Compact design
Hydraulic Steering ‑ 75 HP engines and above
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI
(Use
Compression style fittings and hoses)
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.
