STEERING
STEERING
CYLINDER WITH COMPRESSION STYLE FITTINGS
QUICKSILVER HYDAULIC STEERING SYSTEMS-
COMPRESSION FITTINGS
Most robust steering system in the market.
Ideal for most large outboards
CYLINDER - HYDRAULIC - STANDARD
Heavy Duty Hydraulic standard cylinder that uses compression hoses 8M0053474
‑ 8M005053491. This cylinder is tested to Mercury's rigid standards that include
higher loads and cycle testing to 300,000 cycles. It includes machined, high
strength fasteners, electro polished SS arm, and heavy duty triple seal cartridges
for enhanced duribility and longevity
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on
single, dual and triple installations
This Basic hydraulic cylinder has the same robust performance design requirement
as our heavy duty cylinder. It is qualified to the same 300,000 cycle as our other
steering systems, has high strength fasteners, stainless steel arm, heavy duty triple
CYLINDER WITH COMPRESSION STYLE FITTINGS-
seal cartridges for enhanced duribilty and longevity high quality fittings using
PORT
swaged compression style hose connections.
All Single Outboard ‑ 150 HP and below
(1.5L Opti engine requires the special arm ‑ cylinder 8M0056619)
HYDRAULIC HELM - BASIC SYSTEM
Heavy Duty Hydraulic cylinder counter rotation that uses compression hoses
8M0053474 ‑ 8M005053491. This cylinder is tested to Mercury's rigid standards
that include higher loads and cycle testing to 300,000 cycles. It includes machined,
high strength fasteners, electro polished SS arm, and heavy duty triple seal
cartridges for enhanced duribility and longevity
This hydraulic helm is a std 20 CC / 1.2 Cu Inch helm with compression style
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel
dual and triple installations (Counter rotation )
with a composite tank. The pressure relief is 1000 PSI for high torque
applicactions for improved performance. (5.2 Lock to lock wheel turns).
HYDRAULIC HELM PUMP - COMPRESSION STYLE
Single engine 75‑150 HP ( includes new 150 HP 4 Stroke)
FITTINGS
HYDRAULIC HELM - BASIC SYSTEM
Front Mount Standard helm ‑ 1.5 cu in (25 CC.) displacement. Approximately 5
turns lock to lock on singles (Use Compression style fittings and hoses)
This hydraulic helm is a Tilt 20 CC / 1.2 Cu Inch helm with compression style
and 8 on dual cylinders
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel
Compact design
with a composite tank. The pressure relief is 1000 PSI for high torque
Built‑in valve for positive rudder lock
applicactions for improved performance. (5.2 Lock to lock wheel turns).
Integral relief valve for over pressure protection‑ 1500 PSI
Single engine 75‑150 HP OB (Includes new 150 HP 4 stroke)
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.
US Quicksilver Product Guide
285
