REMOTE CONTROLS
REMOTE CONTROLS
SIDE MOUNT REMOTE CONTROL
SIDE MOUNT CONTROLS
Outboard Use only
SIDE MOUNT REMOTE CONTROL
For non‑power trim models, 15 ft.(4.58 m) harness and without warning horn.
Features "push throttle cable operation" compared to most other remote controls
which are "pull throttle cable operation." New design with soft grip. Ref throttle/shift
cables 877773A__
Fits Mercury/Mariner 20/25 (U.S. S/N 0G044026 and below; Belgium S/N 9807908
and below)
For non‑power trim models, 15 ft.(4.58 m) harness and built‑in warning horn. New
design with soft grip. Ref. Throttle/shift cable Gen I ‑ 897977A__. Throttle/Shift
SIDE MOUNT REMOTE CONTROL
cables (896143A) for MY2005 and newer 8/9.9 FourStroke outboards. 8‑9.9 4
Stroke engines generation change above S/N OR192772 and new 15/20 4 Stroke
engines will use Gen I series T/S Cables
Fits all current Mercury/Mariner outboards 6 hp. and above (without power trim),
and 1993 and newer Force outboards 40 hp and higher utilizing Mercury style
cables (with power trim). When used with a MY2005 and newer 8/9.9 /
15/20FourStroke outboard an adapter harness 892473A01 is required. R/C cables
must use the Gen I cable for connection to this control
SIDE MOUNT REMOTE CONTROL
For manual start models, 20 ft.(6.1 m) harness. Features "push throttle cable
operation" compared to most other remote controls which are "pull throttle cable
operation." New design with soft grip. Toggle switch on control for remote shut off
of engine. Ref throttle/shift cable 897977A__
Fits older push style throttle Mercury/Mariner 20/25 (U.S. S/N 0G044026 and
below; Belgium S/N 9807908 and below) and Force 9.9/15 (1997 and older).
SIDE MOUNT REMOTE CONTROL
For manual start models, 20 ft.(6.1 m) harness. New design with soft grip. Toggle
switch on control for remote shut off of engine. Ref. Throttle/shift cable Gen I ‑
897977A__. Throttle/Shift cables (896143A) for MY2005 and newer 8/9.9
FourStroke outboards. 8‑9.9 4 Stroke engines generation change above S/N
OR192772 and new 15/20 4 Stroke engines will use Gen I series T/S Cables
Fits current pull style throttle, manual start Mercury/Mariner 6 thru 25, 30/40 (2 cyl.‑
U.S. origin), 40 (3 & 4 cyl.) to 45 models, 8/9.9/15/20 4‑stroke models (1996 and
newer), and Force 25 (3 cyl.). R/C Cable must be a Gen I to connect to control
For non‑power trim models, 15 ft.(4.58 m) harness and without warning horn. New
design with soft grip. Ref throttle/shift cables 897977A__
Fits Mariner 30 to 55 (Japanese origin), except 30/40 (2 cyl.) with integral oil
injection.
US Quicksilver Product Guide
269
