INSTRUMENTS
FLAGSHIP OIL PRESSURE GAUGE
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for connection to light.
Black face and Black bezel with Blue/White graduations. Replacement Gauge
only
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22-86306.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE
Anti‑fog lens. Black face and Black bezel; Blue / White graduations.
Fits D3.0L, D3.6L, and 4.2L diesels (1994 & newer) and D2.8, D4.2L, and D7.3L
ES & EI models (1997 & newer).
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP OIL LEVEL GAUGE KIT
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for connection to light.
Black face and bezel; blue graduations. Complete kit. Includes 25 ft.(7.6 m) of
tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
Mercury Branded, Box Point of Sale Packaged.
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for connection to light.
Black face and bezel; blue graduations.. Replacement gauge only.
Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
Anti‑fog lens. Black face and Black bezel; Blue/White graduations.
Mercury Branded, Box Point of Sale Packaged.
Fits V‑6 outboard 3 US gal.(11.34 L) and 1.8 US gal.(6.8 L) remote oil reservoirs.
FLAGSHIP OIL PRESSURE GAUGE
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP FUEL GAUGE
Anti‑fog lens. Black face and Black bezel; Blue/White graduations.
Fits all MCM/MIE gasoline engines and Mercury/Mariner 25/30/40/45/50/225
(4‑stroke) outboards. Sender, if not already installed on the outboard, must be
Anti‑fog lens. Black face and Blue bezel; black graduations. 12 volt system and
purchased separately.
240 ohm sender required.
Mercury Branded, Box Point of Sale Packaged.
Mercury Branded, Box Point of Sale Packaged.
Anti‑fog lens. Black face and bezel; blue graduations. 12 volt system and 240 ohm
sender required. Priced and packaged in quantites of 24 pcs
Mercury Branded, Box Point of Sale Packaged.
US Quicksilver Product Guide
191
