INSTRUMENTS
FLAGSHIP VOLT METER
FLAGSHIP WATER TEMPERATURE GAUGE
Anti‑fog lens. Black face and Black bezel; White/Blue graduations.
Anti‑fog lens. 100 deg.‑240 deg.F gauge. Black face and Black bezel; White/Blue
Outboards require a tachometer harness or ignition/choke assembly for
graduations.
connection.
Diesel
Mercury Branded, Box Point of Sale Packaged.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE
Anti‑fog lens. Black face and Black bezel; White/Blue graduations. Outboards
require a tachometer harness or ignition/choke assembly for connection. Pricing
and packaging will be in qyuantities of 24 pcs.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER TEMPERATURE GAUGE
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
Black face and bezel; blue graduations. Complete kit. Includes 25 ft.(7.6 m) of
tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Anti‑fog lens. 120 deg.‑240 deg.F gauge. Black face and Black bezel; White/Blue
graduations.
Mercury Branded, Box Point of Sale Packaged.
Fits all MCM/MIE gasoline engines and Mercury/Mariner V‑6 outboards. Sender, if
not already installed on the outboard, must be purchased separately.
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
Mercury Branded, Box Point of Sale Packaged.
Black face and bezel; blue graduations. Replacement gauge only
FLAGSHIP WATER TEMPERATURE GAUGE
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE
Anti‑fog lens. 60 deg.‑200 deg.F gauge. Black face and Black bezel; White/Blue
graduations.
Fits Mercury/Mariner 25 thru 115 FourStroke, 225 FourStroke, 40 (3 & 4 cyl.), 45,
50/60 (3 cyl.), and 70 to 125 hp ; and 1993 and newer Force outboards (Force
models must order sender FA299791) Sender need to be ordered seperately
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for connection to light.
Mercury Branded, Box Point of Sale Packaged.
Black face and Black bezel with Blue/White graduations. Complete kit. Includes 25
ft.(7.6 m) of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22-86306.
Mercury Branded, Box Point of Sale Packaged.
190
