CORROSION PROTECTION
ANODES - MISCELLANEOUS
ANODE CHARTS - ACCESSORIES AND INBOARD
Closed Cooling Anodes
Model
Year Range Anode
Mat. Size
120/140/165
1972 - 1982 22-65129 Zinc 1-1/2 inch X 1/2 inch anode w/ 3/8 inch pipe
plug
888/215/225
1972 - 1977 22-65129 Zinc 1 1/2 inch X 1/2 inch anode w/ 3/8 inch pipe plug
233/255
1973 - 1977 22-65129 Zinc 1 1/2 inch X 1/2 inch anode w/ 3/8 inch pipe plug
255/280 (G.M.)
1975 - 1977 22-65129 Zinc 1 1/2 inch X 1/2 inch anode w/ 3/8 inch pipe plug
325/350
1972 - 1976 22-65129 Zinc 1 1/2 inch X 1/2 inch anode w/ 3/8 inch pipe plug
888/215
1971
N.L.A.
Zinc 1 3/4 inch X 3/8 inch anode w/ 1/4 inch pipe plug
325/350
1971
N.L.A.
Zinc 1 3/4 inch X 3/8 inch anode w/ 1/4 inch pipe plug
7.3L V-8 Diesel
1993 - 1995 -
Zinc 2 inch X 1/2 inch anode with 3/8 inch pipe plug
530/636 Diesel
1989
-
Zinc 3/4 inch X 3/4 inch anode only
D183/D219 Diesel 1990 - 1993 -
Zinc 3/4 inch X 3/4 inch anode only
D254 Diesel
1990 - 1993 -
Zinc 3/4 inch X 3/4 inch anode only
D3.0/D3.6L Diesel 1994 - 1995 -
Zinc 3/4 inch X 3/4 inch anode only
D4.2L Diesel
1994 - 1995 -
Zinc 3/4 inch X 3/4 inch anode only
Tear‑Drop Anodes
Part Number Mat. Nominal Weight
Diameter A - in.
Dimension B -
Dimension C -
- lbs.(kg)
(mm)
in.(mm)
in.(mm)
N.L.A.
Zinc .40(.18)
3-1/2 in.(89)
1-3/4 in.(44)
1-3/8 in.(35)
N.L.A.
Zinc 1.00(.45)
5-1/4 in.(134)
2 in.(50)
1-5/8 in.(41)
Rudder Anodes
Part Number Mat.
Nominal Weight - lbs.(kg)
Diameter A - in.(mm) Dimension B - in.
(mm)
N.L.A.
Zinc
.20(.09)
1-7/8 in.(47)
1/4 in.(6)
N.L.A.
Zinc
.90(.40)
2-13/16 in.(71)
1/2 in.(13)
N.L.A.
Zinc
1.40(.64)
3-3/4 in.(95)
1/2 in.(13)
1190
