POWER TRIM
Original Trim
Original Trim
Original Trim
Model
Year Range
Serial # Range
Replacement Trim
Replacement Trim
Original Trim
Cylinder Seal Kit
Cylinder Outer
Cylinder Outer
Cylinder - Port
Cylinder - Starboard Cylinder Overhaul
Housing - Stbd.
Housing - Port
Kit
Alpha One SS
1986 - 1989
0A545004 and up
98703A 3(11)
98704A 3(11)
98703A10(6)
98704A10(8)
Alpha One SS
1986 - 1989
0A545004 and up
14035A 3(12)
14034A 3(12)
14035F 1(4)
14034F 1(3)
Alpha One Gen II
1991 - 2013
0D469859 and up
Vazer
2007 - 2009
0W995000 and up
N/A
N/A
N/A
N/A
Bravo
1988 - 2013
0B664190 and up
Bravo SeaCore
2007 - 2013
0W900000 and up
N/A
N/A
Blackhawk
1994 - 1995
0F186717 and up
II (1.78)
1968 - 1969
2398798 - 2671321
N.L.A.
N.L.A.
N/A
N/A
N/A
N/A
III
1968 - 1972
2373127 - 3002613
N.L.A.
N.L.A.
N/A
N/A
N/A
N/A
215H
1970
2782203 - 2909034
N.L.A.
N.L.A.
N/A
N/A
N/A
N/A
215E
1970 - 1972
2909035 - 2915034
N.L.A.
N.L.A.
N/A
N/A
N/A
N/A
TR/TRS
1973 - 1993
3377316 and up
N.L.A.(10)
N.L.A.(10)
N/A(10)
47342A22(2)
47342A22(2)
25-47389A 2(10)
TR/TRS
1973 - 1993
3377316 and up
N.L.A.(10)
N.L.A.(10)
N/A(10)
N.L.A.(1)
N.L.A.(1)
25-47389A 2(10)
TR/TRS
1973 - 1993
3377316 and up
87411A 3(9)
87412A 3(9)
86611A 1(9)
87411A 6(9)
87412A 6(9)
25-79871A 1(9)
(1) 11-3/8 inch long tubes- internal cylinder lines
(2) 13-3/4 inch long tubes- internal cylinder lines
(3) Casting# 14034 1
(4) Casting# 14035 1
(5) Casting# 98703
(6) Casting# 98703 1
(7) Casting# 98704
(8) Casting# 98704 1
(9) External trim lines
(10) Internal trim lines
(11) Use with 15-9/16 inch long trim cylinder tube
(12) Use with 16-3/16 inch long trim cylinder tube
(13) Trim cylinder with internal trim lines
(14) Trim cylinders using external trim lines
REAR ANCHOR PIN KIT
TRIM CYLINDER ANCHOR PINS & KITS
FRONT ANCHOR PIN KIT
9.18 in. OAL, .625 in. O.D., 7/16‑20 threads
Fits R, MR & Alpha One
11.87 in. OAL, .625 in. O.D., 7/16‑20 threads
Fits R, MR & Alpha One
