STEERING
CYLINDER - HYDRAULIC OR P/S- COUNTER ROTATION
TIE BARS - TRIPLE ENGINES
Port ot counter rotation cylinder designed to meet all Power Steering strength and
performance requirements. This cylinder is the most robust design in the market.
Includes all hardware to mount this cylinder including the strongest bolts to attach
to the engine
26 Inches long
Verado 135‑200 ‑ both Power Steering or Hydraulic‑ Multiple Engines
Outboard centerline spacing of 66.0 cm (26 in.)
V6/1.5 Opti Max Hydraulic‑ 1.5L Opti needs to order arm 898082A03 to provide
OptiMax Multiple Engines
clearance
135‑200 Verado L4
75‑115 4 stroke engines
Multiple OtiMax engines‑ P/S
150 4
Stroke engines
28 Inches long
MERCURY HYD BOLT-ON STEERING KIT- STD -W/O
Outboard centerline spacing of 71.1 cm (28 in.)
HOSES
OptiMax Multiple Engines
135‑200 Verado L4
892789Q34
30 Inches long
Outboard centerline spacing of 71.1 cm (28 in.)
OptiMax Multiple Engines
135‑200 Verado L4
QUICKSILVER HYDAULIC STEERING -POWER
STEERING FITTINGS
Most robust steering system in the market.
This kit includes a standard helm (1.5Cu Inch) with all the needed components to
install the helm along with a bolt‑on cylinder with hardware . This bolt‑on kit is the
Ideal for most large outboards
most robust hydraulic system in the market. The cylinder was tested to all Verado
standards for load and strength. The kit also includes high strength machined
CYLINDER - HYDRAULIC OR POWER STEERING
stainless steel screws that are used at each attachment point. Order Verado hoses
897892K__ series separately
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti)
MERCURY HYD BOLT-ON STEERING KIT-TILT -W/O
HOSES
Cylinder designed to meet all Power Steering strength and performance
requirements. This cylinder is the most robust design in the market. Includes all
hardware to mount this cylinder including the strongest bolts to attach to the engine
Verado 135‑200 ‑ both Power Steering or Hydraulic
V6/1.5 Opti Max Hydraulic‑ 1.5L Opti needs to order arm 898082A03 to provide
clearance
75‑115 4 stroke engines
Multiple
This kit includes a Tilt helm (1.5 Cu Inch) with all the needed components to install
150 4 stroke engines
the helm along with a bolt‑on cylinder with hardware and remote fill kit. This
bolt‑on kit is the most robust hydraulic system in the market. The cylinder was
tested to all Verado standards for load and strength. The kit also includes high
strength machined stainless steel screws that are used at each attachment point.
Order Verado hoses (897982K__) separately
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti)
290
