ELECTRICAL
KEY SWITCH KIT - 4 POSITION MATCHED KEYS-
TRIPLES
11 ft.(3.35 m) harness with audio warning horn.
Fits Mercury/Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury/Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
outboards an adapter harness 892473A01 is required.
15 ft.(4.57 m) harness with audio warning horn.
Fits Mercury/Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury/Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
outboards an adapter harness 892473A01 is required.
84-816626A 20
Four position keyswitch‑ triple engines (Off, Accessory, Run and Start) Includes
matched keyswitch , key cover, bezel, 2 1/8 in. Dia. mounting housing and
20 ft.(6.1 m) harness with audio warning horn.
mounting hardware. 7/8 in. cut out.
Fits Mercury/Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Triple engine ‑ matched key set
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury/Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
KEY SWITCH KIT - 4 POSITION MATCHED KEYS-
outboards an adapter harness 892473A01 is required.
QUADS
84-816626A 24
25 ft.(7.6 m) harness with audio warning horn.
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
outboards an adapter harness 892473A01 is required.
84-816626A 25
25 ft.(7.6 m) harnesses with audio warning horn. Packaged with 2 harnesses with
matched keys for dual engine applications.
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Four position keyswitch‑Quad engines (Off, Accessory, Run and Start) Includes
Mercury Jet Drives.
matched keyswitch , key cover, bezel, 2 1/8 in. Dia. mounting housing and
mounting hardware. 7/8 in. cut out.
84-816626A 29
Quad engine ‑ matched key set
30 ft.(9.1 m) harnesses with audio warning horn.
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
HARNESS - ENGINE TO HELM 8 PIN
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives.
KEY SWITCH W/ HARNESS
30 ft.(9.1 m) harnesses with audio warning horn. Packaged with 2 harnesses with
matched keys for dual engine applications.
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives.
2 ft.(610 mm) harness with audio warning horn.
Fits Mercury/Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury / Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
outboards an adapter harness 892473A01 is required.
8 ft.(2.44 m) harness with audio warning horn.
Fits Mercury/Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin) outboards,
Mariner 30/40 hp. with oil injection (2 cycle, Japanese Origin), all Mercury/Mariner
4‑Stroke (USA Origin) outboards, Force 40 hp. and Higher (1993 and Newer) and
Mercury Jet Drives. When used with MY2005 and newer 8/9.9 hp. FourStroke
outboards an adapter harness 892473A01 is required.
US Quicksilver Product Guide
253
