INSTRUMENTS
ADMIRAL WATER PRESSURE GAUGE
ADMIRAL VOLT METER
Anti‑fog lens. Black face and Chrome bezel; red/white graduations. Outboards
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
require a tachometer harness or ignition/choke assembly for connection.
Black face and Chrome bezel; red graduations. Complete kit. Includes 25 ft.(7.6 m)
of tubing and hardware.
Quicksilver Branded, Box Point of Sale Packaged.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
ADMIRAL WATER TEMPERATURE GAUGE
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22-86306.
Quicksilver Branded, Box Point of Sale Packaged.
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
Black face and Chrome bezel; red graduations. Replacement gauge only.
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Quicksilver Branded, Box Point of Sale Packaged.
ADMIRAL WATER PRESSURE GAUGE
Anti‑fog lens. 100 deg.‑240 deg.F gauge. Black face and Chrome bezel; red
graduations.
Fits all MCM/MIE gasoline engines and Mercury/Mariner V‑6 outboards. Sender, if
not already installed on the outboard, must be purchased separately.
Quicksilver Branded, Box Point of Sale Packaged.
ADMIRAL WATER TEMPERATURE GAUGE
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for connection to light.
Black face and Chrome bezel; red graduations. Complete kit. Includes 25 ft.(7.6 m)
of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22-86306.
Quicksilver Branded, Box Point of Sale Packaged.
Anti‑fog lens. 60 deg.‑220 deg.F gauge. Black face and Chrome bezel; red/white
graduations.
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for connection to light.
Fits Mercury/Mariner 25 thru 115 FourStroke, 225 FourStroke, 40 (3 & 4 cyl.), 45,
Black face and Chrome bezel; red graduations. Replacement gauge only.
50/60 (3 cyl.), and 70 to 125 hp ; and 1993 and newer Force outboards (Force
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
models must order sender FA299791) Senders must be ordered seperately
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
Quicksilver Branded, Box Point of Sale Packaged.
outboards require a reducer fitting p/n 22-86306.
Quicksilver Branded, Box Point of Sale Packaged.
US Quicksilver Product Guide
209
