YAMAHA OUTBOARD APPLICATION CHARTS
T25‑60 Horsepower ‑ Yamaha
T25 All Years
40 HP 1984 and Newer
F40 4‑Stroke 1999 and Newer
48 HP 1995‑2000
50 HP (Excluding T50) 1984 & Newer
F50 4‑Stroke 1999 and Newer
55 HP 1976‑95
60 HP 1976‑91
F60 4‑Stroke 2002 and Newer
13 Tooth Spline
Length (ft/m)
Current MPH/KPH
Propeller Size
Matl
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
House/Work
to 16 / to 26
12 1/2 X 8 RH
AL
3
Black Diamond
(1)
18+ / 5.5+
16-20 / 26-32
12 1/4 X 9 RH
AL
3
Black Diamond
663-45956-01-EL
(1)
17+ / 5.2+
20-23 / 32-37
11 1/4 X 10 RH
AL
3
Black Diamond
6H5-45952-00-EL
(1)
16-19 / 4.8-5.8
22-29 / 36-47
12 X 10 1/2 RH
AL
3
Black Diamond
(1)
16-18 / 4.8-5.5
23-30 / 37-48
10 7/8 X 11 RH
AL
3
Black Diamond
663-45947-02-EL
(1)
15-17 / 4.5-5.2
30-31 / 48-50
10 5/8 X 12 RH
AL
3
Black Diamond
6H5-45958-00-EL
(1)
14-17 / 4.2-5.2
31-35 / 50-56
10 3/8 X 13 RH
AL
3
Black Diamond
6H5-45943-00-EL
(1)
14-16 / 4.2-4.8
35-38 / 56-61
10 1/4 X 14 RH
AL
3
Black Diamond
663-45958-01-EL
(1)
13-15 / 3.9-4.5
38-42 / 61-68
10 1/8 X 15 RH
AL
3
Black Diamond
(1)
15-17 / 4.5-5.2
30-31 / 48-50
10.6 X 12 RH
AL
4
Nemesis
(1)
14-17 / 4.2-5.2
31-35 / 50-56
10.3X 13 RH
AL
4
Nemesis
(1)
14-16 / 4.2-4.8
35-38 / 56-61
10.1 X 14 RH
AL
4
Nemesis
(1)
13-15 / 3.9-4.5
38-42 / 61-68
10.1 X 15 RH
AL
4
Nemesis
(1)
to 14 / to 4.2
45-48 / 73-77
10 X 17 RH
AL
3
Black Diamond
663-45949-01-EL
(1)
15-17 / 4.5-5.2
30-31 / 48-50
11 X 12 RH
SS
3
Silverado
663-45970-60-98
(1)
14-17 / 4.2-5.2
31-35 / 50-56
10 1/2 X 13 RH
SS
3
Silverado
663-45974-60-98
(1)
14-16 / 4.2-4.8
35-38 / 56-61
10 3/8 X 14 RH
SS
3
Silverado
663-45930-00-98
(1)
13-15 / 3.9-4.5
38-42 / 61-68
10 1/4 X 15 RH
SS
3
Silverado
663-45976-00-98
(1)
(1) Flo-Torq Reflex Propeller - All required hardware included
T50‑130 Horsepower ‑ Yamaha
T50 HP 4‑Stroke 1996 and Newer
60 HP 1992 and Newer
T60 HP 4‑Stroke 2003 and Newer
70 HP 1984 and Newer
75 HP 1994‑2000
F75 4‑Stroke 2003 and Newer
80 HP 1977, 2000 and Newer
F80 HP 4‑Stroke 1999 and Newer
85 HP 1991‑97
90 HP 1984 and Newer
F90 HP 4‑Stroke 2003 and Newer
F100 HP 4‑Stroke 2000 and Newer
115 HP 1984 and Newer
F115 HP 4‑Stroke 2000 and Newer
130 HP 1984 and Newer
15 Tooth Spline
Length (ft/m)
Current MPH/KPH
Propeller Size
Matl
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
House/Work
to 14 / to 23
14 X 9 RH
AL
3
Black Diamond
(1)
Pontoon/Work
to 19 / to 31
14 X 10 RH
AL
3
Black Diamond
(1)
Pontoon
to 19 / to 31
14 X 10 RH
AL
3
Black Diamond
(1)(2)
23'+ / 7.0+
to 21 / to 34
14 X 11 RH
AL
3
Black Diamond
6E5-45954-00-EL
(1)
Pontoon
to 21 / to 34
14 X 11 RH
AL
3
Black Diamond
(1)(2)
20'+ / 6.1+
19-27 / 31-44
14 X 13 RH
AL
3
Black Diamond
6E5-45949-00-EL
(1)
Pontoon
19-27 / 31-44
14 X 13 RH
AL
3
Black Diamond
(1)(2)
18-20 / 5.5-6.1
25-32 / 40-52
13 3/4 X 15 RH
AL
3
Black Diamond
6E5-45947-00-EL
(1)
17-19 / 5.2-5.8
30-38 / 48-61
13 1/4 X 17 RH
AL
3
Black Diamond
6E5-45945-01-EL
(1)
US Quicksilver Product Guide
101
