QUICKSILVER GEARCASE LUBRICANT
HIGH PERFORMANCE GEAR LUBE CAPACITY
Brand
Model
Cycle
Model Description
Oz.
mL.
MerCruiser
Blackhawk
4 cycle
with Rectangular Gear
2.25 US
2.1L
CHART
lube Monitor
Quarts
This gear lube capacity chart is limited to recent models and has been
developed to aid in determining how much gearlube to have on hand
when servicing a particular gearhousing. Changing and servicing of
gearlube should always be performed in accordance with techniques
and procedures as outlined in the appropriate service or owner
manuals. The quantities shown here are to be regarded as reference
only. Any variation from the quantities shown may indicate an incorrect
model selection, the wrong service technique or a more serious
problem. Contact your local dealer prior to running if this should occur.
For outboards 75 hp and up and all sterndrives
Mercury or Quicksilver SAE 90 High Performance Gear Lube is recommended
Brand
Model
Cycle
Model Description
Oz.
mL.
Mercury/Mariner
75, 90
2 cycle
3 cylinder
22.5
665
Mercury/Mariner
100, 115, 125
2 cycle
4 cylinder
22.5
665
Mercury/Mariner
115
2 cycle
3 cylinder Optimax
22.5
665
Mercury/Mariner
135, 150
2 cycle
2.0L
22.5
665
Mercury/Mariner
150, 175, 200
2 cycle
2.5L Carb/EFI/Optimax
22.5
665
Mercury/Mariner
200, 225, 250
2 cycle
3.0L Carb/EFI/Optimax
27.0
798
Force
75
2 cycle
12.0
355
Force
90, 120
2 cycle
22.5
655
Mercury/Mariner
75-90
FourStroke S/N 1B366822 & below
22.5
665
Mercury/Mariner
75-90
FourStroke S/N 1B366823 & above
24.0
710
Mercury/Mariner
115
FourStroke
24.0
710
Mercury/Mariner
135/150/175
FourStroke Verado (RH rotation)
32.8
970
Mercury/Mariner
150 EFI
FourStroke RH rotation
26.4
780
Mercury/Mariner
200
FourStroke Verado (RH rotation)
32.8
970
Mercury/Mariner
225 EFI
FourStroke Standard gearcase
39.0
1.15L
Mercury/Mariner
225/250/275/300
FourStroke Verado (RH rotation)
32.8
970
MerCruiser
Alpha One Gen II
4 cycle
without Gear lube
1.22 US
1.16L
Monitor
Quarts
MerCruiser
Alpha One Gen II
4 cycle
with Round Gear lube
2.0 US
1.9L
Monitor
Quarts
MerCruiser
Alpha One Gen II
4 cycle
with Rectangular Gear
1.75 US
1.66L
lube Monitor
Quarts
MerCruiser
Bravo One
4 cycle
without Gear lube
2.0 US
1.9L
Monitor
Quarts
MerCruiser
Bravo One
4 cycle
with Round Gear lube
3.25 US
3.07L
Monitor
Quarts
MerCruiser
Bravo One
4 cycle
with Rectangular Gear
2.75 US
2.6L
lube Monitor
Quarts
MerCruiser
Bravo Two
4 cycle
without Gear lube
2.5 US
2.4L
Monitor
Quarts
MerCruiser
Bravo Two
4 cycle
with Round Gear lube
3.75 US
3.55L
Monitor
Quarts
MerCruiser
Bravo Two
4 cycle
with Rectangular Gear
3.25 US
3.07L
lube Monitor
Quarts
MerCruiser
Bravo Three
4 cycle
without Gear lube
2.0 US
1.9L
Monitor
Quarts
MerCruiser
Bravo Three
4 cycle
with Rectangular Gear
3.0 US
2.84L
lube Monitor
Quarts
MerCruiser
Blackhawk
4 cycle
without Gear lube
1.75 US
1.66L
Monitor
Quarts
52
