Application Charts (90 HP - 150 HP)

CSS Drop Down Menu by PureCSSMenu.com < Previous Page|Next Page >
Mercury, Mariner Application Charts
HP Model Cyl. Year Serial Number Switch Box Stator Trigger Rec./Reg. Harness
90 SportJet 3 93-95 0E021000-0E095087 114-4953 174-8778K 1 134-7029-3 194-5279 414-6075
90 SportJet 3 95-96 0E080400-0E145579 114-4953 174-8778K 1 134-7029-3 194-5279 414-6075
95 950 Inline 6 66-67 1869776-2101742 114-2803 R398-2188* POINTS - 414-2770
95 950 6 66-67 2101743-2318585 114-2986 R398-2188* 134-3736 154-6770 414-2770
95 XRSprtJet 3 95-97 0E141089-0E315900 114-4953 174-9710K 1 134-7029-3 194-5279 R84-828297A 2*
100 1000 Inline 6 67-69 2641855-3253111 114-2986 R398-3633* 393-2918A1* 154-6770 414-2770
100 - 4 88-93 0B209468-0D283221 114-5772 174-8778K 1 134-9021-4 194-5279 414-3443
100 9 Amp 4 94-96 0D283222-0G437999 114-5772 174-8778K 1 134-9021-4 194-5279 414-3443
100 16 Amp 4 94-96 0D283222-0G437999 114-5772 174-9710K 1 134-9021-4 194-5279 414-3443
100 - 4 96-00 0G438000-0G965520 114-7509 174-2075K 2 134-4513-4 194-5279 414-0043
105 Jet 6 92-95 0D082000-0G201874 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
105 Jet 6 96-00 0G303046-0G760500 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
110 1100 Inline 6 66-67 1962462-2103722 114-2803 R398-2188* POINTS R32177A1* R29999*
110 1101 Inline 6 67 2113898-2314955 114-2986 R398-2188* 134-3736 154-6770 R29999*
115 150 SS Inline 6 70-79 2836019-5314655 114-2986 174-4793 134-3736 154-6770 414-2770
115 Inline 6 79-80 5314656-5600966 114-7778 174-5456 134-6456 154-6770 414-5532
115 Inline 6 80-82 5600967-6051525 114-7778 174-5456 134-6456 154-6770 414-9564
115 Inline 6 82-89 6051526-0C10000 114-7778 174-5456 134-6456 154-6770 R84-96188A 2*
115 9 Amp 4 89-93 0C100000-0D252460 114-5772 174-8778K 1 134-9021-4 194-5279 414-3443
115 16 Amp 4 89-97 0C100000-0G437999 114-5772 174-9710K 1 134-9021-4 194-5279 414-3443
115 - 4 96-06 0G438000-1B000001 114-7509 174-2075K 2 134-4513-4 194-5279 414-0043
120 SportJet 4 95 0E070304-0E141088 114-6866 174-9710K 1 134-7029-4 194-5279 414-6075
120 XRSportJet 4 95-00 0E141089-0E379999 114-7509 174-2075K 2 134-8303-4 194-5279 R84-828297A 2*
125 1250 Inline 6 68-69 2314956-3253111 114-2986 R398-3587* R393-2918 154-6770 414-2770
125 9 Amp 4 94-96 0D283222-0G437999 114-5772 174-8778K 1 134-9021-4 194-5279 414-3443
125 16 Amp 4 94-96 0D283222-0G437999 114-5772 174-9710K 1 134-9021-4 194-5279 414-3443
125 - 4 96-06 0G438000-1B000001 114-7509 174-2075K 2 134-4513-4 194-5279 414-0043
135 1350 Inline 6 70-71 2839369-3293233 114-2986 174-4793 134-3736 154-6770 414-2770
135 - 6 85-88 0A904646-0C100860 114-7778 174-5456-16 134-6456 154-8825K 1 414-6220A 4
135 - 6 89-90 0C100861-0C239552 114-7778 174-9610K 2 134-6456 194-1873(f) 414-6220A12
135 16 Amp 6 90-91 0C239553-0D081999 114-7778 174-5456-16 134-6456 154-8825K 1 414-6220A 4
135 40 Amp 6 90-91 0C239553-0D081999 114-7778 174-9610K 2 134-6456 194-1873(f) 414-6220A12
135 41 Amp 6 92-95 0D082000-0G201874 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
135 42 Amp 6 96-99 0G303046-0G960499 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
135 - 6 00-05 0G960500-UP 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-857166T 1*
140 1400 Inline 6 72 3293234-3502805 114-2986 174-4793 134-3736 154-6770 414-2770
140 Inline 6 78-79 4855153-5314655 114-2986 174-4793 134-3736 154-6770 414-2770
140 Inline 6 79 5327663-5625107 114-7778 174-5456-16 134-6456 193-5114 414-5532
140 - 6 80-81 5625108-5669999 114-7778 174-5456 134-6456 154-6770 414-9564
140 Jet 6 92-95 0D082000-0G201874 114-7778 174-9610K 2 134-6456 194-5279 414-6220A16
140 Jet 6 96-99 0G303046-0G960499 114-7778 174-9610K 2 134-6456 194-5279 R84-826730A 4*
140 Jet 6 00-05 0G960500-UP 114-7509 R398-858404T* 134-6456-18 194-2115K 1 R84-857166T 1*
150 1500 Inline 6 73-77 3502806-4868997 114-2986 174-4793 134-3736 154-6770 414-2770
150 XR2 Mag 6 78-86 04868998-0A904645 114-7778 174-5456 134-6456 154-6770 414-6220A 4
150 - 6 85-88 0A904646-0C100860 114-7778 174-5456-16 134-6456 154-8825K 1 (g) 414-6220A 4
150 - 6 89-90 0C100861-0C239552 114-7778 174-9610K 2 134-6456 194-1873 (f) 414-6220A12
*Premier Services Availability Only **Part Currently Unavailable by CDI Electronics at this time (a) Use 994-4463 (b) Auxillary Charging Stator is Premier Services Only (c) If Linkage 90 Deg., Order
134-6454 (d) If Linkage Straight, Order 134-6452 (e) Order 114-2986K 1 if original had 337-4406 (f) Order 194-1873 if Stator has 2 Yellow Wires (g) Replaces both Rectifi er & Regulator
TECH SUPPORT: 1.866.423.4832 CALL TO ORDER: 1.800.209.9624
117
