Mercury, Mariner Application Charts
HP Model Cyl. Year Serial Number Switch Box Stator Trigger Rec./Reg. Harness
60 - 3 91-97 D000750-OG589999 114-9052 174-9710K 1 134-9021-3 194-5279 414-9061
60 - 3 97-00 OG531301-OG833000 114-7509 174-2075K 1 - 194-5279 414-0220
60 Elec Str. 3 98-07 0G590000-OT980000 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
60 Elec Str. 4 Stk 4 02-05 0T178500-0T598999 **878433A 3 174-2387 - 194-2115K 1 R84-857111T 2*
60 EFI 4 Stk 4 2005 0T409000-0T800999 - R398-878143T 3* - 194-2115K 1 R84-877804T 3*
60 EFI 4 Stk 4 2006 0T801000-1B344306 - R398-878143T05* - 194-2115K 1 -
60 EFI 4 Stk 4 06-07 1B344306-1C050252 - R398-878143T05* - 194-2115K 1 -
65 650 4 67 2119749-2309310 114-2986 R398-2997* R393-2918A1* 154-6770 414-2770
65 650 4 68 2309311-2505592 R333-3213* 174-3175 (Red)
174-3176 (Blue)
IGN DRIVER 154-6770 414-2770
65 - 4 69-71 2503993-3293183 114-2986 174-4793 R393-2918A1* 154-6770 414-2770
65 - 3 72-75 3293184-4382056 114-4796 R398-4634* R332-4797 154-6770 R84-60795*
65 - 3 76 4382057-4571651 114-7778 174-5454K 1 134-6453 154-6770 R84-73204*
65 Jet Elec Str. 3 94-96 D283222-OG760299 114-4953 174-9710K 1 134-9021-3 194-5279 414-1591
65 Jet Man Str. 94-96 0D283222-OG437999 114-4953 R398-9873A33* 134-9021-3 - -
65 Jet 3 96-06 0G760300-1B000001 114-7509 174-2075K 2 134-4512-3 194-5279 414-0043
70 - 3 77-85 4571652-A730815 114-7778 174-5454K 1 134-6453 154-6770 R84-73204*
70 9 Amp 3 87-89 0A996142-0D283221 114-7778 174-8778K 1 134-9021-3 154-6770 414-1591
70 16 Amp 3 87-89 0A996142-0D283222 114-7778 174-9710K 1 134-9021-3 194-5279 414-1591
75 - 4 84-86 6432901-0C221499 114-5772 174-5454K 1 134-6454(d) 154-6770 414-6233A 2
75 9 Amp 3 87-93 0C221500-0D283221 114-7778 174-8778K 1 134-9021-3 154-6770 414-1591
75 16 Amp 3 87-93 0A996142-0D283221 114-7778 174-9710K 1 134-9021-3 194-5279 414-1591
75 Elec Str. 3 94-96 0D283222-0G437999 114-4953 174-9710K 1 134-9021-3 194-5279 414-1591
75 Man.Str. 3 94-96 0D283222-0G437999 114-4953 R398-9873A33* 134-9021-3 - -
75 2 Stk. 3 96-06 0G438000-1B000001 114-7509 174-2075K 2 134-4512-3 194-5279 414-0043
80 800 4 69 2559001-2991033 114-2986 174-4793 134-3736 154-6770 414-2770
80 800 4 70 3051041-3052380 114-2986K1 174-4793 134-3736 154-6770 414-2770
80 800 4 70 3052381-3059820 114-2986 174-4793 134-3736 154-6770 414-2770
80 800 4 71 3144219-3192962 114-2986K1 174-4793 134-3736 € 154-6770 414-2770
80 800 4 71-72 3307347-3493912 114-2986 174-4793 134-3736 154-6770 414-2770
80 - 4 78-79 4831999-5582561 114-5772 174-5454K 1 134-6452(c) 154-6770 414-3369
80 - 4 80-83 5582562-6432900 114-5772 174-5454K 1 134-6454 154-6770 414-6233A 2
80 9 Amp 3 87-93 0A996142-0D283221 114-7778 174-8778K 1 134-9021-3 154-6770 414-1591
80 16 Amp 3 87-93 0A996142-0D283221 114-7778 174-9710K 1 134-9021-3 154-6770 414-1591
80 Jet 4 94-96 0D283222-0G437999 114-5772 174-9710K 1 134-9021-4 194-5279 414-0043
80 Jet 4 96-06 0G438000-1B000001 114-7509 174-2075K 2 134-4513-4 194-5279 414-0043
85 850 4 73-75 3493913-4366801 114-2986 174-4793 134-3736 154-6770 414-2770
85 850 4 76-77 4366802-4831998 114-5772 174-5454K 1 134-6452(c) 154-6770 414--3369
90 Inline 6 78-79 4836522-5299505 114-2986 174-4793 134-3736 154-6770 414-2770
90 Inline 6 79 5299506-5595646 114-7778 174-5456 134-6456 154-6770 414-5532
90 Inline 6 79-81 5594657-6026608 114-7778 174-5456 134-6456 154-6770 414-9564
90 Inline 6 82-86 6026609-0B110053 114-7778 174-5456 134-6456 154-6770 R84-96188A 4*
90 Elec Str. 3 87-92 0A996142-0C221999 114-7778 174-8778K 1 134-9021-3 154-6770 414-1591
90 Elec Str. 3 92-94 0C222000-0D283221 114-7778 174-9710K 1 134-9021-3 194-5279 414-1591
90 Elec Str. 3 94-96 0D283222-0G437999 114-4953 174-9710K 1 134-9021-3 194-5279 414-1591
90 Man.Str. 3 94-96 0D283222-0G437999 114-4953 R398-9873A33* 134-9021-3 - -
90 Elec Str. 3 96-06 0G438000-1B000299 114-7509 174-2075K 2 134-4512-3 194-5279 414-0043
*Premier Services Availability Only **Part Currently Unavailable by CDI Electronics at this time (a) Use 994-4463 (b) Auxillary Charging Stator is Premier Services Only (c) If Linkage 90 Deg., Order 134-6454
(d) If Linkage Straight, Order 134-6452 (e) Order 114-2986K 1 if original had 337-4406 (f) Order 194-1873 if Stator has 2 Yellow Wires (g) Replaces both Rectifier & Regulator
