Sierra Marine Parts Catalog
OIL FILter QuIck-reFerence GuIde
Volvo Gasoline
- Continued
Model
Cylinders
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
AQ131 A/B/C/D
4
1985 - 1989
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ140A
4
1975 - 1979
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ145 A/B
4
1979 - 1985
3517857
4.2L / 4.5 Qt.
10W-40 FC-W
AQ151 A/B/C
4
1985 - 1989
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ170 A/B/C
4
1969 - 1980
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ171 A/C
4
1986 - 1989
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ60F
4
1962 - 1968
3517857
Check Owners Manual
10W-40 FC-W
AQ90
4
1962 - 1964
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ95 /A
4
1964 - 1966
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
BB100
4
1963 - 1969
3517857
Check Owners Manual
10W-40 FC-W
BB115 A/B/C
4
1969 - 1977
3517857
Check Owners Manual
10W-40 FC-W
BB140A
4
1975 - 1979
3517857
Check Owners Manual
10W-40 FC-W
BB145A
4
1979 - 1985
3517857
Check Owners Manual
10W-40 FC-W
BB165A
4
1965 - 1969
3517857
Check Owners Manual
10W-40 FC-W
BB170 A/B/C
4
1969 - 1978
3517857
Check Owners Manual
10W-40 FC-W
BB30
4
1963 - 1969
3517857
Check Owners Manual
10W-40 FC-W
4
1971 - 1977
3517857
Check Owners Manual
10W-40 FC-W
MB10A
MB20 A/B/C
4
1969 - 1980
3517857
Check Owners Manual
10W-40 FC-W
4.3L
V6
1993 - 2006
841750
4.2L / 4.5 Qt.
Synthetic SAE 30 (1)
4.3L
V6
2007 - Current
8692305
4.7L / 5.0 Qt.
Synthetic SAE 30 (1)
430 A/B
V6
1990 - 1992
841750
4.2L / 4.5 Qt.
10W-40 FC-W
431 A/B
V6
1989 - 1992
841750
4.2L / 4.5 Qt.
10W-40 FC-W
432A/B
V6
1992 - 1998
841750
4.2L / 4.5 Qt.
10W-40 FC-W
434A/B
V6
1992 - 1997
841750
4.2L / 4.5 Qt.
10W-40 FC-W
AQ175A
V6
1981 - 1985
841750
6.0L / 6.5 Qt
10W-40 FC-W
AQ205A
V6
1988 - 1989
841750
6.0L / 6.5 Qt
10W-40 FC-W
5.0L (Ford)
V8
1993 - 1999
835779
5.7L / 6.0 Qt.
Synthetic SAE 30 (1)
5.0L (GM)
V8
1997 - 2006
835440
5.7L / 6.0 Qt.
Synthetic SAE 30 (1)
5.0L (GM)
V8
2007 - Current
8692305
5.2L / 5.5 Qt.
Synthetic SAE 30 (1)
5.7L
V8
1993 - 2006
835440
5.7L / 6.0 Qt.
Synthetic SAE 30 (1)
5.7L
V8
2007 - Current
8692305
5.2L / 5.5 Qt.
Synthetic SAE 30 (1)
5.8L
V8
1993 - 1996
835779
5.7L / 6.0 Qt.
Synthetic SAE 30 (1)
500 A/B
V8
1989 - 1993
835440
5.7L / 6.0 Qt.
10W-40 FC-W
501 A/B
V8
1989 - 1993
835440
5.7L / 6.0 Qt.
10W-40 FC-W
570 A/MS4A
V8
1989 - 1993
835440
5.7L / 6.0 Qt.
10W-40 FC-W
571A
V8
1989 - 1992
835440
5.7L / 6.0 Qt.
10W-40 FC-W
572A
V8
1991 - 1993
835440
5.7L / 6.0 Qt.
10W-40 FC-W
7.4L
V8
1993 - 2000
3850559
6.6L / 7.0 Qt.
Synthetic SAE 30 (1)
740 A/B
V8
1992 - 1993
3850559
6.6L / 7.0 Qt.
10W-40 FC-W
8.1L
V8
1999 - 2006
835440
8.0L / 8.5 Qt.
Synthetic SAE 30 (1)
8.1L
V8
2007 - Current
8692305
8.0L / 8.5 Qt.
Synthetic SAE 30 (1)
8.2L
V8
1993 - 2000
3850559
6.6L / 7.0 Qt.
Synthetic SAE 30 (1)
AQ190A
V8
1976 - 1977
835779
4.0L / 4.2 Qt.
10W-40 FC-W
AQ211A
V8
1986 - 1989
835440
4.0L / 4.2 Qt.
10W-40 FC-W
AQ225 B/C/D/E/F
V8
1973 - 1976
835440
4.4L / 4.7 Qt.
10W-40 FC-W
AQ231A
V8
1986 - 1989
835440
4.4L / 4.7 Qt.
10W-40 FC-W
AQ231B
V8
1987 - 1989
835440
4.4L / 4.7 Qt.
10W-40 FC-W
AQ240A
V8
1976 - 1977
835779
4.4L / 4.7 Qt.
10W-40 FC-W
AQ255 A/B
V8
1977 - 1978
835440
5.7L / 6.0 Qt.
10W-40 FC-W
AQ260 A/B
V8
1979 - 1986
835440
5.7L / 6.0 Qt.
10W-40 FC-W
AQ271 A/B/C/D
V8
1986 - 1989
835440
5.4L / 5.7 Qt.
10W-40 FC-W
AQ280A
V8
1978 - 1979
835440
5.4L / 5.7 Qt.
10W-40 FC-W
AQ290A
V8
1979 - 1985
835440
5.4L / 5.7 Qt.
10W-40 FC-W
AQ311 A/B
V8
1986 - 1987
835440
5.4L / 5.7 Qt.
10W-40 FC-W
BB225 A/B/C
V8
1973 - 1977
835440
4.4L / 4.7 Qt.
10W-40 FC-W
All listed oil capacities are approximate amounts only and may or may not include the oil filter capacity.
996
ALWAYS follow proper crankcase drain and fill procedures. Check engine dipstick for proper crankcase oil level.
