Sierra Marine Parts Catalog
OIL FILter QuIck-reFerence GuIde
PCM Pleasurecraft
Model
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
200
R077001
Refer to Owners Manual
Refer to Owners Manual
220
R077001
Refer to Owners Manual
Refer to Owners Manual
8200
R077001
Refer to Owners Manual
Refer to Owners Manual
8240
R077001
Refer to Owners Manual
Refer to Owners Manual
230
R077002
Refer to Owners Manual
Refer to Owners Manual
280
R077002
Refer to Owners Manual
Refer to Owners Manual
300
R077002
Refer to Owners Manual
Refer to Owners Manual
350
R077002
Refer to Owners Manual
Refer to Owners Manual
5.0L MPI (Remote Oil Filter)
2007 & Older
R077001
3.8L / 4.0 Qt.
15W-40 API SL or Higher
5.7L MPI (Remote Oil Filter)
2007 & Older
R077001
3.8L / 4.0 Qt.
15W-40 API SL or Higher
6.0L MPI (Remote Oil Filter)
2007 & Older
R077001
4.75L / 5.0 Qt.
15W-40 API SL or Higher
5.0L MPI (Serial 473065 & UP) (Remote Oil Filter)
2007 - 2009
R077001
3.8L / 4.0 Qt.
15W-40 API SL or Higher
EX 343 (Serial 473065 & UP) (Remote Oil Filter)
2007 - 2012
R077001
3.8L / 4.0 Qt.
15W-40 API SL or Higher
ZR6 390 (Serial 470365 & UP) (Remote Oil Filter)
2007
R077001
4.75L / 5.0 Qt.
15W-40 API SL or Higher
5.0L Pro Sport CataniumTM CES (Remote Oil Filter)
2008 - 2010
R077001
4.5L / 4.75 Qt.
15W-40 API SM or Higher
5.7L EX343 CataniumTM CES (Remote Oil Filter)
2008 - 2012
R077001
4.5L / 4.75 Qt.
15W-40 API SM or Higher
2009 - 2012
R077001
4.75L / 5.0 Qt.
15W-40 API SM or Higher
6.0L ZR-409 CataniumTM CES ( Remote Oil Filter)
6.0L MPI - ZR409 (Remote Oil Filter)
2009 - 2012
R077001
4.75L / 5.0 Qt.
15W-40 API SM or Higher
HO303 MPI
2011 - 2012
R077001
3.8L / 4.0 Qt. (Starting Amount)
15W-40 API SM or Higher
HO303 CataniumTM CES
2011 - 2012
R077001
3.8L / 4.0 Qt. (Starting Amount)
15W-40 API SM or Higher
ZR450 CataniumTM CES
2011 - 2012
R077001
3.8L / 4.0 Qt. (Starting Amount)
15W-40 API SM or Higher
ZR550 6.2L MPI
2011 - 2012
R077001
3.8L / 4.0 Qt. (Starting Amount)
5W-30 Full Synthetic
Suzuki
Model
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
DF9.9-DF15 (9.9 hp. serial 110001 and below)
1996 - 2010
16510-05240
16510-45H10
1.0 L / 1.1 Qt.
10W-40 Synthetic Blend FC-W
DF25
2000 - 2006
16510-87J00
3.0 L / 3.2 Qt.
10W-40 Synthetic Blend FC-W
DF25 V-Twin
2006 - 2010
16510-87J00
1.5L / 1.6 Qt.
10W-40 Synthetic Blend FC-W
DF30
2000 - 2007
16510-87J00
3.0 L / 3.2 Qt.
10W-40 Synthetic Blend FC-W
DF40-DF50
1999 - 2010
16510-87J00
2.2 L / 2.3 Qt.
10W-40 Synthetic Blend FC-W
DF60-DF70
1998 - 2009
16510-87J00
4.5 L / 4.8 Qt.
10W-40 Synthetic Blend FC-W
DF60A
2010
16510-87J00
2.7 L / 3.0 Qt.
10W-40 Synthetic Blend FC-W
DF70A
2009 - 2010
16510-61A20-MHL
4.2 L / 4.0 Qt.
10W-40 Synthetic Blend FC-W
DF80A
2009 - 2010
16510-61A20-MHL
4.2 L / 4.0 Qt.
10W-40 Synthetic Blend FC-W
DF90A
2009 - 2010
16510-61A20-MHL
4.2 L / 4.0 Qt.
10W-40 Synthetic Blend FC-W
DF90
2001 - 2008
16510-61A20-MHL
5.5 L / 5.8 Qt.
10W-40 Synthetic Blend FC-W
DF115
2001 - 2010
16510-61A20-MHL
5.5 L / 5.8 Qt.
10W-40 Synthetic Blend FC-W
DF140
2002 - 2010
16510-82703
5.5 L / 5.8 Qt.
10W-40 Synthetic Blend FC-W
DF150-DF175
2006 - 2010
16510-96J00
8.0 L / 8.5 Qt.
10W-40 Synthetic Blend FC-W
DF200 / DF225 / DF250
2004 - 2010
16510-96J00
8.0 L / 8.5 Qt.
10W-40 Synthetic Blend FC-W
DF300
2007 - 2010
16510-96J00
8.0 L / 8.5 Qt.
10W-40 Synthetic Blend FC-W
Volvo Gasoline
Model
Cylinders
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
230 A/B
4
1989 - 1993
3517857
4.5L / 4.75 Qt.
10W-40 FC-W
250 A/B
4
1989 - 1993
3517857
4.5L / 4.75 Qt.
10W-40 FC-W
251A
4
1989 - 1992
3517857
4.5L / 4.75 Qt.
10W-40 FC-W
3.0L
4
1993 - Current
835440
3.8L / 4.0 Qt.
Synthetic SAE 30 (1)
AQ100
4
1961 - 1963
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ110
4
1963 - 1966
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ115 A/B
4
1969 - 1975
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ120 A/B
4
1966 - 1980
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
AQ125 A/B
4
1981 - 1985
3517857
4.2L / 4.5 Qt.
10W-40 FC-W
AQ130 A/B/C/D
4
1968 - 1977
3517857
3.8L / 4.0 Qt.
10W-40 FC-W
Continued Next Page
All listed oil capacities are approximate amounts only and may or may not include the oil filter capacity.
995
ALWAYS follow proper crankcase drain and fill procedures. Check engine dipstick for proper crankcase oil level.
