Sierra Marine Parts Catalog
Brass Bus Bars
* Use as common hot feed or common ground block
* Brass terminal bar
**FS40750
**FS40760
*FS40752
**FS40720
*FS40762
� 10 - 10-32 Screw Terminals
*FS40722
� 20 10-32 Screw Terminals
� 2 - 1/4"-20 Stud Terminals
� 4 - 8-32 Screw Terminals
� 2 1/4"-20 Stud Terminals
Overall size - 5.75"L x 1.25 W x 1.19"H
Overall size - 4.5"L x .5" W x 1"H
Overall size - 8.81L x 1.24W x 1.19"H
Dual Brass Bus Bars
* Combines negative and positive buses in one block
* Brass terminal bar
**FS40690
**FS40660
**FS40670
**FS40680
*FS40692
*FS40662
*FS40672
*FS40682
� 16 - 8-32 Screw Terminals
� 4 - 8-32 Screw Terminals
� 8 - 8-32 Screw Terminals
� 12 - 8-32 Screw Terminals
Overall size -
Overall size -
Overall size -
Overall size -
6"L x 1.5"W x .44"H
1.5"L x 1.5"W x .44"H
3"L x 1.5"W x .44"H
4.5"L x 1.5"W x .44"H
Barrier Type Junction Blocks
� Each screw pair is 1 isolated circuit
� Closed back insulates power from mounting circuit
� Nickel plated brass bus bar
**FS45630
**FS45620
*FS45632
*FS45622
� 6 Gang Block
� 4 Gang Block
� 12 - 10-32 Screw Terminals
� 8 - 10-32 Screw Terminals
Overall size - 4.36"L x 1.312"W x 0.812"H
Overall size - 3.94"L x 1.312"W x 0.812"H
**FS45640
**FS45650
*FS45642
*FS45652
� 8 Gang Block
� 10 Gang Block
� 16 10-32 Screw Terminals
� 20 10-32 Screw Terminals
Overall size - 5.33"L x 1.312"W x 0.812"H
Overall size - 6.31"L x 1.312"W x 0.812"H
ATO/ATC Style Fuse Holders
**FS35870
**FS69130
*FS35872
*N-186913
**FS45410
FUSE HOLDER
FUSE HOLDER
*FS45412
� Weather proof sealed case
� 5" - 12 gauge wire leads
FUSE HOLDER
� 5" - 12 gauge wire leads
� For ATO/ATC style fuses up to 30 amps
� 8" - 14 gauge wire loop
� For ATO/ATC style fuses up to 30 amps
� Includes 30 amp fuse
� For ATO/ATC style fuses up to 20 amps
50
*BULK - 100 pcs. per carton
**CLAMSHELL
