Sierra Marine Parts Catalog
Corrosion Resistant Common Bus Bars
� Use as common hot feed or common ground block
� Tin plated copper bus
� Stainless steel studs & screws
� Large diameter nuts provide large electrical contact area
� Stainless steel screws with lock washers
150 Amp Common Bus
**FS46100
*FS46102
**FS46150
*FS46152
� 5 - 8-32 Screw Terminals
� 4 - 10-24 Stud Terminals
� 2 - 10-24 Stud Terminals
Over all size - 4.13"Lx.75"Wx1.44"H
Over all size - 4.13"Lx.75"Wx1.44"H
**FS46200
*FS46202
**FS46250
� 10 - 8-32 Screw Terminals
*FS46252
� 2 - 1/4"-20 Stud Terminals
� 4 - 1/4"-20 Stud Terminals
Over all size - 6"Lx1.25"Wx1.44"H
Over all size - 6"Lx1.25"Wx1.44"H
**FS46400
*FS46402
**FS46450
*FS46452
� 20 - 8-32 Screw Terminals
� 6 - 1/4"-20 Stud Terminals
� 2 - 1/4"-20 Stud Terminals
Over all size - 9 1/4"Lx1.25Wx1.44"H
Over all size - 9 1/4"Lx1.25Wx1.44"H
250 Amp Common Bus
**FS46300
*FS46302
**FS46350
*FS46352
� 12 - 8-32 Screw Terminals
� 4 - 1/4"-20 Stud Terminals
� 2 - 1/4"-20 Stud Terminals
Over all size - 7.88"Lx1.5"Wx1.75"H
Over all size - 7.88"Lx1.5"Wx1.75"H
600 Amp Common Bus
� 8 X 3/8-16 stud terminals
� 4 X 3/8-16 stud terminals
Over all size - 11.375L X 2"W X 2"H
Over all size - 7.00"L X 2"W X 2"H
Bus Bar Insulating Covers
� ABS cover designed to prevent accidental shorting
Fits FS46561
Fits FS46551
49
*BULK - 100 pcs. per carton
**CLAMSHELL
