arCtIC -- Stylish white bezel design, black on white graphics, accurate and reliable, these tough
instruments look good on all types of boats. Domed glass sheds water and resists scratching.
Features:
Instruments available for most outboards,
stern drives and gasoline-powered inboards.
Scratch-resistant domed glass lenses.
Enhanched illumination:
through-dial and periemeter lighting for
excellent readability at night.
Low-range speedometers.
U.S. and metric scales, with ISO symbols, where
appropriate.
Optional add-on square bezels for modular
appearance (See Gauge Accessories for details).
seLeCtION GuIDe:
GAUGE DESCRIPTION
SIZE
DIAL RANGE
SENDER CODE
PART NUMBER
Ammeter
2"
60-0-60
REQUIRES "F"
Fuel Gauge
2'
(E-F)
NONE REQ'D
Hourmeter
2'
10,000 hrs
Eng Oil Pressure gauge 0-80 PSI
2"
0-80 PSI
REQUIRES "C"
Water Pressure Kits (Outboard):
2"
0-40 PSI
INCLUDES "WP"
(Each kit includes fittings and
20 feet of tubing).
GPS Speedometer:
35 MPH
3"
0-35 MPH
GPS RECEIVER
60 MPH
3"
0-60 MPH
80 MPH
3"
0-80 MPH
Speedo Kit 0-35 mph (inc Pitot and Hose)
3"
5-35 MPH
INCLUDES "G"
Speedo Kit 0-65 mph (inc Pitot and Hose)
3"
10-65 MPH
INCLUDES "G"
Speedo Kit 0-80 mph (inc Pitot and Hose)
3'
20-80 MPH
INCLUDES "G"
Tachometer 0-4000 RPM Diesel Alt
3"
0-4000 RPM
ALTERNATOR
Tachometer 0-7000 RPM
3"
0-7000 RPM
O/B ALT./COIL
Tach/Hourmeter 0-7000 RPM Petrol/Gas
3"
0-7000 RPM
O/B ALT./COIL
I/O, I/B Water Temp Gauge
2"
120-240�F
REQUIRES "D"
Outboard Water Temp Kit (Cold-Hot)
2"
100-220�F
INCLUDES "J"
Trim, Evinrude/Johnson O/B
2"
UP-DOWN
BY ENG. MFR.
Trim, Honda
2"
UP-DOWN
BY ENG. MFR.
Trim, Mariner/Merc, Yamaha 2001
2"
UP-DOWN
BY ENG. MFR.
Trim, Yamaha Outboards, pre 2001
2"
UP-DOWN
BY ENG. MFR.
12v Voltmeter, 8-18 Volts
2"
8-18 VDC
NONE REQ'D
12 Battery Condition Indicator
2"
NONE REQ'D
System Check - Evinrude/Johnson
2"
BY ENG. MFR.
System Check - Suzuki
2"
BY ENG. MFR.
Instrument Set "OUTBOARD"
4 Gauge set
Instrument Set "INBOARD/STERNDRIVE"
6 Gauge set
Instrument Set OB w/Tach/Hr
4 Gauge Set
Instrument Set IB/IO w/Tach/Hr
6 Gauge set
Twin Engine Add On IB/IO Gauge Kit
4 Gauge Set
Twin Engine Add On OB Gauge Kit
2 Gauge set
15
All gauge products are only available in North America!
