aMeGa -- Hottest selling black dial line! Amega� Domed has clean-looking black dials with white and
red graphics plus through-dial and perimeter lighting for great readability. Amega has been very popular,
available in several styles since its debut in 1986.
Features:
Black dial, red graduations, white numerals, vivid
white pointer staff.
Scratch resistant curved glass lenses, with black,
near-flush bezels.
U.S. and metric scales, with ISO symbols, where
appropriate.
Perimeter and thru-dial lighting.
A comprehensive array of outboard water pressure
instrument kits.
Optional add-on square bezels for modular
appearance (See Gauge Accessories for details).
seLeCtION GuIDe:
GAUGE DESCRIPTION
SIZE
DIAL RANGE
SENDER CODE
PART NUMBER
Fuel Gauge:
2"
E-1/2-F
REQUIRES "F"
Hourmeter:
2"
10,000 Hrs.
NONE REQ'D
Oil Pressure Gauges (Electric):
Oil Pressure 80 PSI
2"
0-80 PSI
REQUIRES "C"
Oil Pressure 100 PSI
2"
0-100 PSI
REQUIRES "C"
GPS Speedometer:
35 MPH
3"
0-35 MPH
GPS RECEIVER
b
60 MPH
3"
0-60 MPH
80 MPH
3"
0-80 MPH
Speedometer Kits:
35 MPH (Pitot type)
3"
5-35 MPH
INCLUDES "G"
35 MPH (Pitot type) Head Only
3"
5-35 MPH
50 MPH (Pitot type)
3"
10-50 MPH
INCLUDES "G"
50 MPH (Pitot type) Head Only
3"
10-50 MPH
65 MPH (Pitot type)
3"
10-65 MPH
INCLUDES "G"
65 MPH (Pitot type) Head Only
3"
10-65 MPH
80 MPH (Pitot type)
3"
20-80 MPH
INCLUDES "G"
80 MPH (Pitot type) Head Only
3"
20-80 MPH
Systems Check � Evinrude/Johnson:
2"
SYSTEM DATA
BY ENG. MFR.
Tachometer (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-7000
RPM
O/B ALT./COIL
Systems Check � Evinrude/Johnson
3"
0-7000
RPM
O/B ALT./COIL
Diesel Alt
3"
0-4000
RPM
ALTERNATOR
Force
3"
0-7000
RPM
Tachometer/Hourmeter (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-6000 RPM
O/B ALT./COIL
Tach/Hourmeter
3"
0-7000
Trim Gauges (Outboard, I/O):
Evinrude/Johnson Outboard
2"
UP-DOWN
BY ENG. MFR.
Honda
2"
UP-DOWN
BY ENG. MFR.
Mariner/Merc/Cobra/Volvo DP, SX,
Yamaha 2001 and on
2"
UP-DOWN
BY ENG. MFR.
Yamaha PRE 2001
2"
UP-DOWN
BY ENG. MFR.
Suzuki 4-Stroke, 2002 to date
2"
UP-DOWN
BY ENG. MFR.
Voltmeter-12 Volt:
2"
8-18 VDC
NONE REQ'D
Warning Light Gauge � Suzuki:
2"
SYSTEM DATA
BY ENG. MFR.
Water Pressure Kits (Outboard):**
2"
40 PSI
INCLUDES "WP"
(Each kit includes fittings
2"
30 PSI
INCLUDES "WP"
and 20 feet of tubing)
Water Temp. Kit (Outboard):**
(For all electric-start outboards)
2"
100-220�F
INCLUDES "J"
Water Temp. Gauge (I/O, I/B):
2"
120-240�F
REQUIRES "D"
Ammeter, Amega 60-0-60
2"
Battery Condition Indicator, 12 VDC
NONE REQ'D
Instrument Set "OUTBOARD"
4 Gauge set
Instrument Set "INBOARD/STERNDRIVE"
6 Gauge set
Twin Engine Add On IB/IO Gauge Kit
4 Gauge Set
Twin Engine Add On OB Gauge Kit
2 Gauge set
Instrument Set OB w/Tach/Hr
4 Gauge Set
Instrument Set IB/IO w/Tach/Hr
6 Gauge set
Mariner 30 & 40 HP (2-cylinder) engines require a module (Mercury P/N 17461A2) when using any of these tachometers.
Not tested for non-original-equipment (aftermarket) ignition systems. Not for diesels.
** Adapter (P/N 61886P) is required for Yamaha.
14
All gauge products are only available in North America!
