LIDO PrO -- Hottest selling white dial line! A comprehensive family of instruments for most engine types,
Lido features crisp white dials and fire-orange pointer tips. Red through-dial and white perimeter lighting
provide great night readability. Excellent inboard coverage with engine sync gauges* and diesel alternator
and magnetic pickup tachometers**.
*Module required, not included with gauge. **Magnetic Pickup sender available separately.
Features:
White dial, black numerals, black pointer with
fire-orange tip.
Scratch resistant curved glass lenses, with polished
stainless steel, near-flush bezels.
U.S. and metric scales, with ISO symbols.
Optional add-on square bezels for modular
appearance (See Gauge Accessories for details).
White perimeter and red thru-dial lighting.
Comprehensive line includes tachometers for diesel
alternator and magnetic pickup PLUS synchronizer
gauge (Suitable for gas or diesel engines with ap
propriate module. Module required, not included
with gauge).
FOG resIstaNt GauGe Features:
Fog-Resistant Design! Complies with SAE J-1810.
seLeCtION GuIDe:
GAUGE DESCRIPTION
SIZE
DIAL RANGE
SENDER CODE
FOG
RESISTANT
Engine Sync (gauge only)
2"
PORT-STBD.
REQUIRES "L"
Fuel Gauge:
2"
E-1/2-F
REQUIRES "F"
Hourmeter:
2"
10,000 Hrs.
NONE REQ'D
Oil Pressure Gauges (Electric):
Oil Pressure 80 PSI
2"
0-80 PSI
REQUIRES "C"
Oil Pressure 100 PSI
2"
0-100 PSI
REQUIRES "C"
GPS Speedometer:
35 MPH
3"
0-35 MPH
60 MPH
3"
0-60 MPH
80 MPH
3"
0-80 MPH
Speedometer Kits:
35 MPH (Pitot type)
3"
5-35 MPH
INCLUDES "G"
35 MPH (Pitot type) Head Only
3"
5-35 MPH
50 MPH (Pitot type)
3"
10-50 MPH
INCLUDES "G"
50 MPH (Pitot type) Head Only
3"
10-50 MPH
65 MPH (Pitot type)
3"
10-65 MPH
INCLUDES "G"
80 MPH (Pitot type)
3"
20-80 MPH
INCLUDES "G"
80 MPH (Pitot type) Head Only
3"
20-80 MPH
Systems Check � Evinrude/Johnson:
2"
SYSTEM DATA
BY ENG. MFR.
Tachometer (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-7000 RPM
O/B ALT./COIL
Systems Check � Evinrude/Johnson
3"
0-7000 RPM
O/B ALT./COIL
Tachometer/Hourmeters (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-7000 RPM
O/B ALT./COIL
Diesel Alternator**
3"
0-4000 RPM
SEE "T"
Diesel Magnetic Pickup, 90-180 Teeth
3"
0-4000 RPM
REQUIRES "B"
Trim Gauges (Outboard, I/O):
Evinrude/Johnson Outboard
2"
UP-DOWN
BY ENG. MFR.
Honda Outboards
2"
UP-DOWN
BY ENG. MFR.
Mariner/Merc/Cobra/Volvo DP, SX,
Yamaha 2001, and on
2"
UP-DOWN
BY ENG. MFR.
Suzuki 4-Stroke, 2002 to date
2"
UP-DOWN
BY ENG. MFR.
Yamaha Outboards, pre 2001
2"
UP-DOWN
BY ENG. MFR.
Voltmeter-12 Volt:
2"
8-18 VDC
NONE REQ'D
Warning Light Gauge � Suzuki:
2"
SYSTEM DATA
BY ENG. MFR.
Water Pressure Kit (Outboard):***
Each kit includes fittings
2"
30 PSI
INCLUDES "WP"
and 20 feet of tubing)
Water Temp. Kit (Outboard):***
(For all electric-start outboards)
2"
COLD-HOT
INCLUDES "J"
Water Temp. Gauge (I/O, I/B):
2"
120-240�F
REQUIRES "D"
Instrument Set "OUTBOARD"
4 Gauge set
Instrument Set "INBOARD/STERNDRIVE"
6 Gauge set
8
All gauge products are only available in North America!
