Sierra Marine Parts Catalog
WHIte PreMIer PrO -- Ideal for inboards, including diesels, Premier White features polished stainless
steel bezels and clean white dials with modern black and blue graphics. When illuminated, black dial grads
become red and pointer lights red. Automotive type light-piping and fog-resistant design combine for
outstanding readability.
Features:
Full automotive type lighting, no "halo" around
dial edges. When illuminated, white dial grads
become red, pointer lights white.
White dial, black graduations/numerals (metrics in
blue), red pointer staff.
Scratch resistant curved glass lenses, with polished
stainless steel near-flush bezels.
U.S. and metric scales, with ISO symbols, where
appropriate.
Optional add-on square bezels for modular
appearance (See Gauge Accessories for details).
Fog-Resistant Design! Complies with SAE J-1810.
seLeCtION GuIDe:
GAUGE DESCRIPTION
SIZE
DIAL RANGE
SENDER CODE
PART NUMBER
Fuel Gauge:
2"
E-1/2-F
REQUIRES "F"
Hourmeter:
2"
10,000 Hrs.
NONE REQUIRED
Oil Pressure Gauges (Electric):
Oil Pressure 80 PSI
2"
0-80 PSI
REQUIRES "C"
Oil Pressure 100 PSI
2"
0-100 PSI
REQUIRES "C"
GPS Speedometer:
35 MPH
3"
0-35 MPH
60 MPH
3"
0-60 MPH
80 MPH
3"
0-80 MPH
120 MPH
3"
0-120 MPH
Speedometer Kits:
65 MPH (Pitot type)
3"
10-65 MPH
INCLUDES "G"
65 MPH (Pitot type) Head Only
3"
10-65 MPH
80 MPH (Pitot type)
3"
20-80 MPH
INCLUDES "G"
Tachometer (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-7000 RPM
O/B ALT./COIL
Tachometer/Hourmeter (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-7000 RPM
O/B ALT./COIL
Tachometers (Electric):
Diesel Alternator**
3"
0-4000 RPM
SEE "T"
Diesel Magnetic Pickup, 90-180 Teeth
3"
0-4000 RPM
REQUIRES "B"
Trim Gauges (Outboard, I/O):
Evinrude/Johnson Outboards
2"
UP-DOWN
BY ENG. MFR
Mariner/Merc/Cobra/Volvo DP, SX,
Yamaha 2001 and on
2"
UP-DOWN
BY ENG. MFR
Suzuki 4-Stroke, 2002 to date
2"
UP-DOWN
BY ENG. MFR
Voltmeters-12 & 24 Volt:
12 Volt System
2"
8-18 VDC
NONE REQ'D
24 Volt System
2"
20-32 VDC
NONE REQ'D
Water Temp. Gauge (I/O, I/B):
2"
120-240�F
REQUIRES "D"
Water Pressure Kit, O/B
2"
40 PSI
INCLUDES "WP"
Instrument Set "INBOARD/STERNDRIVE" 6 Gauge set
* Mariner 30 & 40 HP (2-cylinder) engines require a module (Mercury P/N 17461A2) when using any of these tachometers.
Not tested for non-original-equipment (aftermarket) ignition systems. Not for diesels.
** May require alternator tap.
7
All gauge products are only available in North America!
