Starter Motor(8") for Mercruiser (7.4l Bravo) Engine
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]
| #1 — 812428A 3 — STARTER MOTOR ASSEMBLY (1 required per assembly) | ||
  |
50-812428A 3 - Starter Assembly [ More info ] Unavailable |
|
  |
50-812604A 2 - Starter [ More info ] Unavailable |
|
  |
50-806964A 2 - Starter [ More info ] Unavailable |
|
  |
50-806964A 3 - Starter [ More info ] Unavailable |
|
  |
50-806964A 4 - Starter [ More info ] Unavailable |
|
  |
|
50-863007A 1 - Starter, Offset Bolt Pattern. [ More info ]
|
  |
50-864340A 2 - Starter Assembly [ More info ] Unavailable |
|
  |
|
18-6275-1 - Inboard Starter [ More info ]
|
  |
|
18-5913-1 - Starter, 50-812428A3, Gear Reduction, Offset Bolt Pattern [ More info ]
|
  |
|
30460 - Starter, 50-806963A2, Straight Across Bolt Pattern [ More info ]
|
  |
|
30433 - Premium Inboard Starter, Staggered Bolt Pattern [ More info ]
|
| #2 — 814464 — FRAME (1 required per assembly) | ||
  |
|
814464 - Frame, NLA [ More info ] Unavailable |
| #3 — 814465 — BEARING, Ball (1 required per assembly) | ||
  |
|
30-814465 - Ball Bearing, NLA [ More info ]
|
| #4 — 814466 — HOLDER, Brush (1 required per assembly) | ||
  |
|
814466 - Brush Holder Assembly, NLA [ More info ] Unavailable |
| #5 — 814467 — SPRING (4 required per assembly) | ||
  |
|
24-814467 - Spring-brush,NLA [ More info ] Unavailable |
| #6 — 814469 — ARMATURE (1 required per assembly) | ||
  |
|
814469 - Armature, NLA [ More info ] Unavailable |
| #7 — 814470 — SHIELD (1 required per assembly) | ||
  |
814470 - SHIELD [ More info ] Unavailable |
|
  |
|
811882 - SHIELD,NLA [ More info ] Unavailable |
| #8 — 814471 — GEAR AND BEARING (1 required per assembly) | ||
  |
|
814471 - GEAR & BRG ASSY,NLA [ More info ] Unavailable |
| #9 — 814479 — BEARING, Roller (1 required per assembly) | ||
  |
|
814479 - Bearing-ROLLER,NLA [ More info ] Unavailable |
| #10 — 814472 — SHAFT/GEAR ASSEMBLY (1 required per assembly) | ||
  |
814472 - SHAFT & Gear [ More info ] Unavailable |
|
  |
50-822330A 2 - Starter [ More info ] Unavailable |
|
|
50-806964A 2 - Starter [ More info ] Unavailable |
|
|
50-806964A 3 - Starter [ More info ] Unavailable |
|
|
50-806964A 4 - Starter [ More info ] Unavailable |
|
|
50-864340A 2 - Starter Assembly [ More info ] Unavailable |
|
| #11 — 814473 — DRIVE (1 required per assembly) | ||
  |
814473 - Drive Assembly [ More info ] Unavailable |
|
  |
|
811896 - Drive [ More info ] Unavailable |
| #12 — 33291 — COLLAR (1 required per assembly) | ||
  |
|
|
| #13 — 33290 — RING, Retaining (1 required per assembly) | ||
  |
|
53-33290 - Ring - Retaining - Priced Individually [ More info ]
|
| #14 — 814474 — COLLAR (1 required per assembly) | ||
  |
814474 - COLLAR [ More info ] Unavailable |
|
  |
|
23-809457 - Thrust Collar, NLA [ More info ] Unavailable |
| #15 — 814475 — HOUSING, Drive (1 required per assembly) — (Drive Housing includes starter switch, plunger, return spring, and shift lever.) | ||
  |
|
814475 - Drive Housing Assembly, NLA [ More info ]
|
| #16 — 814476 — BUSHING (1 required per assembly) | ||
  |
|
23-814476 - Bearing [ More info ]
|
| #17 — N.S.S. — Not Sold Separate, NUT (1 required per assembly) | ||
  |
|
N.S.S. - Not Sold Separate [ More info ] Unavailable |
| #18 — 814468 — SCREW (2 required per assembly) | ||
  |
|
10-814468 - SCREW,NLA [ More info ] Unavailable |
| #19 — 814477 — THRU BOLT (2 required per assembly) | ||
  |
|
10-814477 - BOLT-THRU,NLA [ More info ] Unavailable |
