SUZUKI OUTBOARD APPLICATION CHARTS
8‑15 Horsepower ‑ Suzuki
DF 8 HP 2010 & Newer
DT 9.9 HP 1983‑87
DF 9.9 HP 1997 & Newer
DT 15 HP 1983‑88
DT 15C HP 1989‑97
DF 15 HP 1997 & Newer
10 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
14-19 / 4.2-5.8 19-24 / 31-39 9 1/4 X 10 RH AL 3 Black Diamond QA2270R 58100-93773-09 Rubber Bushing
14-16 / 4.2-4.8 21-26 / 34-42 9 1/4 X 11 RH AL 3 Black Diamond QA2274R 58100-93743-019 Rubber Bushing
25‑30 Horsepower ‑ Suzuki
DT20 & 25 HP 1987‑88
DT20 & 25 HP 1983‑86
DF25 HP 1989 & Newer
DT25C HP 1989‑2000
DF30 HP 2000 & Newer
DT30 HP 1983‑86
DT30, 30C HP 1987‑97
10 Tooth Spline
Use Suzuki OEM stopper Part No. 57632‑96400 on DT20/25 1983‑86 & DT30 1983‑86.
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
20+ / 6.1+ to 16 / to 26 11 X 9 RH AL 3 Black Diamond QA2242R 58100-96370-019 Rubber Bushing
17-20 / 5.2-6.1 10-20 / 16-32 10.5 X 11 RH AL 3 Black Diamond QA2248R 58100-96420-019 Rubber Bushing
15-18 / 4.5-5.5 21-31 / 34-50 10.3 X 12 RH AL 3 Black Diamond QA2252R 58100-96480-019 Rubber Bushing
13-15 / 3.9-4.5 26-34 / 42-55 10.1 X 13 RH AL 3 Black Diamond QA2254R 58100-96490-019 Rubber Bushing
35‑65 Horsepower ‑ Suzuki ‑ Reflex Hub
DT35C HP 1987‑90
DT40, DF40 HP 1983 & Newer
DF 50 1999 and Newer
DT50,50M HP 1983‑84
DT55 HP 1985‑97
DT60 HP 1983‑84
DT65 HP 1985‑97
13 Tooth Spline
Flo‑Torq Reflex Propeller.
Replace existing forward and aft washer with Quicksilver kit 8M0088039. Purchase separately.
Length (ft/m)
Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N Hub System
20'+ / 6.1+ to 14 / to 23 12 1/2 X 8 RH AL 3 Black Diamond QA2060X Flo-Torq Reflex(1)
19-21 / 5.8-6.4 13-18 / 21-29 12 1/4 X 9 RH AL 3 Black Diamond QA2062X Flo-Torq Reflex(1)
17-20 / 5.2-6.1 18-22 / 29-35 11 1/4 X 10 RH AL 3 Black Diamond QA2064X Flo-Torq Reflex(1)
17-20 / 5.2-6.1 18-22 / 29-35 12 X 10 1/2 RH AL 3 Black Diamond QA2066X Flo-Torq Reflex(1)
17-20 / 5.2-6.1 18-22 / 29-35 11 5/8 X 10 1/2 RH AL 3 Black Diamond QA2068X Flo-Torq Reflex(1)
16-19 / 4.8-5.8 21-25 / 34-41 10 7/8 X 11 RH AL 3 Black Diamond QA2070X Flo-Torq Reflex(1)
15-18 / 4.5-5.5 23-28 / 37-45 10 3/4 X 12 RH AL 3 Black Diamond QA2072X Flo-Torq Reflex(1)
15-18 / 4.5-5.5 23-28 / 37-45 10 5/8 X 12 RH AL 3 Black Diamond QA2074X Flo-Torq Reflex(1)
14-18 / 4.2-5.5 27-32 / 44-52 10 1/2 X 13 RH AL 3 Black Diamond QA2076X Flo-Torq Reflex(1)
14-18 / 4.2-5.5 27-32 / 44-52 10 3/8 X 13 RH AL 3 Black Diamond QA2078X Flo-Torq Reflex(1)
14-16 / 4.2-4.8 31-35 / 50-56 10 3/8 X 14 RH AL 3 Black Diamond QA2080X Flo-Torq Reflex(1)
14-16 / 4.2-4.8 31-35 / 50-56 10 1/4 X 14 RH AL 3 Black Diamond QA2082X Flo-Torq Reflex(1)
13-15 / 3.9-4.5 34-39 / 55-63 10 1/8 X 15 RH AL 3 Black Diamond QA2084X Flo-Torq Reflex(1)
15-18 / 4.5-5.5 23-28 / 37-45 10.6 X 12 RH AL 4 Nemesis 48-8M8027511 Flo-Torq Reflex(1)
14-18 / 4.2-5.5 27-32 / 44-52 10.3 X 13 RH AL 4 Nemesis 48-8M8027512 Flo-Torq Reflex(1)
SUZUKI OUTBOARD APPLICATION CHARTS
