Parts for 9.9 (2 Cyl.) (International) 2-Stroke Carbureted Mercury Outboard Motor Remote Control-4000 Side Mount (Non Power Trim)

Revise Search: Outboard > 2-Stroke Carbureted Mercury Outboard > 9.9 (2 Cyl.) (International) > 0N059858 & Up > Remote Control-4000 Side Mount (Non Power Trim)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Remote Control-4000 Side Mount (Non Power Trim)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0178532	REMOTE CONTROL (1 required per assembly) — Replaces: 881170A9
		8M0178532 - Remote Control [ More info ] $726.28 Available to Order: Shipping delay up to 10 days.
#1	NSS	NOT SOLD SEPARATE HOUSING, FRONT (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#2	170622	DECAL (F-N-R) (1 required per assembly)
		37-17062 2 - Decal -f/N/R [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#3	NSS	NOT SOLD SEPARATE DECAL, THROTTLE FRICTION (1 required per assembly)
#4	NSS	NOT SOLD SEPARATE DECAL, RUN/OFF (1 required per assembly)
#5	850731A2	HARNESS ASSEMBLY (1 required per assembly)
		84-850731A 2 - Harness Assembly [ More info ] $109.99 Available to Order: Shipping delay up to 10 days.
#6	816311T	TIE STRAP (8.00 INCHES) (AR required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#7	11023	PLUG (1 required per assembly)
		19-11023 - Plug [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#8	881148T04	HANDLE KIT (1 required per assembly)
		881148T04 - Handle Kit -nontrim [ More info ] Unavailable
		8M0205858 - HDL KIT-NON-TRIM [ More info ] Unavailable
#9	NSS	NOT SOLD SEPARATE HUB, HANDLE (1 required per assembly)
#10	4007154	SCREW (M8 X 30) (1 required per assembly)
		10-40071 54 - Screw [ More info ] $3.04 $0.88 5 In Stock.
#11	8M0207778	WASHER @5 (1 required per assembly) — Replaces: 12038
		12-8M0207778 - WASHER Note: Priced Individually [ More info ] $11.89 5 In Stock.
#12	40118107	SCREW (M5 X 18) (5 required per assembly)
		10-40118107 - Screw [ More info ] $1.82 Available to Order: Shipping delay up to 10 days.
#13	4005685	SCREW (M4 X 10) (2 required per assembly)
		10-40056 85 - Screw [ More info ] $1.82 $1.74 1 In Stock.
#14	16921	BRACKET LOCK BAR SUPPORT (1 required per assembly)
		16921 - Bracket [ More info ] $2.34 Available to Order: Shipping delay up to 10 days.
#15	87775510	SCREW (M4 X 10) (1 required per assembly)
		10-877755 10 - Screw - Priced Individually [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
#16	8M0207317	LOCK BAR-BLACK (1 required per assembly) — Replaces: 881138
		8M0207317 - LOCK BAR-BLACK [ More info ] $10.27 1 In Stock.
#17	16924	SPRING (1 required per assembly)
		24-16924 - Spring [ More info ] $1.58 Available to Order: Shipping delay up to 10 days.
#18	8811411	GRIP (1 required per assembly)
		881141 1 - Handle Grip [ More info ] $20.89 Available to Order: Shipping delay up to 10 days.
#19	881146	PLUG (1 required per assembly)
		881146 - Plug [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#20	881137A1	CAP/DECAL ASSEMBLY (1 required per assembly)
		881137A 1 - Cap/Decal Assembly [ More info ] $16.39 Available to Order: Shipping delay up to 10 days.
#21	40118107	SCREW (M5 X 18) (2 required per assembly)
#22	16923	LOCKWASHER EXTERNAL (2 required per assembly)
		13-16923 - LockWasher [ More info ] $0.93 Available to Order: Shipping delay up to 10 days.
#23	16899T	HOLDER NEUTRAL LOCK (1 required per assembly) — Replaces: 16899
		16899T - Holder [ More info ] $5.43 2 In Stock.
#24	16917	COVER (1 required per assembly)
		16917 - Cover [ More info ] $6.75 1 In Stock.
#25	40116110T	SCREW (M6 X 110) (3 required per assembly) — Replaces: 40116110
		10-40116110T - Screw [ More info ] $4.64 4 In Stock.
#26	881145	KNOB THROTTLE FRICTION (1 required per assembly)
		881145 - Knob [ More info ] $10.19 Available to Order: Shipping delay up to 10 days.
#27	16896	WASHER (1 required per assembly)
		12-16896 - Washer [ More info ] $0.93 Available to Order: Shipping delay up to 10 days.
#28	13194	RING RETAINING (1 required per assembly)
		53-13194 - Ring - Retaining - Priced Individually [ More info ] $1.27 10+ In Stock.
#29	16895	ARM ASSEMBLY BRAKE (1 required per assembly)
		16895 - Arm Assembly [ More info ] Unavailable
#30	16875	BEARING (1.750 INSIDE DIAMETER) (2 required per assembly)
		23-16875 - Bearing - 1.75 ID [ More info ] $1.82 Available to Order: Shipping delay up to 10 days.
#31	16874	WASHER (1 required per assembly)
		12-16874 - Washer [ More info ] $1.58 Available to Order: Shipping delay up to 10 days.
#32	13541	PLUG MALE (AR required per assembly)
		13541 - Plug [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#32	13540	CAP FEMALE (AR required per assembly)
		13540 - Plug - Priced Individually [ More info ] $1.10 $0.22 10+ In Stock.
#33	401385	NUT (M5) STAINLESS STEEL (2 required per assembly)
		11-40138 5 - Nut [ More info ] Unavailable
#34	85899A1	CLIP ASSEMBLY (2 required per assembly)
		54-85899A 1 - Clip Assembly [ More info ] $4.85 2 In Stock.
#35	NSS	NOT SOLD SEPARATE GEAR SHIFT ASSEMBLY (1 required per assembly)
#36	16868	BEARING (.750 INSIDE DIAMETER) (1 required per assembly)
		23-16868 - Bearing - .75 ID [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#37	16870	WASHER (1 required per assembly)
		12-16870 - Washer [ More info ] $1.58 Available to Order: Shipping delay up to 10 days.
#38	16873	ROLLER CAM (1 required per assembly)
		16873 - Roller [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#39	NSS	NOT SOLD SEPARATE DRIVE GEAR (1 required per assembly)
#40	NSS	NOT SOLD SEPARATE PLATE, STUD ASSEMBLY (1 required per assembly)
#41	4005683	SCREW (M4 X 6) (2 required per assembly)
		10-40056 83 - Screw [ More info ] $1.24 1 In Stock.
#42	16886	CLIP (1 required per assembly)
		16886 - Clip [ More info ] $3.05 2 In Stock.
#43	16888	SPRING (1 required per assembly)
		24-16888 - Spring [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#44	16884	ROLLER (1 required per assembly)
		16884 - Roller [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#45	16883	DRUM ASSEMBLY (1 required per assembly)
		16883 - Drum [ More info ] $14.50 Available to Order: Shipping delay up to 10 days.
#46	16922	WAVE WASHER (1 required per assembly)
		13-16922 - Wave Washer [ More info ] $0.93 Available to Order: Shipping delay up to 10 days.
#47	NSS	NOT SOLD SEPARATE COVER, BOTTOM (1 required per assembly)
#48	NSS	NOT SOLD SEPARATE COVER, TOP (1 required per assembly)
#49	16887	BEARING (.810 INSIDE DIAMETER) (1 required per assembly)
		23-16887 - Bearing - .810 ID [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#50	40118106	SCREW (M5 X 12) (2 required per assembly)
		10-40118106 - Screw [ More info ] $1.82 Available to Order: Shipping delay up to 10 days.
#51	16919A1	LEVER ASSEMBLY WITH DECAL (1 required per assembly)
		16919A 1 - Lever Assembly [ More info ] $24.04 Available to Order: Shipping delay up to 10 days.
#52	NSS	NOT SOLD SEPARATE DECAL, LIFT FOR FAST IDLE (1 required per assembly)
#53	35280	WASHER (.255 X .620 X .030) STAINLESS STEEL (3 required per assembly)
		12-35280 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ] $3.19 $2.56 10+ In Stock.
#54	401196	NUT (M6) (3 required per assembly)
		11-40119 6 - Nut [ More info ] $3.06 Available to Order: Shipping delay up to 10 days.
#55	17063T	SPACER (1 required per assembly)
		17063T - Spacer, NLA [ More info ] $16.45 10+ In Stock.
#56	71942	BUSHING (1 required per assembly)
		23-71942 - Bushing [ More info ] $2.09 10+ In Stock.
#57	17009A5	SWITCH ASSEMBLY IGNITION (1 required per assembly)
		87-17009A 5 - Switch Assembly [ More info ] $71.52 1 In Stock.
		MP51090 - Ignition Switch, 87-17009A5 [ More info ] $63.89 $60.97 2 In Stock.
		MP41070-2 - Ignition Switch, 87-17009A5 [ More info ] $36.49 $35.70 10+ In Stock.
#58	879755	NUT SPECIAL - BLACK NYLON (1 required per assembly)
		11-879755 - Nut, (black Nylon) [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#59	90468A1	COVER ASSEMBLY KEY (2 required per assembly)
		90468A 1 - Cover Assembly [ More info ] $4.86 Available to Order: Shipping delay up to 10 days.
		90468 - Cover, NLA [ More info ] $1.67 $1.42 4 In Stock.
#60	40056105	SCREW (M5 X 10) (1 required per assembly)
		10-40056105 - Screw [ More info ] $1.23 Available to Order: Shipping delay up to 10 days.
#61	16879	ROLLER DETENT (1 required per assembly)
		16879 - Roller [ More info ] $2.34 Available to Order: Shipping delay up to 10 days.
#62	16880	CLIP (1 required per assembly)
		16880 - Clip [ More info ] $2.44 1 In Stock.
#63	16882	SPRING (5 required per assembly)
		24-16882 - Spring, Detent [ More info ] Unavailable
#64	4005647	SCREW (M3 X 16) (2 required per assembly)
		10-40056 47 - Screw [ More info ] $1.24 Available to Order: Shipping delay up to 10 days.
#65	17277T	SWITCH NEUTRAL SAFETY (1 required per assembly) — Replaces: 17277
		87-17277T - Switch - Neutral Safety [ More info ] $13.36 2 In Stock.
#66	91941A8	SWITCH ASSEMBLY (1 required per assembly)
		87-91941A 8 - Switch Assembly [ More info ] $29.66 Available to Order: Shipping delay up to 10 days.
#67	15920Q54	LANYARD ASSEMBLY (1 required per assembly)
		15920Q54 - Stop Switch Lanyard- Priced Individually [ More info ] Unavailable
#68	850753A1	SPACER KIT RIGGING (1 required per assembly)
		850753A 1 - Spacer Kit - Rigging [ More info ] $29.99 Available to Order: Shipping delay up to 10 days.
#69	4008820	SCREW (M6 X 20) (2 required per assembly)
		10-40088 20 - Screw [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#70	892542A01	INDICATOR-SHIFT (1 required per assembly)
		91-892542A01 - Indicator- Shift [ More info ] $75.00 $63.52 5 In Stock.
