Parts for MerCruiser Zeus 3000 JH Cooling System (With Drop Box)
Tap to zoom. Scroll down to order.
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
#1 | 879148T59 | COOLER, Oil (1 required per assembly) |
879148T59 - COOLER-OIL [ More info ] Unavailable |
||
8M0046594 - Oil Cooler [ More info ] Unavailable |
||
#2 | 8M0007715 | BRACKET (1 required per assembly) |
#3 | 8M0007713 | BRACKET (1 required per assembly) |
#4 | 10-40089 16 | SCREW, (M8 x 16) Stainless Steel (3 required per assembly) |
#5 | 8M0007716 | BRACKET (1 required per assembly) |
#6 | 8M0007714 | BRACKET (1 required per assembly) |
#7 | 54-815504224 | CLAMP, Worm Gear (4 required per assembly) |
#8 | 32-8M0037197 | HOSE (1 required per assembly) |
#9 | 879345T58 | BALL VALVE ASSMBLY, 1.5 Inch (1 required per assembly) |
#10 | 25-38106 | O-RING (1 required per assembly) |
#11 | 19-8M0025635 | PLUG (1 required per assembly) |
#12 | 20-815113A06 | BALL VALVE ASSEMBLY, Long Neck, 2.0 Inch (1 required per assembly) |
20-815113A06 - Water Valve Assembly [ More info ] Unavailable |
||
#12 | 879150A64 | BALL VALVE ASSEMBLY, 2.5 Inch (1 required per assembly) |
20-879150A64 - Water Valve - 2.5 [ More info ] Unavailable |
||
#14 | 10-8M0041198 | SCREW, (M8 x 30) (3 required per assembly) |
#15 | 897345T95 | COOLER (1 required per assembly) |
#16 | 10-8M0039671 | SCREW, (M8 x 20) (3 required per assembly) |
#17 | 32-8M0037776 | HOSE (1 required per assembly) |
#19 | 10-40003 27 | SCREW, (M6 x 14) (2 required per assembly) |
#20 | 8M0025162 | CLAMP (1 required per assembly) |
#21 | 8M0040165 | BRACKET (1 required per assembly) |
#23 | 8M0046084 | COVER PLATE (1 required per assembly) Zorro |
