Parts for Mariner 8A Throttle Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 81051M | BRACKET, SHAFT... (1 required per assembly) |
  |
|
81051M - Bracket, NLA [ More info ] Unavailable |
| #2 | 10-82426M | BOLT, BRACKET ATTACHING... (2 required per assembly) |
  |
10-82426M - BOLT [ More info ] Unavailable |
|
  |
10-84237M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #3 | 13-82199M | WASHER... (4 required per assembly) |
  |
13-82199M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #4 | 23-81945M | BUSHING, SHAFT... (2 required per assembly) |
  |
|
23-81945M - Bushing, NLA [ More info ]
|
| #5 | 80499M | SHAFT, THROTTLE... (1 required per assembly) |
  |
|
80499M - SHAFT,NLA [ More info ] Unavailable |
| #6 | 81091M | CAM, THROTTLE... (1 required per assembly) |
  |
|
81091M - Cam, NLA [ More info ] Unavailable |
| #7 | 17-82148M | PIN, ROLL-CAM... (2 required per assembly) SERIAL 00000000-00026575 |
  |
|
17-82148M - Pin, Roll, NLA [ More info ]
|
| #8 | 81050M | PULLEY, THROTTLE CABLE... . (1 required per assembly) SERIAL 00000000-00026575 |
  |
81050M - PULLEY [ More info ] Unavailable |
|
  |
|
83070M - Throttle Shaft [ More info ]
|
| #9 | 81049M | LEVER, MAGNETO CONTROL... (1 required per assembly) |
  |
|
|
| #10 | 10-82422M | .. . (1 required per assembly) SERIAL 00000000-00026575 |
  |
10-82422M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
10-84247M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
10-91725M - BOLT [ More info ] Unavailable |
|
  |
|
10-826957M - Bolt, NLA [ More info ]
|
| #11 | 13-82197M | LOCKWASHER, LEVER BOLT... (1 required per assembly) |
  |
13-82197M - LockWasher - Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #12 | 80489M | LINK, MAGNETO CONTROL... (1 required per assembly) |
  |
|
80489M - LEVER,NLA [ More info ] Unavailable |
| #13 | 80484M | CAM, MAGNETO CONTROL... (1 required per assembly) |
  |
|
80484M - CAM,NLA [ More info ] Unavailable |
| #14 | 17-80500M | PIN, LINK... (1 required per assembly) |
  |
|
17-80500M - Clevis Pin,NLA [ More info ] Unavailable |
| #15 | 17-80501M | PIN, LINK... (1 required per assembly) |
  |
|
17-80501M - Clevis Pin, NLA [ More info ]
|
| #16 | 13-81865M | LOCKWASHER, LINK PIN... (2 required per assembly) |
  |
|
13-81865M - Wave Washer - Priced Individually [ More info ]
|
| #17 | 12-82209M | WASHER, LINK PIN... (2 required per assembly) |
  |
|
12-82209M - Washer, NLA [ More info ]
|
| #18 | 18-82051M | PIN,RETAINING... (2 required per assembly) |
  |
|
18-82051M - Cotter Pin - Priced Individually [ More info ]
|
| #19 | 80487M | INDICATOR, MAGNETO TIMING... (1 required per assembly) |
  |
|
80487M - INDICATOR,NLA [ More info ] Unavailable |
| #20 | 83070M | PULLEY... . (1 required per assembly) SERIAL 00026576-09999999 |
| #21 | 82888M | SHAFT, LINK CONNECTING... (1 required per assembly) SERIAL 00026576-09999999 |
  |
82888M - SHAFT [ More info ] Unavailable |
|
| #22 | 10-82872M | BOSS, LEVER... . (1 required per assembly) SERIAL 00026576-09999999 |
  |
|
10-82872M - Screw, NLA [ More info ]
|
| #23 | 11-82380M | . . (1 required per assembly) SERIAL 00026576-09999999 |
  |
|
11-82380M - NUT - Priced Individually [ More info ]
|
  |
|
11-82389M - Nut, NLA [ More info ] Unavailable |
