Parts for Mariner 8A Steering Handle

Revise Search: All Models > 8A > 682-550141 - 551055 (EL) > Steering Handle

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	81054M	BRACKET, STEERING... (1 required per assembly)
		81054M - Bracket, NLA [ More info ] Unavailable
#2	80510M	SPACER, STEERING BRACKET... (2 required per assembly)
		80510M - Spacer, NLA [ More info ] Unavailable
#3	10-82466M	BOLT, STEERING BRACKET ATTACHING... (2 required per assembly)
		10-82466M - Bolt Note: Priced Individually [ More info ] Unavailable
		10-814575M - BOLT [ More info ] Unavailable
		10-82442M - Bolt, NLA [ More info ] $4.50 10+ In Stock.
#4	12-81801M	WASHER, STEERING BRACKET BOLT... . (2 required per assembly) SERIAL 00000000-00026575
		12-81801M - Washer, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#5	25-80515M	GROMMET, STEERING BRACKET BOLT... (4 required per assembly)
		25-80515M - Grommet, Steering Bracket Bolt, NLA [ More info ] Unavailable
#6	23-81991M	BUSHING, STEERING BRACKET BOLT... . (2 required per assembly) SERIAL 00000000-00026575
		23-81991M - SPACER,NLA [ More info ] Unavailable
#7	82609M	ARM, STEERING... (1 required per assembly) SERIAL 00000000-00020160
		82609M - ARM [ More info ] Unavailable
		83093M - Arm, NLA [ More info ] Unavailable
#7	80502M	ARM, STEERING... (1 required per assembly) SERIAL 16-57630-09999999
		80502M - ARM [ More info ] Unavailable
#8	25-82272M	O-RING, STEERING ARM... (1 required per assembly)
		25-82272M - O-ring, Steering Arm,NLA [ More info ] $1.88 $1.59 6 In Stock.
#9	23-82121M	SPACER, STEERING ARM... (1 required per assembly)
		23-82121M - Spacer, NLA [ More info ] Unavailable
#10	23-82118M	SPACER, STEERING ARM... (1 required per assembly)
		23-82118M - Spacer, NLA [ More info ] $1.62 6 In Stock.
#11	23-80506M	SPACER, STEERING ARM (0.5MM)... (AR required per assembly)
		23-80506M - Spacer - .5mm [ More info ] $1.62 10 In Stock.
#11	25-80507M	SPACER, STEERING ARM (0.6MM)...
		23-80507M - Spacer - .6mm [ More info ] Unavailable
		23-898103217 - Spacer, NLA [ More info ] $1.62 3 In Stock.
#11	23-80508M	SPACER, STEERING ARM (0.8MM)...
		23-80508M - Spacer - .8mm [ More info ] $1.62 10 In Stock.
#12	80503M	CAP, STEERING ARM PIVOT... (1 required per assembly)
		80503M - Steering Arm Pivot Cap [ More info ] Unavailable
#13	10-82173M	SCREW, PIVOT CAP ATTACHING... (2 required per assembly)
		10-82173M - Screw - Priced Individually [ More info ] Unavailable
		10-11828M - Screw, NLA [ More info ] $1.62 10+ In Stock.
#14	13-82212M	LOCKWASHER, PIVOT CAP SCREW... (2 required per assembly)
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#15	81052M	SHAFT, THROTTLE... (1 required per assembly)
		81052M - SHAFT,NLA [ More info ] Unavailable
#16	23-81945M	BUSHING, STEERING ARM... (2 required per assembly)
		23-81945M - Bushing, NLA [ More info ] $9.36 10 In Stock.
#17	82610M	CAM, THROTTLE... (1 required per assembly) SERIAL 00000000-00020160
		82610M - LEVER,NLA [ More info ] Unavailable
#17	81053M	CAM, THROTTLE... (1 required per assembly) SERIAL 00020161-09999999
		81053M - CAM,NLA [ More info ] Unavailable
#18	17-82146M	PIN, ROLL-THROTTLE CAM... (1 required per assembly) SERIAL 00000000-00020160
		17-82146M - Pin -roll, NLA [ More info ] Unavailable
#18	17-82150M	PIN, ROLL-THROTTLE CAM... . (1 required per assembly) SERIAL 00020161-09999999
		17-82150M - PIN,NLA [ More info ] Unavailable
#19	24-82095M	SPRING, THROTTLE SHAFT... (1 required per assembly) SERIAL 00000000-00020160
		24-82095M - Spring, Throttle Shaft,NLA [ More info ] $9.69 10 In Stock.
#19	24-82092M	SPRING, THROTTLE SHAFT... (1 required per assembly) SERIAL 6-57270)-0Z999999
		24-82092M - SPRING,NLA [ More info ] Unavailable
#20	12-82219M	WASHER, THROTTLE SHAFT... . (1 required per assembly) SERIAL 00000000-00020160
		12-82219M - Washer, Throttle Shaft, NLA [ More info ] $1.63 $1.39 10+ In Stock.
#20	81132M	FRICTION, HANDLE GRIP... . (1 required per assembly) SERIAL 16-57270-09999999
		81132M - GUIDE,NLA [ More info ] Unavailable
#21	80505M	INDICATOR, THROTTLE... (1 required per assembly)
		80505M - INDICATOR,NLA [ More info ] Unavailable
#22	17-81907M	RIVET, INDICATOR... . (1 required per assembly) SERIAL 00000000-00020160
		17-81907M - Rivet, NLA [ More info ] $7.53 6 In Stock.
#23	80504M	HANDLE, THROTTLE... (1 required per assembly)
		80504M - Steering Handle Grip, NLA [ More info ] Unavailable
#24	10-82483M	SCREW, HANDLE ATTACHING... (1 required per assembly)
		10-82483M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-84300M - SCREW Note: Priced Individually [ More info ] Unavailable
		10-811916M - Screw, NLA [ More info ] $3.61 $3.06 10+ In Stock.
#25	80509M	GRIP, STEERING ARM END THROTTLE... (1 required per assembly)
		80509M - Grip, NLA [ More info ] $9.99 $8.45 6 In Stock.
#26	81045M	CABLE, THROTTLE ASS'Y... (2 required per assembly)
		81045M - Cable, NLA [ More info ] $18.87 10+ In Stock.
#27	11-81762M	NUT, CABLE GUIDE ATTACHING... (4 required per assembly)
		11-81762M - NUT,NLA [ More info ] Unavailable
#28	80481M	GUIDE, CABLE... (2 required per assembly)
		80481M - GUIDE,NLA [ More info ] Unavailable
#29	11-81761M	LOCK NUT, CABLE ADJUSTING... (2 required per assembly)
		11-81761M - Lock Nut, Cable Adjusting, NLA [ More info ] $1.50 $1.28 1 In Stock.
#30	11-81778M	NUT, THROTTLE CABLE ADJUSTMENT... (2 required per assembly)
		11-81778M - Nut, Throttle Cable Adjustment,NLA [ More info ] Unavailable
#31	81037M	BRACKET, THROTTLE CABLE... (1 required per assembly)
		81037M - Bracket, NLA [ More info ] Unavailable
#32	25-82054M	GROMMET, STEERING HANDLE... (1 required per assembly)
		25-82054M - Grommet, NLA [ More info ] Unavailable
#33	11-82382M	. . (2 required per assembly) SERIAL 00020161-09999999
		11-82382M - Nut - Priced Individually [ More info ] $3.90 $3.12 10+ In Stock.
#34	82956M	COLLAR... (2 required per assembly) SERIAL 00000000-00026575
		82956M - Collar, NLA [ More info ] $2.50 1 In Stock.
#35	83093M	ARM, STEERING... . (1 required per assembly) SERIAL 00021891-09999999
#36	82895M	FRICTION... (1 required per assembly) SERIAL 00021891-09999999
		82895M - Guide, NLA [ More info ] $16.15 10 In Stock.
#37	10-82452M	.. (1 required per assembly) SERIAL 00021891-09999999
		10-82452M - Bolt - Priced Individually [ More info ] $1.29 10+ In Stock.
		10-84058M - Bolt [ More info ] $7.79 1 In Stock.
#38	11-83056M	. (1 required per assembly) SERIAL 00021891-09999999
		11-83056M - Nut, Nylon, NLA [ More info ] $2.70 9 In Stock.
#40	12-82220M	WASHER... (1 required per assembly) SERIAL 00021891-09999999
		12-82220M - Washer - Priced Individually [ More info ] Unavailable
