Parts for Mariner 8A Recoil Starter
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #0-1 | 80455M | STARTER ASS"Y... (1 required per assembly) |
  |
|
80455M - Starter, NLA [ More info ] Unavailable |
| #1 | 24-80457M | SPRING, STARTER... (1 required per assembly) |
  |
|
24-80457M - Spring, NLA [ More info ] Unavailable |
| #2 | 50-80458M | STARTER, SHEAVE... (1 required per assembly) |
  |
|
50-80458M - Starter Sheave, NLA [ More info ] Unavailable |
| #3 | 80460M | DRIVE, PLATE... (1 required per assembly) |
  |
|
80460M - Drive Plate [ More info ]
|
| #4 | 80469M | PAWL, STARTER... (2 required per assembly) |
  |
|
80469M - Starter Pawl, NLA [ More info ]
|
| #5 | 24-80459M | SPRING, DRIVE PLATE... (1 required per assembly) |
  |
|
24-80459M - SPRING,NLA [ More info ] Unavailable |
| #6 | 23-80473M | COLLAR, STARTER ASS'Y BOLT... (1 required per assembly) |
  |
|
23-80473M - COLLAR,NLA [ More info ] Unavailable |
| #7 | 12-82187M | WASHER, STARTER ASS'Y BOLT... (1 required per assembly) |
  |
12-82187M - Washer, Starter Bolt [ More info ] Unavailable |
|
  |
|
12-82209M - Washer, NLA [ More info ]
|
| #8 | 12-80466M | WASHER, THRUST-DRIVE PLATE... (1 required per assembly) |
  |
|
12-80466M - WASHER,NLA [ More info ] Unavailable |
| #9 | 43-80465M | GEAR, STARTER PINION... (1 required per assembly) |
  |
|
43-80465M - Starter Gear [ More info ]
|
| #10 | 23-80462M | SPACER, STARTER BOLT... (1 required per assembly) |
  |
|
23-80462M - COLLAR,NLA [ More info ] Unavailable |
| #11 | 12-80468M | WASHER, THRUST-STARTER BOLT... (1 required per assembly) |
  |
|
12-80468M - WASHER,NLA [ More info ] Unavailable |
| #12 | 80456M | BRACKET, STARTER PULLEY... (1 required per assembly) |
  |
|
80456M - Bracket, NLA [ More info ] Unavailable |
| #13 | 13-80467M | WASHER, TENSION-STARTER ASS'Y... (1 required per assembly) |
  |
|
13-80467M - WAVE WASHER,NLA [ More info ] Unavailable |
| #14 | 13-82190M | LOCKWASHER, STARTER ASS'Y BOLT... (1 required per assembly) |
  |
13-82190M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
| #15 | 10-80461M | BOLT, STARTER ASS'Y ATTACHING... (1 required per assembly) |
  |
|
10-80461M - BOLT,NLA [ More info ] Unavailable |
| #16 | 80470M | PULLEY, ROPE STARTER... (1 required per assembly) |
  |
|
80470M - PULLEY,NLA [ More info ] Unavailable |
| #17 | 12-82189M | WASHER, PULLEY BOLT... (2 required per assembly) |
  |
|
12-82189M - WASHER,NLA [ More info ] Unavailable |
| #18 | 23-80472M | COLLAR, PULLEY BOLT... (1 required per assembly) |
  |
|
23-80472M - COLLAR,NLA [ More info ] Unavailable |
| #19 | 10-82427M | BOLT, BRACKET ATTACHING... (1 required per assembly) |
  |
10-82427M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #20 | 13-82188M | LOCKWASHER, PULLEY BOLT... (1 required per assembly) |
  |
13-82188M - LOCKWASHER Note: Priced Individually [ More info ] Unavailable |
|
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #21 | 80063M | HANDLE, STARTER ROPE... (1 required per assembly) |
  |
80063M - Starter Handle [ More info ] Unavailable |
|
  |
|
814491A 1 - Handle Kit, NLA [ More info ]
|
| #22 | 79629A 1 | STARTER ROPE... (1 required per assembly) |
  |
79629A 1 - Starter Rope Note: Priced Individually [ More info ] Unavailable |
|
  |
50-28985A 2 - Starter Rope Assembly [ More info ] Unavailable |
|
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #23 | 83104M | SEAL RUBBER... (1 required per assembly) |
  |
|
83104M - SEAL,NLA [ More info ] Unavailable |
| #24 | 80471M | GUIDE, STARTER ROPE... (1 required per assembly) |
  |
|
80471M - GUIDE,NLA [ More info ] Unavailable |
| #25 | 24-82072M | SPRING, STARTER GUIDE... (1 required per assembly) |
  |
|
24-82072M - SPRING,NLA [ More info ] Unavailable |
| #26 | 53-82337M | SNAP RING, STARTER GUIDE... (1 required per assembly) |
  |
|
53-82337M - E RING,NLA [ More info ] Unavailable |
| #27 | 10-80474M | BOLT, GEAR DISTRIBUTION... (1 required per assembly) |
  |
|
10-80474M - BOLT,NLA [ More info ] Unavailable |
| #28 | 22-82369M | FITTING, GREASE... (1 required per assembly) |
  |
|
22-82369M - Fitting - Priced Individually [ More info ]
|
| #29 | 81439M | CAP, GREASE FITTING... (1 required per assembly) |
  |
|
81439M - Lubricap - Priced Individually [ More info ]
|
| #30 | 12-80463M | WASHER, GREASE BOLT THRUST (1.0 MM)... (AR required per assembly) |
  |
|
12-80463M - WASHER,NLA [ More info ] Unavailable |
| #30 | 12-80464M | WASHER, GREASE BOLT THRUST (2.0 MM)... (AR required per assembly) |
  |
|
12-80464M - WASHER,NLA [ More info ] Unavailable |
| #31 | 23-81944M | BUSHING, GREASE BOLT... (1 required per assembly) |
  |
|
23-81944M - Bushing,NLA [ More info ] Unavailable |
| #32 | 47341A 1 | EMERGENCY STARTER ROPE... (1 required per assembly) |
  |
47341A 1 - Rope And Handle [ More info ] Unavailable |
|
  |
|
47341A11 - Manual Start Rope And Handle [ More info ]
|
