Parts for Mariner 80 HP (3 Cylinder) Electrical Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 42968T | PLATE, Ignition (1 required per assembly) |
  |
42968T - PLATE [ More info ] Unavailable |
|
  |
42968 2 - Ignition Plate [ More info ] Unavailable |
|
  |
|
42968A23 - IGNITION PL,NLA [ More info ] Unavailable |
| #2 | 332-7778A 9 | SWITCH BOX (1 required per assembly) |
  |
332-7778A 9 - Switch Box [ More info ] Unavailable |
|
  |
|
332-7778A12 - Switch Box [ More info ]
|
  |
|
18-5775-1 - Switch Box, 332-7778A3, 12, 14, 114-7778 [ More info ]
|
  |
|
18-5775-1 - Switch Box, 332-7778A3, 12, 14, 114-7778 [ More info ]
|
  |
|
300-01852 - Switch Box [ More info ]
|
| #3 | 10-69079 | SCREW, (#10-16 x .440), Switch Box (1 required per assembly) |
  |
|
10-69079 - Screw [ More info ]
|
| #4 | 10-40007110 | SCREW, (M5 X 30), Switch Box (2 required per assembly) |
  |
|
10-40007110 - Screw, NLA [ More info ] Unavailable |
| #5 | 23-94304 | SPACER, Switch Box Screw (2 required per assembly) |
  |
|
23-94304 - Spacer - Switch Box Screw [ More info ]
|
| #7 | 84-41592A 4 | HARNESS ASSEMBLY, Primary (1 required per assembly) |
  |
|
84-41592A 4 - Harness, NLA [ More info ]
|
| #8 | 84-813715A 7 | CABLE, High Tension (1 required per assembly) |
  |
|
84-813715A 7 - Ignition Cable Set [ More info ]
|
| #9 | 85-63709A 1 | BOOT KIT, Spark Plug (3 required per assembly) |
  |
|
85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ]
|
| #10 | 33-97182 | SPARK PLUG (3 required per assembly) |
  |
33-97182 - NGK BUHW-2 Note: Priced Individually [ More info ] Unavailable |
|
  |
33-97182Q - NGK Spark Plug BUHW-2 - Priced Individually [ More info ] Unavailable |
|
  |
|
33-896329833 - Spark Plug - L78V - Priced Individually [ More info ] Unavailable |
  |
|
L78V - Champion Spark Plug ( #833M) [ More info ]
|
| #10 | 33-14103570 | SPARK PLUG, Begium, Canada (3 required per assembly) |
  |
33-14103570 - NGK Spark Plug BUZHW-2 - Priced Individually [ More info ] Unavailable |
|
  |
|
33-14103Q - NGK BUZHW-2 - Priced Individually [ More info ] Unavailable |
| #11 | 10-40113 25 | SCREW, Ignition Plate (3 required per assembly) |
  |
10-40113 25 - SCREW [ More info ] Unavailable |
|
  |
10-814752 25 - SCREW [ More info ] Unavailable |
|
  |
|
10-821550 25 - Screw - Priced Individually [ More info ]
|
| #12 | 339-7370A13 | IGNITION COIL ASSEMBLY (3 required per assembly) |
  |
339-7370A13 - Ignition Coil [ More info ] Unavailable |
|
  |
339-832757A 4 - Ignition Coil [ More info ] Unavailable |
|
  |
|
8M0230859 - Ignition Coil [ More info ]
|
  |
|
18-5186 - Ignition Coil 339-7370A13 [ More info ]
|
| #14 | 43542 | COVER, Ignition Coil (1 required per assembly) |
  |
|
43542 - Coil Cover [ More info ] Unavailable |
| #15 | 10-40007115 | SCREW, (M5 X 55), Ignition Coil Cover (6 required per assembly) |
  |
|
10-40007115 - Screw, NLA [ More info ]
|
| #20 | 58124A28 | MERCURY SWITCH ASSEMBLY (1 required per assembly) |
  |
58124A28 - Mercury Switch [ More info ] Unavailable |
|
  |
16731A 1 - Switch Assembly [ More info ] Unavailable |
|
  |
|
16731T01 - Switch Assembly [ More info ]
|
| #22 | 45915 | TERMINAL BLOCK (2 required per assembly) |
  |
|
86-45915 - Terminal Block [ More info ]
|
| #23 | 10-48408 | SCREW, (#10-16 x .500), Terminal Block (4 required per assembly) |
  |
|
10-48408 - Screw - Priced Individually [ More info ]
|
| #24 | 84-41591A 3 | WIRING HARNESS ASSEMBLY, Engine (1 required per assembly) |
  |
|
84-41591A 3 - Wiring Harness [ More info ]
|
| #25 | 88-79091 | FUSE, (20 Ampere) (1 required per assembly) |
  |
|
88-79091 - Fuse - 20 Amp - Priced Individually [ More info ]
|
  |
|
888M0207796 - FUSE-20 AMP Note: Priced Individually [ More info ]
|
| #26 | 84-88439A 3 | BATTERY CABLE, Positive (1 required per assembly) |
  |
|
84-88439A 3 - Battery Cable Assembly [ More info ]
|
| #26 | 84-88439A 4 | BATTERY CABLE, Negative (1 required per assembly) |
  |
|
84-88439A 4 - Cable Assembly -neg [ More info ]
|
| #27 | 89-96158 | SOLENOID STARTER (1 required per assembly) |
  |
89-96158 - Solenoid [ More info ] Unavailable |
|
  |
89-96158T - Solenoid, NLA Order 8M0185622 [ More info ] Unavailable |
|
  |
|
8M0185622 - Solenoid, Starter or Trim [ More info ]
|
  |
|
18-5817 - Solenoid 89-96158 [ More info ]
|
  |
|
SW058 - Solenoid [ More info ]
|
  |
|
89-02718 - Solenoid, 89-96158T [ More info ]
|
| #28 | 10-40007106 | SCREW, (M5 X 13), Starter Solenoid (2 required per assembly) |
  |
|
10-40007106 - Screw [ More info ]
|
| #29 | 12-40023 14 | WASHER, Starter Solenoid Screw (2 required per assembly) |
  |
|
12-40023 14 - Washer - Priced Individually [ More info ]
|
| #30 | 84-88807A 6 | WIRE, (3.50 Inches) Black, Solenoid Screw (1 required per assembly) (Quantity Of Two On Oyster) |
  |
|
84-88807A 6 - Wire Assembly [ More info ]
|
| #31 | 13-26992 | LOCKWASHER, (.250) (2 required per assembly) (Starter Solenoid Terminal) |
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #32 | 11-64015 | NUT, ( #8-32), Starter Solenoid Terminal (2 required per assembly) |
  |
|
11-64015 - Nut (1 /4-20) [ More info ]
|
| #33 | 11-26419 | NUT, (#8-32), Starter Solenoid Terminal (2 required per assembly) |
  |
|
11-26419 - Nut (#8-32) (brass) [ More info ]
|
| #34 | 84-88808A18 | WIRE, (3.00 Inch), Rectifier To Solenoid, Red (1 required per assembly) |
  |
|
84-88808A18 - Cable Assembly, NLA [ More info ]
|
| #35 | 12417T | COVER, Ignition (1 required per assembly) |
  |
12417T - Ignition Cover [ More info ] Unavailable |
|
  |
12417 1 - COVER [ More info ] Unavailable |
|
  |
|
12417 4 - Cover, NLA [ More info ]
|
| #36 | 10-40007114 | SCREW, (M5 X 50), Ignition Cover (3 required per assembly) |
  |
|
10-40007114 - Screw [ More info ]
|
| #37 | 12-89302 | WASHER, (.203 x .406 x .040), Ignition Cover Screw (3 required per assembly) |
  |
|
12-89302 - Washer (.203 X .406 X .040) [ More info ]
|
| #38 | 13473 1 | FUSE HOLDER (1 required per assembly) |
  |
|
13473 1 - Fuse Holder, NLA [ More info ]
|
| #39 | 68878A 6 | ALARM HORN AND WIRE ASSEMBLY, Electric Handle (1 required per assembly) |
  |
|
68878A 6 - Horn Assembly [ More info ]
|
| #40 | 68879 | COVER, Electric Handle (1 required per assembly) |
  |
|
68879 - Cover [ More info ] Unavailable |
| #41 | 10-40056107 | SCREW, (M5 x 16), Electric Handle (2 required per assembly) |
  |
|
10-40056107 - Screw [ More info ]
|
| #42 | 62351A 1 | RECTIFIER, See Note Below (1 required per assembly) |
  |
62351A 1 - Rectifier [ More info ] Unavailable |
|
  |
816770 - Rectifier [ More info ] Unavailable |
|
  |
816770T - 8M0058226 [ More info ] Unavailable |
|
  |
|
8M0058226 - Rectifier - Outboard [ More info ]
|
  |
|
18-99416 - Regulated Rectifier 445114, 193-5114 [ More info ]
|
  |
|
18-5707 - Rectifier 816770 [ More info ]
|
  |
|
300-01404 - Rectifier, 8M0058226 [ More info ]
|
  |
|
AR351 - Rectifier [ More info ]
|
| #43 | 17602A 1 | TERMINAL BLOCK, See Note Below (1 required per assembly) |
  |
|
17602A 1 - Rectifier Assembly [ More info ]
|
| #44 | 12082A 1 | VOLTAGE REGULATOR, Use With Reference Number 43 (1 required per assembly) |
  |
12082A 1 - Voltage Regulator [ More info ] Unavailable |
|
  |
12082A 7 - Voltage Regulator [ More info ] Unavailable |
|
  |
12082A 8 - Voltage Regulator [ More info ] Unavailable |
|
  |
|
815279A 2 - Voltage Regulator Kit [ More info ]
|
  |
|
18-5743-1 - Voltage Regulator, Mercury [ More info ]
|
  |
|
18-5741 - Voltage Regulator, 815279A2 [ More info ]
|
  |
|
300-26072 - Voltage Regulator, 815279A2 [ More info ]
|
| #45 | 10-40094 30 | SCREW, Use With Reference Number 43 (3 required per assembly) |
  |
10-40094 30 - SCREW [ More info ] Unavailable |
|
  |
|
10-40106 30 - Screw [ More info ]
|
| #46 | 11-45076 | NUT, (#10-32), Use With Reference Number 43 (3 required per assembly) |
  |
|
11-45076 - Nut (#10-32) (brass) [ More info ]
|
| #47 | 84-12201A 2 | HARNESS ASSEMBLY, Use With Reference Number 43 (1 required per assembly) |
  |
|
84-12201A 2 - Harness Assembly, NLA [ More info ]
|
