Parts for Chrysler 3.5 HP (1981) Power Head

Revise Search: All Models > 3.5 HP (1981) > 32H1D ( ) > Power Head

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	F521906	GASKET, CARBURETOR (1 required per assembly)
		27-F521906 - Carburetor Gasket [ More info ] $2.59 9 In Stock.
#	F521159	GASKET, REED PLATE (2 required per assembly)
		F521159 - F521159 - GASKET [ More info ] Unavailable Replaced by 27-F521159-1
		27-F521159-1 - Gasket, NLA [ More info ] Unavailable
#	F521168	GASKET, CARBURETOR ADAPTER (1 required per assembly)
		27-F521168 - Carburetor Adapter Gasket [ More info ] $2.99 $2.53 7 In Stock.
#	FC601010	*SHORT BLOCK (NOT SHOWN) (1 required per assembly) INCLUDE ALL ITEMS MARKED WITH AN ASTERISK ()**
		FC601010 - FC601010 - SHORT BLOCK [ More info ] Unavailable Replaced by 800-FC521010
		800-FC521010 - Short Block, NLA [ More info ] Unavailable
#1	F8028	WASHER, PLAIN (4 required per assembly)
		F8028 - 12F8008 [ More info ] Unavailable
		12-F8008 - Washer [ More info ] Unavailable
		12-35044 - Washer, (.281 X .625 X .065) Stainless Steel [ More info ] $2.49 10+ In Stock.
#2	F901938-1	SCREW, CYLINDER HEAD (4 required per assembly)
		10-F901938-1 - Screw, NLA [ More info ] $2.06 10+ In Stock.
#3	33-82370M	SPARK PLUG (L-86) (1 required per assembly)
		33-82370M - NGK B6HS Note: Priced Individually [ More info ] Unavailable
		33-82370M 1 - NGK B6HS - Priced Individually [ More info ] Unavailable
		33-813472 - NGK Spark Plug BR6HS , Priced Individually [ More info ] Unavailable
		L86C - Champion Spark Plug ( #306) [ More info ] $4.50 $3.29 Available to Order: Shipping delay up to 10 days.
#4	F1426	SCREW, HEX HD 1/4 - 20 X 7/16 (2 required per assembly)
		10-F1426 - SCREW-W/LW,NLA [ More info ] Unavailable
#5	F521518	HEAD, CYLINDER (1 required per assembly)
		900-F521518 - Cylinder Head,NLA [ More info ] Unavailable
#6	F521529	GASKET, CYLINDER HEAD (1 required per assembly)
		F521529 - 27F712529 [ More info ] Unavailable
		27-F712529 - Cylinder Head Gasket [ More info ] $28.09 $18.88 5 In Stock.
#7	FA601010	CYLINDER ASSEMBLY W/CRANKCASE COVER (1 required per assembly) ILLUS. 30, 31, AND 33
		FA601010 - FA601010 - CYLINDER ASSY [ More info ] Unavailable Replaced by -FA521010
		FA521010 - Cylinder Kit, NLA [ More info ] $79.99 $67.74 1 In Stock.
#8	39-818038A 1	RING SET, PISTON (2 RINGS) (1 required per assembly)
		39-818038A 1 - Rings - 2 - Standard, NLA [ More info ] Unavailable
#9	F250410	RING, RETAINING, PISTON PIN (2 required per assembly)
		53-F250410 - Ring - Retaining, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#10	F250017	PIN, PISTON (1 required per assembly)
		41-F250017 - Piston Pin, NLA [ More info ] $5.00 $4.24 10+ In Stock.
#11	F521015	PISTON (1 required per assembly)
		F521015 - Piston [ More info ] Unavailable
		700-F521015-1 - Piston, NLA [ More info ] $61.11 $51.76 1 In Stock.
#12	F2A521016	ROD, CONNECTING W/SCREWS AND BEARINGS AND ILLUS. 17 (1 required per assembly)
		F2A521016 - Connecting Rod Assembly,NLA [ More info ] Unavailable
		800-819265A 2 - Cylinder Kit, 5HP Force and Sears [ More info ] $85.00 1 In Stock.
#13	F2A237228	BEARING ASSEMBLY, W/CAGE AND ROLLERS (2 required per assembly)
		F2A237228 - Cage/Roller Assembly [ More info ] Unavailable
		FA567241 - Roller And Cage Set [ More info ] $10.78 10+ In Stock.
#14	F521279	GASKET, CYLINDER EXHAUST (1 required per assembly)
		27-F521279 - 27F5212791 [ More info ] Unavailable
		27-F521279-1 - Cylinder Exhaust Gasket [ More info ] $15.08 9 In Stock.
#15	F521579	SEAL, SPLINE, CRANKSHAFT (1 required per assembly)
		25-F521579 - 0-Ring Seal, Crankshaft Spline,NLA [ More info ] $1.80 5 In Stock.
#16	F521118-1	SEAL, CRANKSHAFT, LOWER (1 required per assembly)
		F521118-1 - Seal [ More info ] Unavailable
		26-819798 - Seal, NLA [ More info ] $19.76 10+ In Stock.
#17	F36634	SCREW, CONNECTING ROD (2 required per assembly)
		10-F36634 - SCREW,NLA [ More info ] Unavailable
#18	F2A527018	CRANKSHAFT ASSEMBLY (1 required per assembly) W/ILLUS. 38 AND 39
		400-F2A527018 - Crankshaft [ More info ] Unavailable
		400-819797A 1 - CrankShaft Assembly, NLA [ More info ] Unavailable
		800-819854A 5 - Powerhead Assembly, 5HP, 98-9 [ More info ] $69.99 1 In Stock.
#19	F521013	BEARING, CRANKSHAFT, UPPER (1 required per assembly)
		31-F521013 - Roller Bearing, NLA [ More info ] $7.55 3 In Stock.
#20	F521146	SEAL, CRANKSHAFT, UPPER (1 required per assembly)
		F521146 - F5211461 [ More info ] Unavailable
		F521146-1 - Seal [ More info ] Unavailable
		26-819799 - Seal, NLA [ More info ] $8.39 10+ In Stock.
#21	F211137-1	GRIP, STEERING HANDLE (1 required per assembly)
		F211137-1 - GRIP,NLA [ More info ] Unavailable
#22	F601079	HANDLE, STEERING (1 required per assembly)
		F601079 - HANDLE,NLA [ More info ] Unavailable
#23	F1893	SCREW 5/16 - 18 X 1 1/2 (1 required per assembly)
		10-F1893 - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#24	F1907	WASHER (2 required per assembly)
		F1907 - Washer, Stainless Steel [ More info ] Unavailable
		12-12038 - Washer [ More info ] $2.30 3 In Stock.
		12-8M0207778 - WASHER Note: Priced Individually [ More info ] $11.89 5 In Stock.
#25	F2108	NUT, LOCK 5/16 - 18 (1 required per assembly)
		11-F2108 - Nut (5/16-18) NLA [ More info ] $1.38 $1.17 10+ In Stock.
#26	F7023	NUT, LOCK 1/4 - 20 (4 required per assembly)
		11-F7023 - NUT,NLA [ More info ] Unavailable
#27	F601078	BRACKET, STEERING HANDLE STOP (1 required per assembly)
		F601078 - Bracket, NLA [ More info ] Unavailable
#28	F1891	SCREW 1/4 - 20 X 1 1/2 (1 required per assembly)
		10-F1891 - Screw -ss, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#29	F1699	SCREW 1/4 - 20 X 1 1/8 (2 required per assembly)
		10-F1699 - Screw -ss, NLA [ More info ] $3.22 10+ In Stock.
#30	F1789	PLUG, PIPE (1 required per assembly)
		22-F1789 - Pipe Plug, NLA [ More info ] Unavailable
#31	F8559	PIN, DOWEL (2 required per assembly)
		17-F8559 - Pin, Dowel [ More info ] $1.30 $1.11 10 In Stock.
#32	F2040	SCREW 1/4 - 20 X 5/8 (1 required per assembly)
		10-F2040 - Screw -ss, NLA [ More info ] Unavailable
#33	F1107	SCREW 1/4 - 20 X 3/4 (2 required per assembly)
		10-F1107 - Screw [ More info ] $0.70 $0.60 10+ In Stock.
#34	F1099	SCREW 1/4 - 20 X 1 1/4 (4 required per assembly)
		F1099 - 10F1504 [ More info ] Unavailable
		10-F1504 - Screw -ss [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#35	F1708	SCREW 1/4 - 20 X 1 3/8 (1 required per assembly)
		10-F1708 - Screw, NLA [ More info ] $1.36 $1.16 8 In Stock.
#36	F601647	HANDLE (1 required per assembly)
		F601647 - HANDLE,NLA [ More info ] Unavailable
#37	FG1015	GASKET SET. (1 required per assembly)
		27-FG1015 - Gasket Set, 3.5-4HP, 76- 8 [ More info ] $21.54 1 In Stock.
#38	F521270	SLINGER (1 required per assembly)
		F521270 - Slinger, NLA [ More info ] $1.88 $1.59 10+ In Stock.
#39	F521910	BEARING, CRANKSHAFT LOWER (1 required per assembly)
		30-F521910 - Ball Bearing, NLA [ More info ] $22.22 $18.82 5 In Stock.
