Parts for Chrysler 3.5 HP (1981) Motor Leg
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | F1645 | RD HD THD. CUTTING, 6 - 32 X 1/4 (3 required per assembly) |
  |
F1645 - Screw [ More info ] Unavailable |
|
  |
|
10-69080 - Screw [ More info ] Unavailable |
| #2 | FA341151 | PLATE, EXHAUST (1 required per assembly) W/ILLUS. 1 |
  |
|
FA341151 - PLATE KIT,NLA [ More info ] Unavailable |
| #3 | FK601133 | MOTOR LEG (1 required per assembly) W/ITEMS 1, 2, AND 32 |
  |
|
FK601133 - FK601133 - LEG KIT [ More info ] Unavailable Replaced by 1500-817940A5 |
  |
1500-817940A 5 - LEG KIT [ More info ] Unavailable |
|
  |
1500-817940A 6 - HSG ASSY-D SHAFT [ More info ] Unavailable |
|
  |
|
1500-817940A 7 - Drive Shaft Housing Assembly, NLA [ More info ] Unavailable |
| #4 | F1922 | HEX HD SCREW, 1/4 - 20 X 5/8 (6 required per assembly) |
  |
|
10-F1922 - Screw, NLA [ More info ] Unavailable |
| #5 | F46899-1 | COVER, SHIFT COUPLING (1 required per assembly) |
  |
|
25-F46899-1 - Shift Coupling Cover [ More info ]
|
| #6 | 817815A 4 | SWIVEL BRACKET - PORT (1 required per assembly) W/ILLUS. 21 ORIGINAL FORCE P/N A 468072-3 |
  |
817815A 4 - Bracket-PORT [ More info ] Unavailable |
|
  |
|
1400-817815A 5 - Bracket Kit - Port, NLA [ More info ] Unavailable |
| #7 | F521261 | LINE, WATER OUTLET (1 required per assembly) |
  |
|
32-F521261 - Water Line Outle, NLA [ More info ] Unavailable |
| #8 | F1445 | SCREW, 1/4 - 14 X 3/8 (1 required per assembly) |
  |
|
10-F1445 - SCREW,NLA [ More info ] Unavailable |
| #9 | 817810A 1 | LOCK BAR ASSEMBLY (1 required per assembly) |
  |
|
817810A 1 - Bar Kit - Lock, NLA [ More info ]
|
| #10 | F24074 | CLAMP SCREW FOOT (2 required per assembly) |
  |
|
F24074 - Foot- Clamp Screw, NLA [ More info ]
|
| #11 | F66480 | STUD (2 required per assembly) |
  |
|
17-F66480 - Clampscrew Stud [ More info ]
|
| #12 | FA28073-1 | CLAMP SCREW (2 required per assembly) W/ILLUS. 10, 11 AND 13 |
  |
|
FA28073-1 - Clamp Screw Kit,NLA [ More info ] Unavailable |
| #13 | F8537 | SPRING PIN (2 required per assembly) |
  |
|
17-F8537 - Spring Pin, NLA [ More info ]
|
| #14 | F7026 | STOP NUT 3/8 - 16 (1 required per assembly) |
  |
|
11-F7026 - Nut (3/8- 16)NLA [ More info ] Unavailable |
| #15 | F2014 | PLAIN WASHER (1 required per assembly) |
  |
|
|
  |
|
12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ]
|
| #16 | FA601532 | STERN BRACKET (2 required per assembly) W/ILLUS. 10, 11, 12 AND 13 |
  |
|
1400-FA601532 - Bracket Kit,NLA [ More info ] Unavailable |
| #17 | F468037-1 | PIVOT BOLT (1 required per assembly) |
  |
10-F468037-1 - Bolt -Special, NLA [ More info ] Unavailable |
|
| #18 | F2037 | PLAIN WASHER (2 required per assembly) |
  |
|
12-F2037 - Washer [ More info ]
|
| #19 | F468300 | SPRING, REVERSE LOCK (1 required per assembly) |
  |
F468300 - 24F4683001 [ More info ] Unavailable |
|
  |
|
24-F468300-1 - Spring, Reverse Lock,NLA [ More info ]
|
| #20 | F468349 | REVERSE LOCK (1 required per assembly) |
  |
|
F468349 - Reverse Lock, NLA [ More info ]
|
| #21 | F197813 | BEARING (2 required per assembly) |
  |
23-F197813 - Bushing -nyLiner [ More info ] Unavailable |
|
  |
|
23-26856 - Bushing [ More info ]
|
| #22 | F468350 | PIN, REVERSE LOCK (1 required per assembly) |
  |
|
17-F468350 - PIN-REVERSE LOCK,NLA [ More info ] Unavailable |
| #23 | F2035 | PHILLIPS FILL HD SCREW, 1/4 - 20 X 1 (4 required per assembly) |
  |
|
10-F2035 - Screw -ss, NLA [ More info ]
|
| #24 | FA601572 | SWIVEL BRACKET - STARBOARD (1 required per assembly) W/ILLUS. 21 AND 25 |
  |
|
FA601572 - BRKT KIT-SW,NLA [ More info ] Unavailable |
| #25 | F521661-1 | PAD, SWIVEL FRICTION (2 required per assembly) |
  |
|
F521661-1 - Pad, NLA [ More info ]
|
| #26 | F8083 | SPRING LOCKWASHER (1 required per assembly) |
  |
F8083 - LockWasher SS [ More info ] Unavailable |
|
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #27 | F1341 | NUT (1 required per assembly) |
  |
F1341 - Hex Nut 1/4 - 20 [ More info ] Unavailable |
|
  |
|
11-64015 - Nut (1 /4-20) [ More info ]
|
| #28 | F468169 | BEARING, SWIVEL BRACKET (2 required per assembly) |
  |
F468169 - 23F4681691 [ More info ] Unavailable |
|
  |
|
23-F468169-1 - Bearing - Swivel Bracket [ More info ]
|
| #29 | FA468346 | SHOCK MOUNT (2 required per assembly) W/LITERATURE |
  |
FA468346 - Mount Kit [ More info ] Unavailable |
|
  |
|
820161 - Mount, NLA [ More info ]
|
| #30 | F521244-1 | WATER LINE STANDARD LEG (1 required per assembly) |
  |
32-F521244-1 - Water Line, NLA [ More info ] Unavailable |
|
| #31 | F521342-1 | SEAL, WATER LINE (1 required per assembly) |
  |
|
26-F521342-1 - Seal, NLA [ More info ]
|
