Application Charts (30 HP - 40 HP)

Johnson Evinrude Application Charts

HP Model Year Cyl. Ign. Pack Stator Rec/Reg Trigger Harness Ign. Coil

30 Elect Start 89-91 2 113-4489 173-1670 153-1778 133-3387 R583648* 183-2508

30 TE 92 2 113-4489 173-1670 N/A 133-3387 N/A 183-2508

30 EE, EL, IE, SE 92 2 113-4489 173-1670 153-1778 133-3387 413-4398 183-2508

30 Manual Start 93-97 2 113-4767 173-1670 N/A 133-3387 N/A 183-3740

30 TE 93-97 2 113-4767 173-1670 153-1778 133-3387 N/A 183-3740

30 Elect Start 93-95 2 113-4767 173-1670 153-1778 133-3387 R584881* 183-3740

30 Elect Start 96-01 2 113-4767 173-1670 153-1778 133-3387 413-0016 183-3740

30 Manual Start 00-01 2 113-4767 173-1670 N/A 133-3387 413-0016 183-3740

30 JET 00 2 113-3241 173-1670 N/A 133-3387 N/A 183-3740

30 JET 1 2 113-4767 173-1670 N/A 133-3387 N/A 183-3740

33 68-70 2 MAGNETO N/A N/A POINTS N/A 183-4477

35 Manual Start 76 2 MAGNETO 173-1202 N/A POINTS N/A **502881

35 Electric Start 76 2 MAGNETO 173-1557 153-1778 POINTS 413-6720 **502881

35 Manual Start 77-84 2 113-2453 173-1670 N/A 133-3387 N/A 183-2366

35 Elect Start 77-80 2 113-2453 173-1651 153-1778 In Stator 413-9914 183-2366

35 Elect Start 78-81 2 113-2453 173-1651 153-1778 In Stator 413-9914 183-2366

35 Elect Start 82-84 2 113-2453 173-1670 153-1778 133-3387 413-1818 183-2366

35 Manual Start 83-84 2 113-2453 173-1670 N/A 133-3387 N/A 183-2366

35 Manual Start 85-87 2 113-2285 173-1670 N/A 133-3387 N/A 183-2508

35 Elect Start 85-87 2 113-2285 173-1670 153-1778 133-3387 R582524* 183-2508

35 Elect Start 87-88 2 113-2285 173-1670 153-1778 133-3387 413-3601 183-2508

35 Manual Start 88 2 113-2285 173-1670 N/A 133-3387 N/A 183-2508

35 Manual Start 89-92 2 113-4489 173-1670 153-1778 133-3387 N/A 183-2508

35 Elect Start 89-91 2 113-4489 173-1670 153-1778 133-3387 R583648* 183-2508

35 TE 92 2 113-4489 173-1670 153-1778 133-3387 N/A 183-2508

35 Manual Start 93-97 2 113-4767 173-1670 N/A 133-3387 N/A 183-2508

35 Manual Start 96-97 3 **586472 R178278* R584952* **584824 N/A **586323

35 AC Manual Start 96-97 3 **586472 R584954* R584952* **584824 R586091* **586323

35 Elect Start 96-97 3 **586472 R584821* 193-4890 **584824 R586044* **586323

35 TEL 96-97 3 **586472 R584821* 193-4890 **584824 R586045* **586323

35 TNT 96-97 3 **586472 R584821* 193-4890 **584824 R586043* **586323

35 A, R, RL 2000 3 **586472 R584954* N/A **584824 R586091* **586323

35 E, EL 2000 3 **586472 R584821* 193-4890 **584824 R586044* **586323

35 PL 2000 3 **586472 R584821* 193-4890 **584824 R586043* **586323

35 TEL 2000 3 **586472 R584821* 193-4890 **584824 R586045* **586323

35

JET TL, M ElecStart

92 2 113-4489 173-4333 153-1778 133-3387 413-4398 183-3740

35 Manual Start 92 2 113-4489 173-4333 N/A 133-3387 N/A 183-3740

35 JET TE, TTL, M 92 2 113-4489 173-4333 153-1778 133-3387 N/A 183-3740

35 JET TL, J

Elect Start

92-93 2 113-5316 173-4560 193-4476 133-5386 R584695* 183-3740

35 JET EL, TL 93-95 2 113-5316 173-4560 193-4476 133-5386 413-4686 183-3740

35 JET TE, TTL, M 93-95 2 113-5316 173-4560 193-4476 133-5386 R584695* 183-3740

35 95 2 113-5316 173-4560 193-4476 133-5386 413-4686 183-3740

35 JET EL, TL, TTL 96 2 113-5316 173-4560 193-4476 133-5386 R586020* 183-3740

35 Jet Elect Start 97 2 113-5316 173-4560 193-4476 133-5386 R586020* 183-3740

35 Jet Manual Start 97 2 113-4767 173-1670 N/A 133-3387 N/A 183-3740

40 68-73 2 MAGNETO N/A N/A POINTS N/A 183-4477

* Premier Services Availability Only ** Part Currently Unavailable by CDI Electronics at this time (a) Engines with Option 35 Amp Upgrade ***May Require Mounting Modification

TECH SUPPORT: 1.866.423.4832 CALL TO ORDER: 1.800.209.9624

81
