Application Charts (25 HP - 60 HP)

CSS Drop Down Menu by PureCSSMenu.com < Previous Page|Next Page >
Yamaha Application Charts
HP Year Stk. Model Cyl. Ign. Pack Stator Trigger Rectifier Ign. Coil
25 84-87 2 EL, ES, LH, SH 2 117-689-21 R689-81311-40*(C)
R689-81303-A0*(D)
689-85580-40-00** 157-664-61 689-85570-20-00**
25 88-93 2 EL, ES, LD, LF, LG,
ML, MS, SD, SF, SG
2 R6L2-85540-23-00* R6L2-85520-11*(C) 6L2-85580-10-00** 157-664-61 61N-85570-10-00**
25 90 2 CV25, EL, EM 2 117-695-11 R695-85520-70*(C)
R695-81303-A0*(D)
R695-85580-70-00* 157-664-61 6E7-85570-19-00**
25 91-97 2 C25, EL, ES, ML, MS 2 117-695-11 R695-85520-70*(C)
R695-81303-A0*(D)
R695-85580-70-00* 157-664-61 6E7-85570-17-00
25 94-05 2 EL, ES, ML, MS 2 R6L2-85540-23-00* R6L2-85520-11*(C)
R6L2-85533-10*(D)
6L2-85580-10-00**
6L2-85580-20-00**
157-664-61 61N-85570-10-00**
25 97-98 2 EL, ES, ML, MS 3 117-6J8-H1 R6H4-85520-01*(C)
R6H4-85533-A0*(D)
R6H4-85510-F1*(F) - 6H4-85570-20-00**
25 98-05 4 F25, EH, ER, TH 2 65W-85540-20-00** R65W-85510-10* R65W-85580-00*(I) 194-5279 65W-85570-01-00**
25 98-05 4 F25, MH 2 65W-85540-20-00** R65W-85510-00* R65W-85580-00*(I) 194-5279 65W-85570-01-00**
30 84-87 2 EL, ES, LH, SH 2 117-689-21 R689-81311-40*(C)
R689-81303-A0*(D)
R689-85580-40-00* 157-664-61 689-85570-20-00**
30 88-99 2 EL, ES, ML, MS 3 117-6J8-H1 R6H4-85520-20*(F)
R6J8-85520-00*(G)
R6H4-85510-F1*(F) - 6H4-85570-20-00**
30 89-90 2 CV30, EL 2 117-689-21 R689-81311-40*(C)
R689-81303-A0*(D)
R689-85580-40-00* 157-664-61 689-85570-20-00**
30 91-97 2 C30, EL 2 61N-85540-13-00** R61N-85541-09-00*(C) R61N-85543-09-00* 157-664-61 61N-85570-10-00**
30 99-02 2 EL, ES, ML, MS 3 117-6J8-H2 R6H4-85520-20*(F)
R6J8-85520-00*(G)
R6H4-85533-A1*(D)
6H4-85510-F1-
00**(F)
6J8-81960-00-00** 6H4-85570-20-00**
30 03-05 4 F30 2 67C-85540-01-00** R65W-85510-10* 65W-85580-00-00** 194-5279 67C-85570-00-00**
40 84-88 2 ALL 3 117-6H4-21 R6H4-85520-00*(C)
R6H4-81303-A0*(D)
6H4-85510-F0-00** 157-664-61 6H4-85570-20-00**
40 89-94 2 EL, EJ, ES, ETL, LD,
LF, MJ, ML, MS, PL,
SD, SF, TL
3 117-6H5-02 R63D-85520-00*(C)
R6H5-85533-01*(D)
6H5-85580-00-00**
6H5-85580-10-00**
6H5-85580-20-00**
157-664-61 6H5-85570-00-00**
40 90 2 CV40 2 117-689-21 R689-81311-40*(C)
R689-81303-A0*(D)
689-85580-40-00** 157-664-61 689-85570-20-00**
40 95-05 2 EL, ES, MJ, ML,
MS, TL
3 117-63D-04 R63D-85520-00*(C)
R63D-85533-10*(D)
63D-85580-00-00** 6H2-81960-10** 6H5-85570-00-00**
48 95-00 2 E48 2 117-696-12 R6E7-85520-70-00*
R696-81303-F0-00*
6E7-85580-70-00** 157-664-61 696-85570-11-00**
50 84-88 2 ALL 2 117-6H4-21 R6H4-85520-00*(C)
R6H4-81303-A0*(D)
6H4-85510-F0-00** 157-664-61 6H4-85570-20-00**
50 89-94 2 EL, EJ, ES, ETL, LD,
LF, MJ, ML, MS, PL,
SD, SF, TL*
3 117-6H5-02 R63D-85520-00*(C)
R6H5-85533-01*
6H5-85580-00-00**
6H5-85580-10-00**
6H5-85580-20-00**
157-664-61 6H5-85570-00-00**
50 95-05 2 EL, ES, MJ, ML,
MS, TL
3 117-6H5-04 R63D-85520-00*(C)
R63D-85533-10*(D)
63D-85580-00-00** 6H2-81960-10* 6H5-85570-00-00**
50 2005 4 F50 4 6C1-8591A-10-00** 6C5-81410-00-00** 62Y-85580-00-00** 68V-81960-00-00** 63P-82310-01-00**
55 89 2 CV55 2 117-TIA02-12 R663-85541-A0*(C)
R663-85565-A0*(h)
663-85580-10-00** 157-664-61 697-85570-11-00**
55 91-94 2 C60 2 117-TIA02-12 R663-85541-A0*(C)
R663-85565-A0*(h)
663-85580-10-00** 157-664-61 697-85570-11-00**
60 96-01 2 C60, P60 3 6H2-85540-12-00** R6H2-85520-01*(C)
R6H2-85533-01*(D)
6H2-85580-01-00** 6H2-81960-10** 697-85570-00-00**
60 99 2 E60 3 117-6H3-11 R6H3-85520-00*(C)
R6H3-85533-00*(D)
6H3-85510-A0-00** 157-664-61 697-85570-00-00**
60 01-05 2 TL 3 6H2-85540-A9-00** R6H2-85520-01*(C)
R6H2-85533-01*(D)
6H2-85580-01-00** 6H2-81960-10** 697-85570-00-00**
60 2005 4 F60 4 6C1-8591A-10-00** 6C5-81410-00-00** 62Y-85580-00-00** 68V-81960-00-00** 63P-82310-01-00**
(a) Low Speed (b) High Speed (c) Charge Coil (d) Lighting Coil (e) 10 Amp Lighting Coil (f) Manual Start (g) Electric Start (h) Blanking Coil
* Premier Services Availability Only ** Part Currently Unavailable by CDI Electronics at this time
TECH SUPPORT: 1.866.423.4832 CALL TO ORDER: 1.800.209.9624
135
Yamaha
Application Charts
