COMPLETE SYSTEMS
See application and ordering guides to select
appropriate components.
COMPONENTS
HELM
SeaStar 1.7 - Front Mount Helm
SeaStar 1.7 - Rear Mount Helm
SeaStar 1.7 - R. Mt. 1" Taper. Shaft
SeaStar 1.7 - Classic Tilt
CYLINDER
Cylinder-power steering (primary)
HC58xx
Cylinder-power steering (additional)
HC58xx
OIL COOLERS
Oil Cooler (2.25 Kw, 1" Water Lines)
Oil Cooler (6.25 Kw, 2" Water Lines)
OIL RESERVOIR & FILTER
Oil Reservoir
Oil Filter
HOSE/TUBING
Hose/Tubing for Manual Circuit
5/16” I.D.†
Hose/Tubing for Power Circuit
100R1 type
PUMPS
Outlet Check Power Pump
Pressure Relief Twin Pump
Pumps — Right-Hand Rotation:
Pump—Belt Drive, Right Rotation
(Universal)
Pump—Keyed Shaft, Right Rotation
Pump—Keyed Shaft, Direct Drive,
Right Rotation (Detroit Diesel)
Pump—Keyed Shaft, Direct Drive,
Right Rotation (2 GPM)
Pump—Direct Drive, Right Rotation
(No Flow Control)
Pump—Splined Shaft, Direct Drive,
Right Rotation (Caterpillar)
Pump—6-tooth (B Flange) Splined Shaft,
Direct Drive, Right Rotation)
Pump—9-tooth Splined Shaft,
Direct Drive, Right Rotation
Pump—9-tooth Splined Shaft,
Direct Drive, Right Rotation
Pump—9-tooth Splined Shaft,
Direct Drive, Right Rotation
Pump—11-tooth Splined Shaft,
Direct Drive, Right Rotation
Pump—11-tooth Splined Shaft,
Direct Drive, Right Rotation
Pump—13-tooth Splined Shaft, Direct Drive,
Heavy Duty Right Rotation (Twin Disc)
Pumps — Left-Hand Rotation:
Pump—Belt Drive, Left Rotation
(Universal)
Pump—Keyed Shaft, Right Rotation
Pump—Direct Drive,
Left Rotation
Pump—9-tooth Splined Shaft,
Direct Drive, Left Rotation
Pump—9-tooth Splined Shaft,
Direct Drive, Left Rotation
Pump—11-tooth Splined Shaft,
Direct Drive, Left Rotation
Pump—11-tooth Splined Shaft,
Direct Drive, Left Rotation
Pump—11-tooth Splined Shaft,
Direct Drive, Left Rotation
Pump—11-tooth Splined Shaft,
Direct Drive, Left Rotation
FLUID
SeaStar Oil (1 Gallon)
HA5440‡ or
Capilano Steering Fluid
Dexron II
®
ATF‡
STEERING - Inboard (Hydraulic)
SEASTAR INBOARD STEERING COMPONENTS:
† If using 1/4" I.D. tube, runs should be short and
SeaStar oil must be used.
‡ Use SeaStar fluid with SeaStar 1.4, 1.7, 2.0 &
2.4 helms or Dexron II
®
type ATF if using Capilano
1250V/1275V helms.
