191
CONTROLS - Dual Function
®
MT-3 TWIN
NEUTRAL
WARM-UP
(pull lever out
from dome)
MT-3 SINGLE
Pictured
Pictured
NEUTRAL
WARM-UP
(pull lever out
from dome)
Controls are shown with levers in partial forward throttle positions. At neutral, the control levers are about 30° aft from vertical to
provide more forward throttle lever arc.
MOUNTING
CUTOUT
DIMENSIONS:
