Sierra Marine Parts Catalog: Mercruiser
GIMBAL BEARING
GIMBAL BEARING
SEAL & GIMBAL BEARING KIT
Replaces: 30-36418
Replaces: 30-862540A3
(Link-Belt)
Fits: Gen II (1998-Up) and all Bravo
Fits:All Bravos, Alpha One Gen II (1998-up)
HEAvY DUTY GIMBAL BEARING
Replaces: 30-60794A4
(Link Belt)
Fits: Mercruiser- 120HP / 140HP
SEAL & GIMBAL
(2791957-6225576) ( With Gimbal Trim Sender), 165HP (2763442 & Up),
BEARING KIT
225S (3856268-4200499), 228HP (4782330 & Up), 233HP (4200500 & Up),
Fits: 1, R, MR and Alpha (1974-97)
250HP (4791300 & Up)
HINGE PIN
HINGE PIN
Replaces: 77123
Replaces: 10-86801
UPPER DRIvE UNIT CAP
UPPER DRIvE UNIT CAP
(with grease port)For gimbal housing
For gimbal housing
Replaces: 94998A2, 94998A4
Replaces: 828692A1
Fits: Alpha, Alpha Gen II
Fits: Alpha Gen II S/N 0M85639 & UP
S/N 0M815638 & Lower
S/N 6225577 & Later Alpha I, except Gen II
For: Gen II S/N F680000 & UP
Bravo All Models with trim sender
GIMBAL BEARING APPLICATION
Beginning
Ending
Gimbal
Beginning
Ending
Gimbal
Model
Year Range
Serial No.
Serial No.
Bearing
Model
Year Range
Serial No.
Serial No.
Bearing
60
1965-1972
1830753
3225967
898 / 228
1977-1982
4782330
6225576
80
1965-1972
1830753
3225967
250 / 260
1977-1982
1791300
6225576
90
1965-1972
1830753
3225967
R / MR / ALPHA I
1983-1990
6225577
& UP
ALPHA I SS
I
1963
1534570
1684187
1986-1989
A545004
& UP
IA
1964
1684186
1777798
1991-1997
D469859
K999999
ALPHA I GEN II
IB
ALPHA I GEN II
1964
1684188
1777798
1998-2010
L100040
& UP
IC
1964
1684188
1777798
VASER
2007-2010
W995000
& UP
EZ-SHIFT
1964
1684188
1777798
BRAVO I
1988-1995
B664190
F729999
120 / 140
1967-1973
2062141
3780849
BRAVO II
1988-1995
B664190
F729999
120 / 140
1974-1982
3780850
6225576
BRAVO III
1988-1995
B664190
F729999
470 / 485
1976-1982
4208730
6225575
BRAVO I
1996-2010
F730000
& UP
160 / 165
1967-1973
2065190
3780849
BRAVO II
1996-2010
F730000
& UP
165
BRAVO III
1974-1981
3780850
& UP
1996-2010
F730000
& UP
888
1971-1973
3106717
3784374
X / XR /XZ
1996-2010
F730000
& UP
888
1974-1977
3784375
& UP
BLACK HAWK
1994-1995
F186717
& UP
225 / 233
1974
3856268
& UP
DRIvE SHAFT
LOCK NUT
Replaces: 45-557961
DRIvE SHAFT
CARRIER NUT WASHER
Replaces: 11-22339
For: Gen II (S/N F680000 & UP),
714
/8" - 18
Replaces: 45-55796
Replaces: 12-45810
5
Mercruiser Vazer
