Sierra Marine Parts Catalog: Chrysler Inboard
fEatUrEs
Replaces points & condensers for true solid state ignition.
★
Uses standard coil, cap and rotor.
★
Easy to install, one-piece, 2-wire hook-up.
★
Accurate to within 1/4� timing accuracy 0 to 6000 RPM range.
★
Can be used with Flame Thrower Coil 18-5469
★
ELECTRONIC
ELECTRONIC
CONvERSION KIT
CONvERSION KIT
Fits most 4 cyl. Prestolite distributors. (Except IBM 7026)
Fits 6 cyl. Delco distributors
For: Onan, Universal, Waukesha, Wisconsin
IGNITION COIL
IGNITION COIL
Replaces: 201522, 2495531
Replaces: 200691
Uses External Resistor
Has Internal Resistor
fEatUrEs
Oil filled for better cooling and long life
�
Low resistance and improved turn ratios produces the higher voltage needed to run larger spark
�
plug gaps for added power and better fuel economy
More windings maximize energy and reliability over the full RPM range
�
Fits existing brackets for easy installation
�
HI-PERFORMANCE IGNITION COIL
HI-PERFORMANCE IGNITION COIL
0.6 ohm (oil filled), black - 4, 6, & 8 cylinder:
Flame-Thower 45,000 volt coil.
3.0 ohm (oil filled), black - 4 & 6 cylinder:
� Super low 0.6 ohm resistance coil designed
Flame-Thrower 40,000 volt coil.
� Designed for use with the original Ignitor
for use with the Ignitor II Hi Performance
Electronic Conversion Kits
Electronic Conversion Kits
� Compatible with capacitive discharge systems
� Can be used with other inductive ignition systems
Recommended
Resistance
Sierra Part #
Description
Coil
Ohms
Electronic Conversion Kit
3.0
Electronic Conversion Kit
3.0
Hi Performance Electronic Conversion Kit
0.6
IGNITION MODULE
COIL RESISTOR
COIL RESISTOR
RELUCTOR
IGNITION PICKUP
494
Replaces: 3874020
Replaces: 4106140
Replaces: 3874767
Replaces: 3656017
Replaces: 3780600
