Sierra Marine Parts Catalog: Yamaha
Figure
Figure
#
Description
Part #
O.E.M. #
Qty.
#
Description
Part #
O.E.M. #
Qty.
Gearcase 50-75 HP 3 Cyl 1979-2003
50
Screw, Water Inlet
--
98680-05545-00
1
1
Gearcase
--
6H1-45301-04-eK
1
51
Nut, Water Inlet
--
90185-05002-00
1
2
oil Seal, Shift Shaft
93106-09014-00
1
52
Trim Tab
988-45371-02-00
1
3
plate, Shift rod
--
688-45321-00-00
1
53
Bolt, Anode Mounting
--
90105-10M00-00
1
4
Bolt, Shift rod retainer
--
97395-06016-00
2
54
Nut, pinion
--
90170-16M01-00
1
5
Washer
--
92990-06600-00
2
55
Gear, pinion
--
688-45551-01-00
1
6
o-ring
--
93210-49046-00
1
56
Shifter
--
6H1-45641-01-00
1
7
o-ring
--
93210-07540-01
1
57
Shift Cam
--
6H1-44151-00-00
1
8
Circlip
--
99001-08600-00
1
58
Shift Slide
--
6H1-45634-02-00
1
9
rod, Shift
--
6H1-44144-00-00
1
59
pin
--
93603-12M11-00
1
10
Circlip
--
93450-07M00-00
1
60
Nut, Spring
--
90183-02M03-00
1
11
Bearing, pinion
--
93315-325V1-00
1
61
Shift plunger
--
6H1-45635-00-00
1
12
Sleeve, Drive shaft
--
688-45536-01-00
1
62
Shaft
--
6H1-45668-00-00
1
13
Shim Drive Shaft (0.10mm)
--
688-45587-01-10
Ar
63
Shift plunger
--
6H1-45635-00-00
1
Shim Drive Shaft (0.12mm)
--
688-45587-01-12
Ar
64
Spring, Compression
--
90501-12M48-00
1
Shim Drive Shaft (0.15mm)
--
688-45587-01-15
Ar
65
Washer, plate
--
90201-03313-00
1
Shim Drive Shaft (0.18mm)
--
688-45587-01-30
Ar
66
Nut, Spring
--
90183-02M03-00
1
Shim Drive Shaft (0.30mm)
--
688-45587-01-40
Ar
67
Spring, Compression
--
90501-16M65-00
1
Shim Drive Shaft (0.40mm)
--
688-45587-01-50
Ar
68
Shim Forward Gear (0.10mm)
--
688-45567-01-10
Ar
Shim Drive Shaft (0.50mm)
--
688-45587-01-16
Ar
Shim Forward Gear (0.12mm)
--
688-45567-01-12
Ar
14
Bearing, Upper Drive Shaft
--
93332-000U3-00
1
Shim Forward Gear (0.15mm)
--
688-45567-01-15
Ar
15
Key, Impeller
90280-04M04-00
1
Shim Forward Gear (0.18mm)
--
688-45567-01-18
Ar
16
Drive Shaft
--
6H1-45501-11-00
1
Shim Forward Gear (0.30mm)
--
688-45567-01-30
Ar
17
oil Seal, pump Base
93101-25M03-00
2
Shim Forward Gear (0.40mm)
--
688-45567-01-40
Ar
18
o-ring, Base
9321-46044-00
1
Shim Forward Gear (0.50mm)
--
688-45567-01-50
Ar
19
Gasket, Base
688-44316-A0-00
1
69
Bearing, Forward Gear
--
93332-000W7-00
1
20
Base, Water pump
--
688-44341-01-94
1
70
Gear, Forward
--
688-45560-00-00
1
21
Gasket, Wear plate to Base
--
688-44324-A0-00
1
71
Clutch, Dog
--
6H1-45631-01-00
1
22
Wear plate
18-3341
688-44323-00-00
1
72
pin, Cross
--
90250-07M02-00
1
23
Gasket, Wear plate to Housing
688-44315-A0-00
1
73
Spring, Cross pin
--
688-45633-00-00
1
24
pin
--
93604-10M03-00
1
74
Shaft, propeller
--
6H1-45611-01-00
1
25
Impeller
688-44352-03-00
1
75
Gear, reverse
--
6H1-45571-00-00
1
26
Insert, Water pump
--
688-44322-00-00
1
76
Shim reverse Gear (0.10mm)
--
688-45577-01-10
Ar
27
Housing, Water pump
688-44311-01-00
1
Shim reverse Gear (0.12mm)
--
688-45577-01-12
Ar
28
Bolt, Water pump
--
97395-08070-00
2
Shim reverse Gear (0.15mm)
--
688-45577-01-15
Ar
29
Bolt, Water pump
--
97395-08050-00
2
Shim reverse Gear (0.18mm)
--
688-45577-01-18
Ar
30 &
Shim reverse Gear (0.30mm)
--
688-45577-01-30
Ar
31
Washer, Water pump
--
90209-08M02-00
4
Shim reverse Gear (0.40mm)
--
688-45577-01-40
Ar
32
Nipple, Hose
--
6e5-45378-00-00
1
Shim reverse Gear (0.50mm)
--
688-45577-01-50
Ar
33
plug, Drain
90340-08M04-00
1
77
Washer, Thrust
--
688-45576-00-00
1
34
Gasket, Vent & Drain plugs
90430-08020-00
1
78
Bearing, reverse Gear
--
93306-207U0-00
1
35
plug, Drain
90340-08M04-00
1
79
o-ring, Bearing Housing
--
93210-85M97-00
1
36
Gasket, Vent & Drain plugs
90430-08020-00
1
80
Housing, Bearing
688-45331-00-94
1
37
plug, Drain
688-45341-00-00
1
81
Key
--
90282-04010-00
1
38
Gasket, Vent & Drain plugs
90430-08020-00
1
82
Bearing, Needle
--
93317-325U0-00
1
39
Bolt
--
97395-10040-00
2
83
oil Seal
93101-25M03-00
2
40
Washer, Lock
--
92990-10100-00
2
84
Washer, Tab
--
688-45383-02-00
1
41
Washer, Flat
--
92990-10600-00
2
85
Nut, Cover
--
688-45384-00-00
1
42
Bolt
--
97395-10040-00
2
86
Spacer, Forward
--
688-45987-01-00
1
43
Washer, Lock
--
92990-10100-00
2
87
Spacer
688-45997-01-00
1
44
Washer, Flat
--
92990-10600-00
2
88
Washer, propeller
--
90201-17M00-00
1
45
Bolt
--
97395-08060-00
1
89
Nut, Castle
90171-16011-00
1
46
Washer, Lock
--
92990-08100-00
1
90
pin, Cotter
91490-40030-00
1
47
Washer, Lock
--
92990-08100-00
1
91
Water pump repair Kit
692-W0078-00-00
1
48
Cover, Water Inlet (port)
--
688-45214-02-00
92
Gear Housing Seal Kit
688-W0001-20-00
1
49
Cover, Water Inlet (Stbd)
--
688-45215-02-00
1
Ar
As required
461
