Sierra Marine Parts Catalog: Mercury Mariner
-- CONTAINS --
Part #
Desc.
O.E.#
Qty.
Thermostat Gasket
27-62386
2
O-Ring
254029
1
O-Ring
25-62700
1
Reed Block Gasket
27-65744-3
6
Adapter Cover Gasket
27-78246
1
Relief Valve Plate Gasket
27-78690
2
Relief Valve Plate Gasket
27-88907
2
O-Ring
25-20415
2
O-Ring
25-35480
1
Reed Block Housing Gasket
27-93536-1
1
Divider Plate Gasket
27-90484-1
2
Drive Shaft Hsg. to Exhaust Plate Gasket
27-99177-1
1
18-2506
Exhaust Plate Gasket
27-99176-3
1
18-2508
Exhaust Plate Gasket
27-99776-1
2
Carb. Mtg. Gasket
27-67751
3
Reed Block Housing Gasket
27-96761-1
1
Drive Shaft Housing to Plate Gasket
27-99173-2
1
Cyl Block Sealing Gasket
27-11338
2
Carb. Mounting Gasket
27-90430
3
Cyl. Cover
27-96278
2
Water Pump Base to Gear Housing Gasket
27-85610-1
1
Water Pump Gasket
27-85608-1
1
Water Pump Gasket
27-85609-1
1
Bushing
26-38970
2
O-Ring
25-25439
1
O-Ring
25-29976
1
O-Ring
25-31534
1
O-Ring
25-33145
1
O-Ring
25-33466
1
O-Ring
25-48171
4
O-Ring
25-45711
2
O-Ring
25-90011
1
18-7196
O-Ring
25-38099
1
Fuel Pump Kit
89031A2
1
18-7816
Fuel Pump Diaphragm Kit
21-42990A9
1
Head Gasket
27-96542-1
2
Induction Silencer Cover Gasket
27-67275-1
1
POWERHEAD GASKET SET
Carburetor Gasket
27-89221-1
3
Water Pump Gasket
27-42631-1
1
Replaces: 27-90484A88
O-Ring
--
1
-- CONTAINS --
Part #
Desc.
O.E.#
Qty.
Thermostat Gasket
27-62386
2
O-Ring
254029
1
O-Ring
25-62700
1
Reed Block Gasket
27-65744-3
6
Adapter Cover Gasket
27-78246
1
Relief Valve Plate Gasket
27-78690
2
Relief Valve Plate Gasket
27-88907
2
O-Ring
25-20415
2
O-Ring
25-35480
1
Reed Block Hsg. Gasket
27-93536-1
1
Divider Plate Gasket
27-90484-1
2
Drive Shaft Hsg. to Exhaust Plate Gasket
27-99177-1
1
18-2506
Exhaust Plate Gasket
27-99176-3
1
18-2508
Exhaust Plate Gasket
27-99776-1
2
Carb. Mtg. Gasket
27-67751
3
Reed Block Hsg.Gasket
27-96761-1
1
Drive Shaft Hsg.to Plate Gasket
27-99173-2
1
Cyl Block Sealing Gasket
27-11338
2
Carb. Mtg. Gasket
27-90430
3
Cyl. Cover
27-96278
2
Water Pump Base to Gear Housing Gasket
27-85610-1
1
Water Pump Gasket
27-85608-1
1
Water Pump Gasket
27-85609-1
1
Bushing
26-38970
2
O-Ring
25-25439
1
O-Ring
25-29976
1
O-Ring
25-31534
1
O-Ring
25-33145
1
O-Ring
25-33466
1
O-Ring
25-48171
4
O-Ring
25-45711
2
O-Ring
25-90011
1
18-7196
O-Ring
25-38099
1
Fuel Pump Kit
89031A2
1
18-7816
Fuel Pump Diaphragm Kit
21-42990A9
1
Head Gasket
27-41246-1
2
Induction Silencer Cover Gasket
27-67275-1
1
Carburetor Gasket
27-89221-1
3
POWERHEAD GASKET SET
Water Pump Gasket
27-42631-1
1
Replaces: 27-11338A88, 27-89221A88
O-Ring
--
1
O-Ring
25-90011
1
-- CONTAINS --
Part #
Desc.
O.E.#
Qty.
Baffle Plate to Exhaust Gasket
27-85488-2
1
Adapter Plate Gasket
27-38501-1
1
Block Cover Gasket
27-43777-2
1
Powerhead to Ext. Plate Gasket
27-79650-1
2
Baffle Plate Gasket
27-85492-2
1
Carb. Flange Gasket
27-75791-1
2
Transfer Port Cover Gasket
27-27936-1
2
Rubber Seal Gasket
37721
1
O-Ring
25-32546
1
Thermostat Gasket
27-48818-1
1
Lower Water Pump Base to
Face Plate Gasket
27-19553
1
Water Inlet Tube Gasket
27-79797-1
1
Water Pump Base Gasket
27-32771
1
POWERHEAD GASKET SET
O-Ring
25-25439
1
Replaces: 27-85491A90
O-Ring
25-20081
1
GASKET SET APPLICATION BEGINS ON PAGE 359
355
*POWER HEAD GASKET SETS DO NOT INCLUDE HEAD GASKETS
