Sierra Marine Parts Catalog: Mercury Mariner
WATER PUMP KIT
WATER PUMP KIT
Replaces: 46-73640A2
Replaces: 46-77177A3
-- CONTAINS --
-- CONTAINS --
Part #
Desc.
O.E. #
Qty.
Part #
Desc.
O.E. #
Qty.
Impeller
47-89983
1
Impeller
47-89983
1
Upper Pump Housing
46-77822A1
1
Upper Pump Housing
46-77822A1
1
Water Pump Base
46-73640A1
1
Water Pump Base
46-77177A1
1
Drain Gasket.
12-20260, 12-19183
2
Drain Gasket.
12-20260, 12-19183
2
Lower Water Pump Base to
Lower Water Pump Base to
27-32769,
Face Plate Gasket
27-32769, 27-19553
1
Face Plate Gasket
27-19553
1
Upper Face Plate To Body Gasket
27-32770, 27-19551
1
Upper Face Plate To Body Gasket
27-32770, 27-19551
1
Water Pump Base Gasket
27-32771
1
Water Pump Base Gasket
27-32771
1
Water Pump Base Gasket
27-77417, 27-19552
1
Water Pump Base Gasket
27-77417, 27-19552
1
Drain Plug
12-49221-1
1
Drain Plug
12-49221-1
1
Plate
54705
1
Plate
54705
1
O-Ring
25-26855
1
O-Ring
25-26855
1
O-Ring
25-45711
1
O-Ring
25-45711
1
O-Ring
25-26722
1
O-Ring
25-26722
1
WATER PUMP HOUSING KIT
WATER PUMP HOUSING KIT
Replaces: 817275A1
Replaces: 817275A2
V-6 outboard
V-6 outboard
WATER PUMP REPAIR KIT
WATER PUMP KIT
Without Housing
Replaces: 46-70941A3
Replaces: 46-84277M, 46-84277T
For: 4/4.5 HP
-- CONTAINS --
-- CONTAINS --
Part #
Desc.
O.E. #
Qty.
Part #
Desc.
O.E. #
Qty.
Wear Plate Gasket
--
1
Impeller
47-89981
1
Impeller
47-84027M
1
Impeller Plate
46895
1
Woodruff Key
28-8192M
1
341
APPLICATION BEGINS ON PAGE 343
