Sierra Marine Parts Catalog
SHIELDS OIL TANK FILL HOSE
Shields Oil Tank Fill Hose has a nitrile/
PVC blend for excellent oil resistance. It
has a flexible corrugated design, smooth
bore and a vinyl helix to prevent collapse.
It also resists ozone and cold temperature
cracking. This hose is primarily used for
2-cycle oil tank fill.
Bulk Pack
Dist. Pkg.
Bend
Wt
100' (30.5m)
50" (15.2m)
10' (3.1m)
I.D.
mm
Radius
mm
"C"
Coils Code #
R/O Ctn. Code #
Ctn Code #
1 1/2"
16-309-1120
16-309-1126
16-309-1123
38.1
4"
101.6
22
SHIELDS SILvERADO 2000 FUEL vENT LINE
Silverado 2000 Fuel Vent Line is primarily used for
fuel tank vent (outside the engine compartment)
and is for pleasure boats only. The Temperature
range is -5 F to +180 F. It meets SAE J1527
Type A2 standards.
50' (15.2m)
Dist. Pkg.
10' (3.1m)
Burst
Wt.
Bulk Pack
R/O Ctn.
25' (7.6m)
Polypac
I.D.
mm
O.D.
mm
Ply
Pressure
"C"
Code #
Code #
R/O Ctn. Code #
Code #
/8"
/32"
16-315-0580 (250' reel)
16-315-0586
16-315-0585
16-315-0583
15.9
23.0
2
175#
24.0
5
29
79
