Sierra Marine Parts Catalog
SHIELDS 1300/1350 WATER/HEATER HOSE
Shields 1300/1350 Water / Heater Hose is fabric reinforced
and has an EPDM tube and cover. This hose is primarily
used for engine heater hose, heat exchanger, A/C circula-
tion, and drain lines (sink, icebox, shower and livewell).
It is resistant to mild chemicals, heat, cold, ozone and
saltwater. The temperature ranges from -40�F � +212�F.
SHIELDS 1300 Water/Heater Hose
Bulk Pack
Dist. Pkg.
Working
Bulk Pack
50' (15.2m)
25' (7.6m)
I.D.
mm
O.D.
mm
Pressure
Wt. "C"
Code #
m
R/O Ctn. Code #
R/O Ctn. Code #
/2"
/4"
16-130-0120 (500' reel)
16-130-0126
12.7
18.69
62 PSI
17
152.4
--
1
3
/8"
/8"
16-130-0580 (500' reel)
16-130-0586
16-130-0585
15.9
22.3
62 PSI
21
152.4
5
7
/4"
16-130-0340 (500' reel)
16-130-0346
16-130-0345
19.1
1"
25.48
50 PSI
26
152.4
3
SHIELDS 1350 HEAvY DUTY Water/Heater Hose
Dist. Pkg.
Working
Wt.
Bulk Pack
50' (15.2m)
I.D.
mm
O.D.
mm
Pressure
"C"
Code #
m
R/O Ctn. Code #
/2"
/16"
16-135-0120 (550' reel)
16-135-0126
12.7
20.6
200 PSI
19
167.6
1
13
/8"
/32"
16-135-0580 (450' reel)
16-135-0586
15.9
24.59
200 PSI
26
137.2
5
31
/4"
1 /64"
16-135-0340 (400' reel)
16-135-0346
19.1
28.4
200 PSI
33
121.9
3
1
13/64"
16-135-1000 (300' reel)
16-135-1006
1"
25.4
36.6
150 PSI
52
91.4
SHIELDS 1600 WATER/HEATER HOSE
Shields 1600 Water/Heater Hose has a good bend radius, is fabric reinforced, and has an EPDM tube and cover.
This hose is primarily used for critical water connections, heat exchanger, toilet intake, small engine intake, bilge
pump intake/discharge, and below water line drains and scuppers. It is resistant to mild chemicals, heat, cold,
ozone and saltwater. The temperature ranges from -40�F � +190�F
Dist. Pkg.
Working
Wt.
Bulk Pack
50' (15.2m)
I.D.
mm
O.D.
mm
Pressure
"C"
Code #
m
R/O Ctn. Code #
/8"
/64"
16-160-0380B (500' reel)
16-160-0386B
9.5
17.8
250 PSI
17
152.4
3
45
/2"
/32"
16-160-0120B (450' reel)
16-160-0126B
12.7
21.3
250 PSI
22
137.2
1
27
/8"
16-160-0580B (400' reel)
16-160-0586B
15.9
1"
25.4
250 PSI
28
121.9
5
/4"
19/64"
16-160-0340B (300' reel)
16-160-0346B
19.1
28.8
250 PSI
34
91.4
3
129/64"
16-160-1000B (250' reel)
16-160-1006B
1"
25.4
36.8
200 PSI
52
76.2
11/4"
1.3/4"
16-160-1140B (200' reel)
16-160-1146B
31.8
44.5
200 PSI
62
61.0
69
