Sierra Marine Parts Catalog
**UN21280 Red
*UN21282
� 12 VDC use only
**UN21290 Green
� 17/32" Lense
*UN21292
� Insulated plastic socket
Large Indicator Lights
**UN22190
� Chrome plated brass bezel
12 VDC use only
**UN21320
*UN22192
� 1 1/16"L x 3/4" mounting socket
� 1/2" mounting hole
*UN21322 Amber
PILOT LIGHT
� Replaceable bulb
� 4" tinned copper wire leads
Weather Resistant Push Pull Switches
**MP39380
*MP39382
**MP39390
OFF-ON SPST
*MP39392
� Solid brass construction
OFF-ON SPST
� Solid brass construction
� Gasket sealed case
with chrome plated plastic knob
� Vinyl coated body to resist moisture
� 3/8" mounting bushing
**MP39390B
� Two 18 gauge x 12" wire leads
� 2 screw terminals
*MP39392B
� 3/8" mounting bushing
� 3/4" chrome plated brass knob
OFF-ON SPST
� For panels up to 1" thick
� For panels up to 1" thick
with chrome plated brass knob
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
Heavy Duty Marine Push Pull Switches
**MP39520
**MP39510
**MP39530
*MP39522
*MP39512
*MP39532
OFF-ON SPST
OFF-ON SPST
OFF-ON SPST
� Pull for ON
� Pull for ON
� Pull for ON
� Solid brass construction
� Solid brass construction
� Solid brass construction
� 3/8" mounting bushing
� 3/8" mounting bushing
� 3/8" mounting bushing
� 2 screw terminals
� 2 screw terminals
� 2 screw terminals
� For panels up to 1" thick
� For panels up to 1" thick
� For panels up to 1" thick
� Chrome plated plastic knob
� Cream plastic knob
� Chrome plated solid brass knob
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
**MP39570
**MP39540
*MP39572
**MP39600
*MP39542
OFF-ON(1)-ON(1&2) SPDT
*MP39602
OFF-ON SPST
� First pull energizes #1
OFF-ON (1 & 2) SPST
� Pull for ON
� Second pull energizes both circuits
� Pull for ON - turns on two separate circuits
� Solid brass construction
� Solid brass construction
� Solid brass construction
� 3/8" mounting bushing
� 3/8" mounting bushing
� 3/8" mounting bushing
� 2 blade terminals
� 3 screw terminals
� 3 screw terminals
� For panels up to 1" thick
� For panels up to 1" thick
� For panels up to 1" thick
� Chrome finish plastic knob
� Chrome finish plastic knob
� Chrome plated solid brass knob
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
**MP39580
**MP39590
**MP39610
*MP39582
*MP39592
*MP39612
OFF-ON(1)-ON(1&2)
OFF-ON(1)-ON(1&2)
OFF-ON(1)-ON(2&3)
SPDT
SPDT
SPDT
� First pull energizes #1
� First pull energizes #1
� First pull energizes #1
� Second pull energizes two separate circuits
� Second pull energizes both circuits
� Second pull energizes both circuits
� For anchor/running lights or similar function
� Solid brass construction
� Solid brass construction
� Solid brass construction
� 3/8" mounting bushing
� 3/8" mounting bushing
� 3/8" mounting bushing
� 3 screw terminals
� 3 blade terminals
� 4 screw terminals
� For panels up to 1" thick
� For panels up to 1" thick
� For panels up to 1" thick
� Chrome plated solid brass knob
� Chrome finish plastic knob
� Chrome finish plastic knob
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
Rated: 15 amp @ 12 VDC
44
*BULK - 100 pcs. per carton
**CLAMSHELL
