Sierra Marine Parts Catalog
3 POSITION CONvENTIONAL � OFF � RUN � START
MP39060-1 � CLAMSHELL
MP39080-1 � CLAMSHELL
MP39120 � CLAMSHELL
MP39062-1 � BULK 100 PCS/CTN
MP39082-1 � BULK 100 PCS/CTN
MP39122 � BULK 100 PCS/CTN
DeSCrIpTIoN
DeSCrIpTIoN
DeSCrIpTIoN
Material
Brass
Material
Brass
Material
polyester
Length
Length
Long: 1 1/8" maximum panel thickness
Long: 1 1/8" maximum panel thickness
Long: 1 1/8" maximum panel thickness
Length
3 Screw Tab
Terminal Type
Terminal Type
3 Screw Tab
Terminal Type
3 Screw Tab
Back Up Nut
Brass
Back Up Nut
Brass
Brass
Back Up Nut
Face Nut
Knurled black plastic w/rubber cap
Face Nut
Hex Chrome Face Nut
Face Nut
Hex black plastic face nut
7/8"
Hole Size
7/8"
Hole Size
7/8"
Hole Size
rated;
rated;
rated;
Ignition
15 Amp @ 12v DC
Ignition
15 Amp @ 12v DC
Ignition
15 Amp @ 12v DC
Solenoid
30 Amp @ 12v DC
Solenoid
30 Amp @ 12v DC
30 Amp @ 12v DC
Solenoid
MP39200 � CLAMSHELL
MP39780 � CLAMSHELL
MP39770 � CLAMSHELL
MP39202 � BULK 100 PCS/CTN
MP39782 � BULK 100 PCS/CTN
MP39772 � BULK 100 PCS/CTN
DeSCrIpTIoN
DeSCrIpTIoN
DeSCrIpTIoN
Material
polyester
Material
polyester
Material
polyester
Long: 1 1/8" maximum panel thickness
Length
Short: 5/8" maximum panel thickness
Length
Length
Long: 1 1/8" maximum panel thickness
Terminal Type
3 Screw Tab
Terminal Type
3 Screw Tab
Terminal Type
3 Blade
Back Up Nut
Brass
Brass
Back Up Nut
Back Up Nut
Brass
Face Nut
Knurled black plastic w/rubber cap
Face Nut
Hex black plastic face nut
Face Nut
Knurled black plastic w/rubber cap
Hole Size
7/8"
Hole Size
7/8"
Hole Size
7/8"
rated;
rated;
rated;
Ignition
15 Amp @ 12v DC
Ignition
15 Amp @ 12v DC
Ignition
15 Amp @ 12v DC
30 Amp @ 12v DC
Solenoid
Solenoid
30 Amp @ 12v DC
Solenoid
30 Amp @ 12v DC
2 POSITION CONvENTIONAL � OFF�ON�
USE WITH SEPARATE STARTER BUTTON
MP41030 � CLAMSHELL
MP39020 � CLAMSHELL
MP39010 - CLAMSHELL
MP41032 � BULK 100 PCS/CTN
MP39022 � BULK 100 PCS/CTN
MP39012 - BULK 100 PCS/ CTN
DeSCrIpTIoN
DeSCrIpTIoN
Description
Material
polyester
Material
Brass
Material
Brass
Length
Short: 1 1/8" maximum panel thickness
Long: 1 1/8" maximum panel thickness
Length
Length
Short: 5/8" maximum panel thickness
Terminal Type
3 Screw Tab
Terminal Type
2 Screw Terminal
Terminal Type
2 Screw Tab
Back Up Nut
Brass
Back Up Nut
Brass
Back Up Nut
Brass
Face Nut
Knurled black plastic w/rubber cap
Face Nut
Hex Chrome Face Nut
Face Nut
Hex Chrome Face Nut
Hole Size
7/8"
Hole Size
7/8"
Hole Size
3/4"
rated;
rated;
Ignition
15 Amp @ 12v DC
rated;
28
Ignition
5 Amp @ 12 VDV
Solenoid
30 Amp @ 12v DC
Ignition
15 Amp @ 12v DC
